Transcend CompactFlash TS16GCF100I-P User manual

(

)

Transcend Information Inc.

V1.1

Description

The Transcend CF100I is a High Speed industrial

Compact Flash Card with high quality Flash Memory

assembled on a printed circuit board.

Placement

Dimensions

Features

•CompactFlash Specification Version 4.1 Complaint

•RoHS compliant products

•Single Power Supply: 3.3V

5% or 5V

10%

•Operating Temperature: -40

C to 85

•Storage Temperature: -55

C to 100

•Operation Modes:



PC Card Memory Mode



PC Card IO Mode



True IDE Mode

•True IDE Mode supports:



Ultra DMA Mode 0 to Ultra DMA Mode 4



Multi-Word DMA Mode 0 to Multi-Word DMA Mode 4



PIO Mode 0 to PIO Mode 6



(Series of –P Only support PIO Mode 0 to PIO Mode

4, please see Order Information)

•True IDE Mode: Fixed Disk (Standard)

•PC Card Mode: Fixed Disk (Standard)

•Durability of Connector: 10,000 times

•Endurance: 2,000,000 Program/Erase cycles

•MTBF: 1,000,000 hours

•

Support Wear-Leveling to extend product life

•

Support S.M.A.R.T (Self-defined)

•

Support Security Command

•Compliant to CompactFlash, PCMCIA, and ATA

standards

•Mechanical Shock Test: 1500G

•Vibration Test: 20G (Peak-to-Peak)

20Hz to 2000Hz (Frequency)

(

)

Transcend Information Inc.

V1.1

Order information

Part Number Interface Transfer Mode

True IDE mode

Ultra DMA mode 0~4

Multi-Word DMA Mode 0~4

PIO Mode 0 ~ 6

Fixed Disk (Standard)

TS128M~16GCF100I

PC Card mode (PCMCIA)

80ns, 100ns, 120ns, 250ns Fixed Disk (Standard)

True IDE mode PIO Mode 0 ~ 4 Fixed Disk (Standard)

TS128M~16GCF100I-P

PC Card mode (PCMCIA)

250ns Fixed Disk (Standard)

C.H.S. Table

Capacity C H S

128MB 246 16 63

256MB 493 16 63

512MB 987 16 63

1GB 1974 16 63

2GB 3949 16 63

4GB 7899 16 63

8GB 15798 16 63

16GB 33149 15 63

(

)

Transcend Information Inc.

V1.1

Transcend

(

)

Transcend Information Inc.

V1.1

Block Diagram

(

)

Transcend Information Inc.

V1.1

Pin Assignments and Pin Type

(

)

Transcend Information Inc.

V1.1

Note: 1) These signals are required only for 16 bit accesses and not required when installed in 8 bit

systems. Devices should allow for 3-state signals not to consume current.

2) The signal should be grounded by the host.

3) The signal should be tied to VCC by the host.

4) The mode is required for CompactFlash Storage Cards.

5) The -CSEL signal is ignored by the card in PC Card modes. However, because it is not

pulled upon the card in these modes, it should not be left floating by the host in PC Card

modes. In these modes, the pin should be connected by the host to PC Card A25 or

grounded by the host.

6) If DMA operations are not used, the signal should be held high or tied to VCC by the host. For

proper operation in older hosts: while DMA operations are not active, the card shall ignore

this signal,including a floating condition

7) Signal usage in True IDE Mode except when Ultra DMA mode protocol is active.

8) Signal usage in True IDE Mode when Ultra DMA mode protocol DMA Write is active.

9) Signal usage in True IDE Mode when Ultra DMA mode protocol DMA Read is active.

10) Signal usage in PC Card I/O and Memory Mode when Ultra DMA mode protocol DMA Write is active.

11) Signal usage in PC Card I/O and Memory Mode when Ultra DMA mode protocol DMA Read is active.

12) Signal usage in PC Card I/O and Memory Mode when Ultra DMA protocol is active.

(

)

Transcend Information Inc.

V1.1

Signal Description

Signal Name

Dir.

Description

A10 – A00

(PC Card Memory Mode)

A10 – A00

(PC Card I/O Mode)

A02 - A00

(True IDE Mode)

8,10,11,12,

14,15,16,17,

18,19,20

These address lines along with the -REG signal are used to

select the following:

The I/O port address registers within the CompactFlash Storage Card , the

memory mapped

port address registers within the CompactFlash Storage Card,

a byte in the card's information structure and its

configuration control and status

registers.

This signal is the same as the PC Card Memory Mode signal.

In True IDE Mode, only A[02:00] are used to select the one of eight registers

in the Task File, the remaining address lines should be grounded by the

host.

BVD1

(PC Card Memory Mode)

-STSCHG

(PC Card I/O Mode)

Status Changed

-PDIAG

(True IDE Mode)

I/O

46 This signal is asserted high, as BVD1 is not supported.

This signal is asserted low to alert the host to changes in the

READY and Write

Protect states, while the I/O interface is configured. Its use is controlled by the

Card Config and Status Register.

In the True IDE Mode, this input / output is the Pass Diagnostic signal in the

Master / Slave handshake protocol.

BVD2

(PC Card Memory Mode)

-SPKR

(PC Card I/O Mode)

-DASP

(True IDE Mode)

I/O

45 This signal is asserted high, as BVD2 is not supported.

This line is the Binary Audio output from the card. If the Card does not support

the Binary Audio function, this line should be held negated.

In the True IDE Mode, this input/output is the Disk Active/Slave

Present signal in

the Master/Slave handshake protocol.

-CD1, -CD2

(PC Card Memory Mode)

-CD1, -CD2

(PC Card I/O Mode)

-CD1, -CD2

(True IDE Mode)

26,25 These Card Detect pins are connected to ground on the

CompactFlash Storage

Card. They are used by the host to determine that the CompactFlash Storage

Card is fully inserted into its socket.

This signal is the same for all modes.

(

)

Transcend Information Inc.

V1.1

Signal Name

Dir.

Description

-CE1, -CE2

(PC Card Memory Mode)

Card Enable

-CE1, -CE2

(PC Card I/O Mode)

Card Enable

-CS0, -CS1

(True IDE Mode)

7,32 These input signals are used both to select the card and to indicate to the card

whether a byte or a word operation is being performed. -CE2 always accesses

the odd byte of the word.-CE1 accesses the even byte or the Odd byte of the

word depending on A0 and -CE2. A multiplexing scheme based on A0,-CE1,

-CE2 allows 8 bit hosts to access all data on D0-D7. See Table 27, Table 29,

Table 31, Table 35, Table 36 and Table 37.

This signal is the same as the PC Card Memory Mode signal.

In the True IDE Mode, -CS0 is the address range select for the task file

registers while -CS1 is used to select the Alternate Status Register and the

Device Control Register.

While –DMACK is asserted, -CS0 and –CS1 shall be held negated and the

width of the transfers shall be 16 bits.

-CSEL

(PC Card Memory Mode)

-CSEL

(PC Card I/O Mode)

-CSEL

(True IDE Mode)

39 This signal is not used for this mode, but should be connected by

the host to PC

Card A25 or grounded by the host.

This signal is not used for this mode, but should be connected by

the host to PC

Card A25 or grounded by the host.

This internally pulled up signal is used to configure this device as

a Master or a

Slave when configured in the True IDE Mode.

When this pin is grounded, this device is configured as a Master.

When the pin is open, this device is configured as a Slave.

D15 - D00

(PC Card Memory Mode)

D15 - D00

(PC Card I/O Mode)

D15 - D00

(True IDE Mode)

I/O

31,30,29,28,

27,49,48,47,

6,5,4,3,2,

23, 22, 21

These lines carry the Data, Commands and Status information

between the host

and the controller. D00 is the LSB of the Even

Byte of the Word. D08 is the LSB

of the Odd Byte of the Word.

This signal is the same as the PC Card Memory Mode signal.

In True IDE Mode, all Task File operations occur in byte mode

on the low order

bus D[7:0] while all data transfers are 16 bit using D[15:0].

GND

(PC Card Memory Mode)

GND

(PC Card I/O Mode)

GND

(True IDE Mode)

1,50 Ground.

This signal is the same for all modes.

(

)

Transcend Information Inc.

V1.1

Signal Name

Dir.

Description

-INPACK

(PC Card Memory Mode)

-INPACK

(PC Card I/O Mode)

Input Acknowledge

DMARQ

(True IDE Mode)

43 This signal is not used in this mode.

The Input Acknowledge signal is asserted by the CompactFlash Storage Card

when the card is selected and responding to an I/O read cycle at the address

that is on the address bus. This signal is used by the host to control the enable

any input data buffers between the CompactFlash Storage Card and the CPU.

This signal is a DMA Request that is used for DMA data

transfers between host

and device. It shall be asserted by the

device when it is ready to transfer data to

or from the host. For Multiword DMA transfers, the direction of data transfer is

controlled by -IORD and -IOWR. This signal is used in a

handshake manner with

-DMACK, i.e., the device shall wait until the host asserts -DMACK before

negating DMARQ, and reasserting DMARQ if there is more data to transfer.

DMARQ shall not be driven when the device is not selected.

While a DMA operation is in progress, -CS0 and –CS1 shall be

held negated and

the width of the transfers shall be 16 bits.

If there is no hardware support for DMA mode in the host, this

output signal is not

used and should not be connected at the

host. In this case, the BIOS must report

that DMA mode is not supported by the host so that device drivers will not

attempt DMA mode.

A host that does not support DMA mode and implements both PCMCIA and

True-IDE modes of operation need not alter the PCMCIA mode connections

while in True-IDE mode as long as this does not prevent proper operation

in any

mode.

-IORD

(PC Card Memory Mode)

-IORD

(PC Card I/O Mode)

-IORD

(True IDE Mode – Except

Ultra DMA Protocol Active)

-HDMARDY

(True IDE Mode – In Ultra

DMA Protocol DMA Read)

HSTROBE

(True IDE Mode – In Ultra

DMA Protocol DMA Write)

34 This signal is not used in this mode.

This is an I/O Read strobe generated by the host. This signal

gates I/O data onto

the bus from the CompactFlash Storage

Card when the card is configured to use

the I/O interface.

In True IDE Mode, while Ultra DMA mode is not active, this

signal has the same

function as in PC Card I/O Mode.

In True IDE Mode when Ultra DMA mode DMA Read is active, this signal is

asserted by the host to indicate that the host is read to receive Ultra DMA data-

bursts. The host may negate -HDMARDY to pause an Ultra DMA transfer.

In True IDE Mode when Ultra DMA mode DMA Write is active,

this signal is the

data out strobe generated by the host. Both the rising and falling edge of

HSTROBE cause data to be latched by the device. The host may stop

generating HSTROBE edges to pause an Ultra DMA data-out burst.

(

)

Transcend Information Inc.

V1.1

Signal Name

Dir.

Description

-IOWR

(PC Card Memory Mode)

-IOWR

(PC Card I/O Mode)

-IOWR

(True IDE Mode – Except

Ultra DMA Protocol Active)

STOP

(True IDE Mode – Ultra DMA

Protocol Active)

35 This signal is not used in this mode.

The I/O Write strobe pulse is used to clock I/O data on the Card Data bus into

the CompactFlash Storage Card controller registers when the CompactFlash

Storage Card is configured to use the I/O interface.

The clocking shall occur on the negative to positive edge of the signal (trailing

edge).

In True IDE Mode, while Ultra DMA mode protocol is not active, this signal has

the same function as in PC Card I/O Mode. When Ultra DMA mode protocol is

supported, this signal must be negated before entering Ultra DMA mode

protocol.

In True IDE Mode, while Ultra DMA mode protocol is active, the

assertion of this

signal causes the termination of the Ultra DMA burst.

-OE

(PC Card Memory Mode)

-OE

(PC Card I/O Mode)

-ATA SEL

(True IDE Mode)

9 This is an Output Enable strobe generated by the host interface. It is used to

read data from the CompactFlash Storage Card in Memory Mode and to read

the CIS and configuration registers.

In PC Card I/O Mode, this signal is used to read the CIS and configuration

registers.

To enable True IDE Mode this input should be grounded by the host.

READY

(PC Card Memory Mode)

-IREQ

(PC Card I/O Mode)

INTRQ

(True IDE Mode)

37 In Memory Mode, this signal is set high when the CompactFlash Storage Card

ready to accept a new data transfer operation and is held low when the card is

busy.

At power up and at Reset, the READY signal is held low (busy) until the

CompactFlash Storage Card has completed its power up or reset function. No

access of any type should be made to the CompactFlash Storage Card during

this time.

Note, however, that when a card is powered up and used with RESET

continuously disconnected or asserted, the Reset function of the RESET pin is

disabled. Consequently, the

continuous assertion of RESET from the application

of power shall not cause the READY signal to remain continuously in the busy

state.

I/O Operation – After the CompactFlash Storage Card Card has been

configured for I/O operation, this signal is used as -

Interrupt Request. This line is

strobed low to generate a pulse mode interrupt or held low for a level mode

interrupt.

In True IDE Mode signal is the active high Interrupt Request to the host.

This manual suits for next models

Table of contents

Other Transcend Storage manuals

Transcend

Transcend USB JetFlash User manual

Transcend

Transcend JETFLASHTM TS32M-2GJF2B User manual

Transcend

Transcend StoreJet 25M3 User manual

Transcend

Transcend TS128GSSD18M-M User manual

Transcend

Transcend StoreJet SJM100 User manual

Transcend

Transcend StoreJet 18 mobile User manual

Transcend

Transcend USB JetFlash User manual

Transcend

Transcend TS250GSJ25P User manual

Transcend

Transcend 32MB4GB User manual

Transcend

Transcend TS4G-32GSDHC6-P2 User manual

Transcend

Transcend ExpressCard SSD34E User manual

Transcend

Transcend CompactFlash CF 300X User manual

Transcend

Transcend StoreJet TS500GSJ25M-R User manual

Transcend

Transcend CompactFlash TS1G-32GCF133 User manual

Transcend

Transcend TS1-GSDOM22V Manual

Transcend

Transcend 1.8" StoreJet Portable HDD 20GB (TOSHIBA)... User manual

Transcend

Transcend TS16GCF600 User manual

Transcend

Transcend TS250GSJ25M-R User manual

Transcend

Transcend T.sonic Photo TS512MMP810EU User manual

Transcend

Transcend StoreJet 2.5 IDE Series User manual

Transcend

Transcend JetFlash 820 User manual

Transcend

Transcend StoreJet 18 mobile User manual

Transcend

Transcend Mobile Memory Card TS1GRMMC4 User manual

Transcend

Transcend StoreJet 2.5 SATA Series User manual

Popular Storage manuals by other brands

QNAP

QNAP TS 32PXU Series user guide

LaCie

LaCie RUGGED RAID user manual

Freecom

Freecom CLS DOCK Quick install guide

PNY

PNY Attache P-FD64MBATT3 install guide

HP StorageWorks MSL2024 Getting started

OLT

OLT 6x6 Maximizer Assembly manual

LaCie

LaCie RUGGED MINI user manual

Thunderbolt

Thunderbolt 600 user manual

Panasonic

Panasonic LB-DH8 series Operator's guide

Intel

Intel RAID High Availability user guide

LaCie

LaCie 12big Thunderbolt 3 Quick install guide

Spectra Logic

Spectra Logic T-Series Spectra T50e quick start guide

Panasonic

Panasonic LKM-F931-1 instruction manual

Tabernus

Tabernus Enterprise Erase E2400 user guide

Rocstor

Rocstor COMMANDER 3F series user manual

HP P9000 user guide

Western Digital

Western Digital Ultrastar Data60 installation guide

Dell

Dell PowerVault MD3600f Series Getting started
