TP-Link TL-WN722N User manual

Option 1: Directly Option 2: Via the USB Extension Cable

Connect to a Computer

12Install Driver and Utility 3Join a Wireless Network

Option 1: Via TP-LINK Utility

b. Browse the CD, go to TL-WN722N > Mac OS

X Driver, unzip the Mac OS X 10.6_10.11.zip

ﬁle and run the Installer.

c. Follow the wizard to complete the installation.

uninstall.commandInstaller.pkg

SHELL

a. Insert the CD.

For Mac OS X

150Mbps High Gain Wireless USB Adapter

MODEL NO. TL-WN722N

7106506469 REV8.0.0

Quick

Installation

Guide

This USB Adapter can be powered only by computers that comply with Limited

Power Source (LPS).

Note: You can also download the driver at www.tp-link.com.

a. Click (TP-LINK Wireless Configuration

Utility) on the menu bar.

b. Select your Wi-Fi network and enter the Wi-Fi

password when prompted.

Fri 5:14 PM

34567_TEST

abcdef_0903

AAAAAA

TP-LINK_A

Join Other Network

WPS

Open Wireless Utility

USB-WiFi: On

Turn USB-WiFi Off

Option 2: ViaWi-Fi Protected Setup (WPS)

a. Press the WPS button on your router.

b. Within 2 minutes, press and hold the WPS button on

the adapter until the WPS Progress screen appears.

When you are prompted“WPS Protocol Finished!”,

click OK.

150Mbps

TL-WN722N

Connect to a Computer

Note: In Windows XP, a Found New HardwareWizard window will appear when the adapter is detected. Please click Cancel.

Option 1: Directly Option 2: Via the USB Extension Cable

1 2 Install Driver and Utility

a. Insert the CD and run the Autorun.exe from

the pop-up Autoplay window.

b. Select TL-WN722N and click Install Driver,

then follow the InstallShield Wizard to

complete the installation.

Setup Wizard

Browse CD EXIT

TL-WN722N

Install Driver

User Guide

3Join a Wireless Network

Click or ( Network icon) on the task bar,

select your Wi-Fi network, and click Connect.

Note: In Windows XP, you need to close the TP-LINK Utility

before using the WindowsWireless Utility.

Option 1: Via Windows Wireless Utility

For Windows

Option 3: ViaWi-Fi Protected Setup (WPS)

a. Press the WPS button on your router.

b. Within 2 minutes, press and hold the WPS button on

the adapter until the conﬁguring screen appears.

Notes:

1. You can also download the driver at www.tp-link.com.

2. In some operating systems, the CD screen will pop up

automatically. Otherwise, run the CD manually.

Note: During the installation, select TP-LINK Wireless

Conguration Utility and Driver if you want to use

TP-LINK Utility and WPS function.

Option 2: Via TP-LINK Utility

Select your Wi-Fi network from the utility window

and click

Connect

. The symbol indicates a

successful connection.

Network Name(SSID)

Channel

Signal

Security

2 (2.4G)

5 (2.4G)

149 (5G)

None

WPA/WPA2-Personal

None

34567_TEST

abcdef_0903

AAAAAA

6 (2.4G)

TP-LINK_A

Connect automatically

WPA/WPA2-Personal

Status WPS Profile AdvancedNetwork

Connect

34567_TEST

Network Na

TP-LINK_A

When you are prompted“Successfully connected to

the network by WPS!”, click OK.

For more information, please visit our website

http://www.tp-link.com

150Mbps

TL-WN722N

Networks

Connect automatically Connect

√

Wi-Fi

TP-LINK_A

abcdef_0903

34567_TEST
