TRENDnet TW-200 User manual

The TW-200 is a IP address sharing device which

allows your entire network to logon to the Internet

with only one ISP account, and assigned IP address

to all network users. The TW-200 is equipped with

high-speed COM ports through which analog

modems or ISDN terminal adapters can be attached.

Through one modem, your entire network can

access the Internet. It eliminates the need for a

separate modem, phone line and phone charges for

each individual user.

TW-200

2-port Ethernet Internet Station

BENEFITSFEATURES

Integration Friendly:

Cost Effective:

Flexible:

Security:

Performance:

Designed to easily integrate into any

Ethernet network.

Saves router costs, on-line charges,

and less expensive than owning a

class C IP address.

Can be used in either LAN or WAN

and 10Base-2 or 10Base-T

environments.

Built-in firewall and secure gateway

for LAN users.

Asynchronous WAN port supports up

to 230.4Kbps data transfers.

Connect to the Internet via 10Base-T or 10Base-2

connections

Supports Win3.x/95/98/NTTM, NetwareTM , Mac, OS/2,

LANtastic, and many others

Asynchronous WAN port supports up to 230.4Kbps data

transfer

Easy configuration through your Web browser

Monitors communications link for inactivity and drops the

connection. (user defined)

Built-in firewall and secure gateway for LAN users

5 Year Warranty

TW-200 (11-17-2002)

TRENDnet

TRENDware, USA

What's Next in Networking

PRODUCT INFORMATION

To Order Please Call:

1-888-326-6061

TW-100

1-port Ethernet Internet Station

TW-200

2-port Ethernet Internet Station

NETWORKING SOLUTIONS

SPECIFICATIONS

TW-200

2-port Ethernet Internet Station

TW-200

2-port Ethernet Internet Station

Protocols:

• PPP(RFC1661), compression TCP/IP(RFC 1144),

CHAP/PAP IP(791), ICMP(792), ARP(826),

SNMP(1157), DHCP(1533,1541)

Security:

• PAP/CHAP(RFC1334), local password

Management:

• VT100,VT102, VT220 compatible terminal

application via its RS-232 port.

• Internet Browser

LAN Port:

• 1 x 10Base-2 (BNC) and 1 x 10Base-T (RJ45)

10Mbps Connector type auto-sensing Ethernet

interface

WAN Port:

• 2 x asynchronous ports (male)

WAN Speed:

• 230.4Kbps Max. Speed

Weight:

• 440g /15 oz. (excluding power adapter)

Power Consumption:

• DC 12v/800mA

Dimensions:

• 255mm x 140mm x 40mm (LxWxH)

LED:

• Green—Link, Red—Error,

two WAN ports for traffic

Certifications:

• FCC, UL, VCCI, CSA, C-tick, TUV, CE

TRENDnet is a registered treademark of TRENDware International, Inc. Other Brands and product names are trademarks of their respective holders. Information provided in this

document pertain to TRENDware products and is subject to change at any time, without notice. For the most recent product information please visit

____________________

http://www.TRENDNET.com.

TRENDware International, Inc.

3135 Kashiwa Street

Torrance, CA. 90505. USA

Tel: 310-891-1100

Fax: 310-891-1111

Web:

Email: [email protected]

www.TRENDNET.com

ORDERING INFORMATION

TRENDnet

TRENDware, USA
