TRENDnet TE-PCIWplus User manual
TRENDnet's PCI Plug-and-Play (PnP) 32-bit Ethernet
adapters feature the latest PCI bus technology to process
network packets with minimal CPU utilization. The adapters
are recommended for workstations in a PC client/server
environment. Taking advan-tage of 32-bit bus width and
speed up to 33MHz, they are superior to all ISA adapters.
Equipped with both BNC and RJ-45 connec-tors they include
drivers for every popular network operating system. The PnP
and full-duplex functions increase the channel bandwidth
from 10Mbps to 20Mbps and avoid the performance-
degrading problem. TRENDnet adapters provide software
configuration of the jumperless Ethernet through a setup
program.
TE-PCIWplus
32-bit PCI Plug-and-Play Ethernet Adapter with BNC + RJ-45 Connectors
Comply with IEEE 802.3 10Base-2 and 10Base-T
industry standard
32-bit PCI local bus specification 2.0 compliant
Plug-and-Play (self-configuring), plugs into any
486/Pentium PCI bus slot
Supports PCI bus slave mode for low maintenance
cost
Compatible with all popular network operating
systems
Supports both 10Mbps (half-duplex) and 20Mbps
(full-duplex) operations
Easy-to-view LED indicators
5 Year Warranty
BENEFITSFEATURES
Easy Configuration:
Flexibility:
Performance:
Cost-Effectiveness:
Plug-and-Play function simply lets you
plug the adapter to connect to the
network.
With the full-duplex mode, PCs connect
to switch receiving and transmitting data
at the same time on a dedicated 20Mbps
bandwidth.
Provide the 32-bit high throughput data
transfer with the host - powerful
performance in very heavy traffic
environments.
With its low cost of ownership and
standard compliance, TRENDnet ISA
PnP adapters are the perfect choice for
cost-effective workgroup networking.
TE-PCIWplus (11-17-2002)
TRENDnet
TRENDware, USA
What's Next in Networking
PRODUCT INFORMATION
To Order Please Call:
1-888-326-6061
TE100-PCIWS: 32-bit PCI 10/100Mbps NWay Fast Ethernet Card
TE100-PCIWN: 32-bit PCI 10/100Mbps N-way Fast Ethernet Card
TE100-PCIWA: 32-bit PCI 10/100Mbps N-way Fast Ethernet Card
with ACPI Wake-on-LAN
TE-16PCTplus: 16-bit ISA PnP Ethernet Card with BNC + RJ-45
Connectors
TE-16PTplus: 16-bit ISA PnP Ethernet Card with RJ-45 Connector
TE-PCIWplus: 32-bit PCI PnP Ethernet Card with BNC + RJ-45
Connectors
TE-PCIWTplus: 32-bit PCI PnP Ethernet Card with RJ-45
Connector
NETWORKING SOLUTIONS
SPECIFICATIONS
TE-PCIWplus
32-bit PCI Plug-and-Play Ethernet Adapter with BNC + RJ-45 Connectors
TE-PCIWplus
32-bit PCI Plug-and-Play Ethernet Adapter with BNC + RJ-45 Connectors
Standards:
IEEE 802.3 10Base-2 and 10Base-T
On-board Connector:
RJ-45 and BNC
Data Bus Supported:
32-bit, PCI Local Bus Specification 2.0
IRQ’s Supported:
Assigned by the BIOS to a free IRQ (interrupt)
number
I/O Base Address:
Assigned by the BIOS to a free I/O address block
Network Drivers:
Novell IPX, ODI, NDIS, SCO Unix, NetWare 3.x,
4.x server, Windows 95/98/NT 3.x, 4.x/2000/XP,
Windows for Workgroups, LAN Manager,
LAN Server, Banyan VINES, PathWork,
Packet Driver, LANtastic, NetBIOS,
and many others
•
•
•
•
•
•
RAM Buffer:
16Kb
Boot ROM Size:
8Kb, 16Kb, and 32Kb
Dimensions:
5.20" x 3.27"
FCC Compliance:
FCC Class B
Power Consumption:
430mA at 5V
Operating Temperature:
0° to 55°C
Operating Humidity:
10 to 90%, non-condensing
•
•
•
•
•
•
•
TRENDnet is a registered treademark of TRENDware International, Inc. Other Brands and product names are trademarks of their respective holders. Information provided in this
document pertain to TRENDware products and is subject to change at any time, without notice. For the most recent product information please visit
____________________
http://www.TRENDNET.com.
©
Copyright TRENDware International, Inc. 2004. All Rights Reserved.
TRENDware International, Inc.
3135 Kashiwa Street
Torrance, CA. 90505. USA
Tel: 310-891-1100
Fax: 310-891-1111
Web:
Email: [email protected]
www.TRENDNET.com
ORDERING INFORMATION
