Totally Wicked Corsa 200 User manual
USER MANUAL / BEDIENUNGSANLEITUNG
ELECTRONIC CIGARETTE BATTERY
TW_Corsa_200_Manual.indd 1 19/12/2016 13:20
2
Congratulations on purchasing your
Totally Wicked Corsa 200 Electronic Cigarette
The Totally Wicked Corsa 200 is the most recent addition to the Corsa range,
utilising three 18650 batteries to provide an outstanding 200 watts of power. The
Corsa incorporates an intelligent temperature control system with pre-heating
functionality, allowing you to finely tune your device to suit your vaping style.
Upgradeable firmware means you will always be up to date. The user is provided
with five modes of operation; variable power (W); variable temperature with nickel
coils (Ni); variable temperature with titanium coils (Ti); variable temperature with
stainless steel coils (SS316); and temperature coefficient of resistance (TCR). The
Corsa 200 combines all of its functionality and triple 18650 batteries in a stylish and
ergonomic package, sure to be popular with electronic cigarette users who require
a considerable power output.
TW_Corsa_200_Manual.indd 2 19/12/2016 13:20
3
Battery Cover
Power Button 510 Thread
and Sprung Connector
OLED Screen
Adjustment Button
TW_Corsa_200_Manual.indd 3 19/12/2016 13:20
4
Using your Corsa 200
Fitting Batteries:
The Corsa 200 is powered by 3 x
18650 Li-batteries. To fit the batteries
simply slide the battery cover from
the bottom of the device and insert
3 x 18650 batteries, ensuring the
correct polarity. To replace the battery
cover push it firmly into position,
ensuring that it is closed securely.
Note: Please do not mix together
non-matching cell brands or types,
or batteries that are not of a matched
set.
Power On and Off:
The Corsa 200 uses a 5-click on/
off function. To switch the device
on quickly press the power button
5 times. The OLED screen will
illuminate, signifying that the device
is powered on. Once the Corsa 200
is powered on the user can press
the button 5 times to switch the
device off.
Vaping:
Simply press the power button as
you inhale.
TW_Corsa_200_Manual.indd 4 19/12/2016 13:20
5
New Atomizer Installation:
When a new atomizer is connected
or the existing atomizer is
disconnected and reconnected, a
message prompt will be displayed
– ‘New Coil Right, Same Coil Left’.
Press the right adjustment button to
confirm that a new atomizer has been
connected, or the left adjustment
button to confirm that the existing
atomizer has been reconnected.
Selection of a new coil should only
be made when the atomizer and coil
are at room temperature.
Charging the Batteries:
Simply charge the Corsa 200 via
the USB cable when connected to
a powered USB port or suitable wall
adapter. The indicator on the display
will indicate the battery status.
Alternatively, charge the batteries
using a suitable external battery
charging unit.
Using your Corsa 200
TW_Corsa_200_Manual.indd 5 19/12/2016 13:20
6
Battery Charge:
The individual battery charge for
each of the 3 18650 batteries is
displayed on the sixth row of the
OLED display.
Upgrading Firmware:
To upgrade the firmware installed on
the device simply load the relevant
product page on the Totally Wicked
website, click on the link under
‘Firmware Upgrade’ and follow the
instructions provided.
Shift between VW/TC/TCR Modes:
When powered on, press the power
button 3 times consecutively, the
first row will flash indicating that the
right adjustment button may be used
to cycle through the VW/TC/TCR
modes.
Using your Corsa 200
TW_Corsa_200_Manual.indd 6 19/12/2016 13:20
7
VW Mode:
When in VW mode, use the left or
right adjustment buttons to decrease
or increase the level of wattage
respectively. The available wattage
range is 1W – 200W in increments
of 0.1W.
Shift between TC (Ni/Ti/SS316)
Modes:
To shift between TC modes when in
TC mode, press the power button
3 times consecutively to activate
the menu, press the left adjustment
button once and then use the right
adjustment button to cycle through
the Ni/Ti/SS316 modes.
TC Mode (Ni/Ti/SS316):
When in TC mode, use the left
or right adjustment buttons to
decrease or increase the temperature
respectively. The available
temperature range is 100-315°C or
200-600°F and can be adjusted in
increments of 5°C and 10°F. To adjust
the wattage level whilst in TC mode,
press the power button 3 times
Using your Corsa 200
TW_Corsa_200_Manual.indd 7 19/12/2016 13:20
8
consecutively to activate the menu,
press the left adjustment button twice
and the wattage value will flash, use
the right adjustment button to adjust
the wattage level. To lock/unlock
the atomizer resistance, press the
fire button 3 times consecutively
to activate the menu, press the left
adjustment button three times and
the atomizer value will flash, use the
right adjustment button the lock/
unlock the atomizer resistance. Only
lock the atomizer when the coil is at
room temperature.
Note: If a coil with a resistance
exceeding 1.5ohms is applied in VT
mode, the device will automatically
switch to VW mode. Also, if a
standard kanthal or nichrome coil is
used under VT mode, the device will
automatically switch to VW mode.
TCR Mode:
When in TCR mode and the title is
flashing indicating that the menu
is active, press the left adjustment
button once and the sub-menu
(M1, M2, M3) will flash. Whilst the
sub-menu is flashing press the right
Using your Corsa 200
TW_Corsa_200_Manual.indd 8 19/12/2016 13:20
9
Using your Corsa 200
button to shift between M1, M2 and
M3, then press the fire button to
confirm. (Also see: Configuring TCR
Mode)
Configuring TCR Mode:
To set the temperature coefficient
of resistance to match a particular
coil, when the device is powered off
simultaneously hold the fire button
and the right adjustment button to
enter the TCR configuration menu.
Use the right or left adjustment
buttons to select which to configure
from M1, M2 and M3 – this feature
allows the TCR values for 3 materials
to be stored to the device. Press the
fire button to select the TCR value
and then use the adjustment buttons
to increase or decrease the value
to your preference, long press the
fire button or leave the device for 10
seconds to confirm the selection.
TW_Corsa_200_Manual.indd 9 19/12/2016 13:20
10
TCR Value Range:
Using your Corsa 200
Material TCR Value Range
Nickel 600-700
NiFe 300-400
Titanium 300-400
SS (303, 304, 316, 317) 80-200
Note: The TCR value displayed is the 105multiple of the actual TCR value and
is for Corsa 200 usage only.
