Triarch 31911 Quick start guide

ASSEMBLY AND MOUNTING INSTRUCTION

For31911

Please read the Assembly lnstruction sheet carefully before proceeding.Carefully unpack and

identify all parts prior to building the unit. Each part is identified on the drawingfor reference.

DO NOT DISCARD THE ORIGINAL PACKAGING. If after careful inspection and you must returnthe item

for any reason. Please repack the unit using the original carton and inserts.

STEP 1:Unpack all the parts and Classify them according to the illustration shown

at the side.Place the parts on a scratchfree surface;

Fi ni al Knob

Bot t om Cap

Nut

Glass Washer

Gl ass Shade

Threaded Nipple

Fixture

Pan j unct i on

box scr ew

Junct i on box

screws

Nut Cap

Uni ver s al mount i ng bar

STEP 2:install center rod,washer to the

Fixture

STEP 3: Install correct bulbs(not provided);

STEP 4: Install the Glass shade and fix it with

the Glass washer,and the nus;

STEP 5: Secure with bottom cao and the finial;

STEP 6: Make sure the power is turned off at

the junction box where the fixture is to be

installed.Secure the cross bar to the ceiling

juncton box using junction box screws;

STEP 7: Use the wire nuts to connect the

positive and negative wires.connect the

ground wire to the junction box ground

port;

STEP 8: Secure the fixture to the ceiling with

the ball nuts.(FOR FLUSH ONLY)

STEP 9: Secure the canopy to the ceiling with

the Knurled RingFOR PENDANT ONLY)

STEP10: Install the Loop to the Fixture;Buckle

The Quick Links to the Loops;(FOR PENDANT

ONLY)
