Toshiba AW-M731APH User manual

OWNER’S MANUAL

Fully Automatic

Washing Machine

Read This Manual

Read and

Keep the OWNER'S MANUAL handy for

future use .

follow the instructions carefully.

Thank you for purchasing TOSHIBA automatic

washing machine.

Model:

AW-M731APH

AW-M801APH

AW-M901BPH

CONTENTS

SAFETY INSTRUCTIONS

Safety instructions ...................................... .................................

INSTALLATION

Product description ............................................ .......................

Installation area ................................................. .. ... .....................

Unpacking the washing machine ..................... ....................

Levelling the washing machine ..............................................

Selection of tap .................................................... ... ......................

Connection of inlet hose, tap and washing machine......

Preparation before washing................................. ....................

Washing .......................................................... ....... .... ......................

After washing................................................. ...... .... ......................

Washing matters needing attention ................ .....................

The usage of detergent and washing powder.... ...............

Control pan ...........................................................el ......................

Option............................................................ ... .......... ......................

Personalized setting of washing ...... ... ......course .......... ......

Operations of washing process................ ...............................

Washing table .............................. ...........course .......................

Maintenance

Cleaning and care .............................................. ..........................

Cleaning the cabinet............................................ ... .... ................

Trouble hooting.................................................. ... ..s .................. ...

Technical ...................................... . .........specifications . ..............

Installation of the cabinet base cover................................... 9

OPERATION

Cleaning the inlet filter ................................... ............................ 19

Recommended detergent amount.............................

Energy efficiency test program . ...................................... . ......... 22

When using softener....................................................................

Cleaning drain pump filter................................ ... .................... ... 20

SAFETY INSTRUCTIONS

For your safety, the information in this manual must be

followed to minimize the risk of fire or explosion, electric

shock, or to prevent property damage, personal injury or

loss of life.

− Staff kitchen areas in shops, offices and other working

environments;

− Farm houses;

− By clients in hotels, motels and other residential type

environments;

− Bed and breakfast type environments;

− Areas for communal use in blocks of flats or in launderettes.

• This appliance is not intended for use by persons

(including children) with reduced physical, sensory

or mental capabilities or lack of experience and

knowledge unless they have been given supervision

or instruction concerning use of the appliance by a

person responsible for their safety.

• Children should be supervised to ensure that they do

not play with the appliance.

• If the supply cord is damaged, it must be replaced by

the manufacturer, its service agent or similarly qualified

persons in order to avoid a hazard.

• The new hose-sets supplied with the appliance are to

be used and that old hose-sets should not be reused.

• The openings must not be obstructed by a carpet.

• This appliance is intended to be used in household only

and it is not intended to be used such as:

Important safety precautions

CAUTION: In order to avoid a hazard due to inadvertent

resetting of the thermal cut-out, this appliance must not

be supplied through an external switching device, such

as a timer, or connected to a circuit that is regularly

switched on and off by the utility.

SAFETY INSTRUCTIONS

Explanation of the symbols:

Note!

This combination of symbol and word

indicates a potentially dangerous situation which may

result in slight or minor injuries.

descriptive

Warning!

This combination of symbol and word

indicates a potentially dangerous situation which may

result in death or serious injuries unless it is avoided.

descriptive

Caution!

This combination of symbol and word

indicates a potentially dangerous situation which may

result in slight or minor injuries or damage to property

and the environment.

descriptive

Model Washing Capacity Standard Water Pressure

0.03MPa ~ 0.8MPa

AW-M731APH

6.3kg

AW-M801APH

7.0kg

AW-M901BPH

0.03MPa ~ 0.8MPa

8.0kg

SAFETY INSTRUCTIONS

The electric shock!

Warning!

• washing machine

• Do not put this washing machine in a humid place.

• Before doing any maintenance the unit, unplug the

appliance from the electrical source.

• Always unplug the machine and turn off the water supply

after use. Be aware of the maximum and minimum inlet

water pressure which is in megapascals (MPa)

• To ensure your safety, power plug must be inserted into

an earthed three-pole socket. Check carefully and make

sure that your socket is properly and reliably earthed.

• Make sure that the water and electrical devices provisions

are connected by a qualified technician in accordance with

the manufacturer's instructions and local safety regulations

•

This is for indoor use only.

If the supply cord is damaged, it must be replaced by

the manufacturer, its service agent or similarly qualified

persons in order to avoid a hazard.

Risk of explosion!

•

washed in, soaked in, or dabbed with combustible or

explosive substances( such as wax, oil, paint, gasoline,

degreasers , dry-cleaning solvents, kerosene, etc.)

This may result in fire or explosion.

Do not wash or dry articles that have been cleaned in,

SAFETY INSTRUCTIONS

• Animals and children can not climb into the machine.

Check the machine before every operation.

• Children should be supervised that they do not play with

the appliance.

• Keep children and animals far away from the machine

during operation.

•

This appliance is not intended for use by persons

(including children) with reduced physical, sensory

or mental capabilities or lack of experience and

knowledge unless they have been given supervision

or instruction concerning use of the appliance by a

person responsible for their safety.

• Children should be supervised to ensure that they do

not play with the appliance.

• The appliance can not be used by children

with reduced physical sensory or mental capabilities or

lack of experience and knowledge if they have been

given supervision or instruction concerning use of the

appliance in a safe way and understand the hazards

involved.

Cleaning and user maintenance shall not be done by

children without supervision.

and persons

Risk to children!

• This washing machine is for indoor use only.

• It is not intended for built-in using.

• The openings must not be obstructed by a carpet.

• The washing machine shall not be installed in bath rooms

or very wet rooms as well as in the rooms with explosive

or caustic gases.

• Remove all packaging materials before using

Otherwise, serious damage may result.

the appliance.

• The washing machine with single inlet valve may only

connected to a cold water supply. be

• The plug must be accessible after installation.

• Avoid place where the machine is exposed to direct

sunlight .Plastic parts may become deformed or discolored .

Avoid place where the machine may become frozen

during cold weather.

•

Do not wash, spin, or dry water-proof seats, mats, or

clothing.

Do not wash thick, hard mats even if the washer mark

is on the care label.

This may result in injury or damage to the washer, walls,

floor, or clothing due to abnormal vibrations.

This appliance is intended to be used in household.

• The new hose-sets supplied with the appliance are to

be used and that old hose-sets should not be reused.

•

SAFETY INSTRUCTIONS

Installing the product!

Caution!

Operating the appliance!

• Before washing the clothes for the first time, the product

shall be operated without clothes using tub clean as the

displayed program on the control panel.

• Flammable and explosive or toxic solvents are forbidden.

Gasoline and alcohol etc. Shall not be used as detergents.

Please only select the detergents suitable for machine

washing, especially for top-loading fully automatic washing

machines.

• Make sure that all pockets are emptied. Sharp and rigid

items such as coins, brooches, nails, screws or ston s etc.

may cause serious damage to this machine.

• This appliance is intended to be used in household.

• Hands should not be inserted into the rotating drum .

• This product is for domestic use only.

SAFETY INSTRUCTIONS

Risk of damaging appliance!

• Your product is only for home use and is only designed

for textiles suitable for machine washing.

• Do not climb up and sit on the glass lid of the machine.

• Cautions during Machine Handling and transport:

1.The accumulated water shall be drained out of the

machine.

2.Handle the machine carefully. Never hold protruding

parts of the machine while lifting.

3.This appliance is heavy, it should be transported carefully.

• Please do not close the glass lid with excessive force.

• It is forbidden to wash carpets.

INSTALLATION

Product description

• ll illustrations in this manual are for reference only.

lease refer to the product ,for actual appearance of the parts

P .

Note!

Accessories

Inlet hose assy Manual S

rew

Adjustable foot

Glass lid

Drum

Frame

Control panel

Cabinet

Water inlet valve

Power

and plug cord

Handle

Cabinet base cover

Drain hose

Refer to P12 and P18 for the s

pecific operation mode of

detergents and softeners

Softeners

Detergents

Unpaking the washing machine

*Keep clearance：50mm with the

drain hose beside the machine,

20mm without the drain hose.

This manual suits for next models

Table of contents

Other Toshiba Washer manuals

Toshiba

Toshiba AW-7480EM User manual

Toshiba

Toshiba AW-J750APH User manual

Toshiba

Toshiba TW-BL80A2 Series User manual

Toshiba

Toshiba AW-B1100GM User manual

Toshiba

Toshiba AW-1170SM User manual

Toshiba

Toshiba AW-J800APH1 User manual

Toshiba

Toshiba TW-BK105S2 Series User manual

Toshiba

Toshiba TWD-BM105GF4S User manual

Toshiba

Toshiba AW-SD150UBPE User manual

Toshiba

Toshiba aw-dc series User manual

Toshiba

Toshiba TW-BK95G4 Series User manual

Toshiba

Toshiba AW-8570SM User manual

Toshiba

Toshiba TW-BH85S2 User manual

Toshiba

Toshiba TW-BH95M4H User manual

Toshiba

Toshiba AW-M901BPH User manual

Toshiba

Toshiba TW-BL100M4RO User manual

Toshiba

Toshiba TW-BK95GF4 Series User manual

Toshiba

Toshiba TW-BL80S2 Series User manual

Toshiba

Toshiba AW-DC1000CM User manual

Toshiba

Toshiba AW-SD150SBA User manual

Toshiba

Toshiba TW-BK100S2 User manual

Toshiba

Toshiba AW-DUK1300K Series User manual

Toshiba

Toshiba AW-DUM1000JS User manual

Toshiba

Toshiba VH-H80WPH User manual

Popular Washer manuals by other brands

Tricity Bendix

Tricity Bendix AW 1000 W Operating & installation instructions

Panasonic

Panasonic NA-F60L5WRB operating instructions

GE WSLP1500 Dimensions and installation information

Electrolux

Electrolux EWF1284EDW Service manual

Bosch

Bosch WAN2829BSN User manual and installation instructions

LG TV2516DV3B owner's manual

LG TH2517DSAV owner's manual

VESTEL

VESTEL CMH-XL 7510 TE user manual

AEG

AEG 74335 User information

Johnson

Johnson JWF721A user manual

Beko

Beko WTE7604XLW0 owner's manual

Danby

Danby DTT100A1WDB Owner's use and care guide

Amica

Amica WA 14 Ex operating instructions

Daewoo

Daewoo DWD-F1222 instruction manual

Bosch

Bosch WAS28461AU instruction manual

Miele

Miele PW 6080 Vario manual

Finlux

Finlux FLX108CF220 user manual

Whirlpool

Whirlpool 3LBR5132AN0 Use and care guide
