Toshiba TW-BK100S2 User manual

Read This ManualRead all instructions and explanations for the installation before use. Follow the instructions carefully. Keep the operation instructions handy for later use. If the appliance is sold or passed on, ensure that the new owner always receives this operation instructions.OWNER’S MANUALFRONT LOADING

WASHER

MODEL:TW-BK100S2

CONTENTSSAFETY INSTRUCTIONS Safety Instructions ........................................................INSTALLATION Product Description ...................................................... Installation .....................................................................OPERATIONS Quick Start ...................................................................... Before Each Washing .................................................... Detergent Dispenser .................................................... Control Panel .................................................................. Programmes.................................................................... Option............................................................................. MAINTENANCES Cleaning and Care ........................................................ Trouble Shooting .......................................................... Technical Specifications ............................................. Product Fiche ................................................................. 2910141617192027293233341

Please read the following safety information thoroughly and follow it strictly to minimize the risk of fire or explosion, electric shock and to prevent property damage, personal injury or loss of life. Failing to follow these instructions shall void any warranty.

its service agent or similarly qualified persons in order to avoid a hazard.•If the machine is damaged, it must not be operated unless repaired by the manufacturer, its service agent or similarly qualified persons.Risk of electric shock!•If the supply cord is damaged, it must be replaced by the manufacturer, ELECTRIC SHOCK HAZARDSAFETY INSTRUCTIONSSafety Instructionsa potentially dangerous situation which may result in death or serious injuries unless it’s avoided.This combination of symbol and signal word indicates Warning!！a potentially dangerous situation which may result in slight or minor injuries.This combination of symbol and signal word indicates Note!a potentially dangerous situation which may result in slight or minor injuries or damage to property and the environment.This combination of symbol and signal word indicates Caution!Warning!！2

SAFETY INSTRUCTIONS•The appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision.•Children should be supervised that they do not play with the appliance.•Children 3 years and under shall be kept away from the appliance or continuously supervised.•Animals and children may climb into the machine. Check the machine before every operation. •Do not climb or sit on the appliance.INSTALLATION LOCATION AND SURROUNDING•All washing and additional substances are to be kept in a safe place out of the reach of children.•Do not install the machine on a carpet floor. The obstruction of the openings by a carpet can damage the machine.•Keep the appliance clear from heating sources and direct sunlight to avoid plastic and rubber parts to corrode.•Do not use the appliance in humid environments or rooms containing explosive or caustic gas. In case of water leakage or water splashes let the appliance dry in the open air.•The appliance must not be installed behind a lockable door, a sliding door or a door with a hinge on the opposite side to that of the washing machine.3

SAFETY INSTRUCTIONS•Do not operate the machine in rooms with a temperature of below 5°C. This can cause damages to parts of it. If it is unavoidable, make sure to drain the water completely from the appliance after every use (see „Maintenance - Cleaning of drain pump filter“) to avoid damages caused by frost.•Never use flammable sprays or substances in the immediate proximity of the appliance.INSTALLATION•Remove all packaging material and transport bolts before using the appliance. Otherwise, serious damage may result.•This appliance is equipped with a single inlet valve and can be connected to the cold water supply only. •Mains plug must be accessible after installation.•Before washing clothes for the first time, the product shall be operated once throughout all the procedures without any clothes inside.•Before using the washing machine, the product shall be calibrated.•Do not put any excessively heavy objects on the appliance, like water containers or heating devices.•The new hose-sets supplied with the appliance are to be used and that old hose-sets should not be reused.•Max. Inlet water pressure 1 MPa. Min. inlet water pressure 0.05 MPa.ELECTRICAL CONNECTION•Make sure the supply cable is not trapped by the machine, it can get damaged. •Connect the product to a grounded outlet protected by a fuse complying with the values in the “ Technical specifications“ table. The grounding installation has to be made by a qualified electrician. Ensure that the machine is installed in accordance with the local regulations.4

SAFETY INSTRUCTIONS•Water and electrical connections must be carried out by a qualified technician in accordance with the manufacturer‘s instructions and local safety regulations.•Don´t use multiple plugs or extension cords.•The appliance must not have an external switching device such as a timer or connected to a circuit that is regularly switched on and off.•Do not pull the plug out of the mains outlet if there is flammable gas around.•Never pull out power plug with wet hands. •Always pull at the plug, not at the cable.•Always unplug the appliance if it is not being used.Warning!！WATER CONNECTIONS•Check the connections of the water inlet tubes, the water tap and the outlet hose for possible problems due to changes of water pressure. If the connections loosen or leak close the water tap and get it repaired. Do not use the appliance before the pipes and hoses are installed properly by qualified persons.•Glass door may become very hot during the operation. Keep children and pets far away from the machine while it is operating.•The water inlet and outlet hoses have to be safely installed and remain undamaged. Otherwise, water leakage can occur.•Do not remove the drain pump filter while there is still water in the appliance. Big quantities of water can leak out, and there is a risk of scalding due to hot water.5

SAFETY INSTRUCTIONSOPERATION AND MAINTENANCE•Never use any flammable, explosive or toxic solvents. Do not use gasoline and alcohol etc. as detergents. Only select detergents that are suitable for machine washing.•Make sure that all pockets are emptied. Sharp and rigid items such as coins, brooches, nails, screws, stones etc. may cause serious damages to this machine.•Remove all objects from pockets such as lighters and matches before use the appliance.•Thoroughly rinse items that have been washed by hand.•Items that have been soiled with substances such as cooking oil, acetone, alcohol, petrol, kerosene, spot removers, turpentine, wax and wax removers should be washed in hot with an extra amount of detergent before being dried in the appliance.•Items containing foam rubber (latex foam), shower caps, water proof textiles, rubber backed articles and clothes or pillows fitted with foam rubber pads should not be dried in the machine•Fabric softeners or similar products should be used as recommended in their instructions. •Never try to open the door forcefully. The door will unlock shortly after the end of a cycle.•Please do not close the door with excessive force. If it is found difficult to close the door, please check if the clothes are properly inserted and distributed.6

SAFETY INSTRUCTIONS•Always unplug the appliance and close the water tap before cleaning and maintenance and after each use.•Never pour water over the appliance for cleaning purpose. Risk of electric shock!•Repairs shall only be carried out by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard. The producer will not be responsible for damages caused by the intervention of not authorized persons.TRANSPORT•Before Transport:-Bolts shall be reinstalled to the machine by a specialized person-Accumulated water shall be drained out of the machine•This appliance is heavy. Transport with care. Never hold any protruding part of the machine when lifting. The machine door cannot be used as a handle.INTENDED USEThe product is intended only for home use and for textiles in household amounts suitable for machine washing and drying. This appliance is for indoor use only and not intended for built in use. Only use according to these instructions. The appliance is not intended for commercial use.Any other use is considered as improper use. The producer is not responsible for any damage or injuries that may result of it.•Thisapplianceisintendedtobeusedinhouseholdand similarapplicationssuchas:-Staffkitchenareasinshops,officesandother working environments;-Farmhouses;-Byclientsinhotels,motelsandother residentialtypeenvironments;-Bedandbreakfasttypeenvironments;-Areasforcommunaluseinblocksofflatsorin launderettes.7

SAFETY INSTRUCTIONSThis marking indicates that this product should not be disposed with other household wastes throughout the EU.To prevent possible harm to the environment or

human health from uncontrolled waste disposal,recycle

it responsibly to promote the sustainable reuse of material resources.To return your used device, please use the collection systems or contact the retailer where the product was purchased. They return and can take this product for environmental safe recycling.

Packaging/Old appliance

AccessoriesProduct DescriptionTransport plughole Supply hosecold waterDrain hose (supportoptional)

• The product line chart is for reference only, please refer to real product as standard.

Note!Owner’s manualDrum Power supply cordControl panel

Detergent dispenser

Drain pump filterDoor

Water supply hose

Top cover Drain hoseScrew(optional)Rat resistance panel(optional)

Spanner assembly(optional)

INSTALLATION9
