Totally Wicked Switz2 User manual

Congratulations on purchasing your

Totally Wicked Switz2 Electronic Cigarette Kit

The Totally Wicked Switz2

Using your Switz2

Priming the Atomizer Head:

Turn the Switz2 kit upside down so the

mouthpiece points downwards. Unscrew and

remove the battery from the tank. Grip the

atomizer head by its connector and remove it

from the tank by pulling. Prime the atomizer

head by dripping a few drops of E-liquid into

the central hole of the atomizer head. After

priming the atomizer head, insert it back into

the tank and screw the battery back on.

Filling the Tank:

Unscrew the top cap from the tank. Fill the

tank to the top of the e-liquid viewing window,

avoiding ﬁlling down the central airﬂow

hole. Once ﬁlled, screw the top cap back on.

Powering On And Off:

To turn the Switz2 on, press the power button

ﬁve times in quick succession, the indicator

light will ﬂash purple three times to show the

Switz2 has been switched on. Similarly, if the

Switz2 is already turned on, press the power

button ﬁve times in quick succession to turn

the Switz2 off, the indicator light will ﬂash

purple three times.

Vaping:

Press and hold the power button as you inhale

the vapour, the indicator light will illuminate

while the power button is held down to vape.

E-liquid Viewing Windows:

The Switz2 tank has three E-liquid viewing

windows, these enable you to see at a glance

how much e-liquid is left in the tank. Ensure

the E-liquid level does not go lower than the

bottom of the viewing window to prevent

the atomizer head from becoming dry and

burning prematurely.

Charging The Battery:

The Switz2 is recharged by inserting the

charge lead into the charge port located to

the right of the power button. The indicator

light will ﬂash three times when the charge

lead is ﬁrst connected, the indicator light will

illuminate red and remain on while charging.

Once fully charged, the indicator light will turn

off completely.

Installing/Replacing an Atomizer Head:

To install a new atomizer head follow the

process shown in the “Priming the atomizer

head” instructions above.

Reminder: After priming a new atomizer

head and ﬁlling the tank with e-liquid, it is

recommended to wait 5 minutes to ensure

the atomizer head is fully saturated with

e-liquid.

Battery Life Indication:

As the level of battery charge changes, the

indicator light will change colour to represent

the amount of remaining battery life.

Mouthpiece

Tank

E-liquid Viewing Window

Power

Button USB Charging Port

Battery Atomizer

Head

Note: After priming a new atomizer head

and ﬁlling the tank, it is recommended to

wait 5 minutes to ensure the atomizer head

is fully saturated.

(1) (2)

When battery charge remaining is above 30%

the indicator light will glow blue when the

power button is pressed.

When battery charge is between 6% and 30%

the indicator light will glow purple when the

power button is pressed.

If battery charge drops below 6% the indicator

light will glow red when the power button is

pressed.

When the battery is completely exhausted

the indicator light will ﬂash red 8 times and

the device will go into sleep mode until it is

recharged.

Short Circuit Protection:

If an atomizer short circuit occurs the indicator

light will glow red and ﬂash ﬁve times in

succession whenever the power button is

pressed. If an atomizer short circuit error

occurs, replacing the atomizer head should

allow normal operation to resume.

Atomizer Head Protection:

If the power button is held down for longer

than ten seconds while vaping, the indicator

light will ﬂash eight times and the Switz2 will

stop producing vapour.

1 x Switz2 Battery

1 x Switz2 Tank

1 x 1.5ohm SW2 Atomizer Head (ﬁtted)

1 x 1.5ohm SW2 Atomizer Head (spare)

1 x USB Charge Lead

1 x User Manual

Kit Contents

Specications

Dimensions: 16.5mm (diameter) 120.5 mm

(length)

Battery: 800mAh Integrated Battery

Max Charging Current: 850mA

Tank Capacity: 1.8ml

Atomizer Type: SW2 Atomizer Heads

Maximum Filling Nozzle Diameter: 4mm

Additional product information

There are no reported medical side effects

with this product. If you believe you

experience a side effect, please contact the

manufacturer.

Product Storage and Battery

Precautions

• Store the Switz2 and its accessories away

from children when not in use.

• Ensure the Switz2 is powered off when not

in use.

• Avoid accidentally pressing the Switz2

power button when not in use.

• Please only use the charging cable

provided.

• Please dispose of dead batteries in

accordance with your country’s appropriate

legislation.

• Do not charge the batteries in a damp

environment.

• Do not use the device when temperatures

are outside the range of -10°C - 60°C.

• Do not charge the battery when

temperatures are outside the range of

0°C – 45°C.

• Do not attempt to repair a faulty Switz2 as

these are sealed units with no serviceable

parts. Attempted repairs will void the

warranty.

Warranty

The Switz2 components have a 28 day parts

warranty, with the exception of Atomizer

Heads, which are consumable items and

covered by a “dead on arrival” warranty only.

The USB cable supplied has a 12-month

warranty. If any parts are found to be faulty

within this time please contact our customer

service team, whose details are on the back

page of this booklet and we will arrange for a

replacement. We may require the goods to be

returned for further investigation.

Manufactured in China under the authority of

Pillbox38 UK Ltd, Stancliffe Street, Blackburn,

Lancashire, BB2 2QR.

Tel 01254 692244

www.totallywicked.co.uk

Tel 1(888) 761-9425

www.totallywicked.com

Tel 0941-78447082

www.totallywicked.de

(3) (4)
