SERVICE MANUAL

FILE NO.SVM-04015

AIR-CONDITIONER

SPLIT TYPE

RAS-M10UKV-E3, RAS-M13UKV-E3, RAS-M16UKV-E3

RAS-4M27YAV-E

RAS-M10UKCV-E3, RAS-M13UKCV-E3, RAS-M16UKCV-E3

RAS-4M27YACV-E

RAS-M10UKV-E3, RAS-M13UKV-E3, RAS-M16UKV-E3

RAS-3M26YAV-E

R410A

– 2 –

CONTENTS

1. SPECIFICATIONS....................................................................................... 3

2. REFRIGERANT R410A ............................................................................ 26

3. CONSTRUCTION VIEWS ......................................................................... 34

4. WIRING DIAGRAM ................................................................................... 36

5. SPECIFICATIONS OF ELECTRICAL PARTS .......................................... 38

6. REFRIGERANT CYCLE DIAGRAM ......................................................... 40

7. CONTROL BLOCK DIAGRAM ................................................................. 48

8. OPERATION DESCRIPTION .................................................................... 50

9. INSTALLATION PROCEDURE ................................................................. 64

10. HOW TO DIAGNOSE THE TROUBLE ....................................................... 79

11. HOW TO REPLACE THE MAIN PARTS ...................................................100

12. EXPLODED VIEWS AND PARTS LIST .................................................. 110

– 3 –

1. SPECIFICATIONS

1-1. Specifications

RAS-M10UKV-E3, RAS-M13UKV-E3, RAS-M16UKV-E3/RAS-4M27YAV-E, RAS-3M26YAV-E

• For performance when each indoor unit is combined with other unit, refer to the separate table.

• The specifications may be subject to change without notice for purpose of improvement.

Indoor RAS-M10UKV-E3, RAS-M13UKV-E3, RAS-M16UKV-E3

Unit model Outdoor RAS-4M27YAV-E RAS-3M26YAV-E

Cooling capacity

(

)

8.0 7.5

Cooling capacity range

(

)

1.4 –9.2 1.4 –8.9

Heating capacity

(

)

9.0 9.0

Heating capacity range

(

)

0.8 –11.0 0.8 –10.8

Power supply 220/230/240V, 1Ph, 50/60Hz

Unit model RAS-M10UKV-E3 RAS-M13UKV-E3 RAS-M16UKV-E3

Running current

(

)

0.15 0.15 0.15

Power consumption

(

)

30 30 30

Indoor

Power factor

(

)

91/87/83 91/87/83 91/87/83

Operation mode Cooling Heating Cooling Heating

Running current

(

)

11.60/11.09/10.63 10.44/9.98/9.57 10.44/9.98/9.57 11.83/11.31/10.84

Power consumption

(

)

2500 2250 2250 2550

Power factor

(

)

98 98 98 98

Electric

characteristics

Total

Starting current

(

)

11.60/11.09/10.63 11.83/11.31/10.84

C.O.P. (Cooling/Heating) 3.20/4.00 3.33/3.53

Unit model RAS-M10UKV-E3 RAS-M13UKV-E3 RAS-M16UKV-E3

High dB

(

)

36/39 39/40 42/42

Medium dB

(

)

33/35 35/35 39/39

Indoor

(Coolin

/Heatin

)

Low dB

(

)

28/29 28/29 33/33

Unit model RAS-4M27YAV-E RAS-3M26YAV-E

Operating

noise

Outdoor

(Coolin

/Heatin

)Full indoor units operatin

(

)

48/48 48/48

Unit model RAS-M10UKV-E3 RAS-M13UKV-E3 RAS-M16UKV-E3

Height

(

)

275275275

Width

(

)

790 790 790

Dimension

Depth

(

)

208208208

Net weight

(

10 10 10

Fan motor output

(

)

19 19 19

Indoor unit

Air flow rate (Cooling/Heating)

(

m³/h

)

470/520 520/560 600/600

Unit model RAS-4M27YAV-E RAS-3M26YAV-E

Height

(

)

795 795

Width

(

)

900 900

Dimension

Depth

(

)

320 320

Net weight

(

65 64

Motor output

(

)

2000

Type Twin rotary type with DC-inverter variable speed control

Compressor

Model DA220A2F-20L

Fan motor output

(

)

Outdoor unit

Air flow rate

(

m³/h

)

High : 3000, Medium : 2800

Type Flare connection

Unit model RAS-M10UKV-E3 RAS-M13UKV-E3 RAS-M16UKV-E3

Liquid side Ø6.35 Ø6.35 Ø6.35

Indoor unit

Gas side Ø9.52 Ø9.52 Ø12.7

Unit model RAS-4M27YAV-E RAS-3M26YAV-E

A unit liquid side/gas side Ø6.35/Ø12.7 Ø6.35/Ø12.7

B unit liquid side/gas side Ø6.35/Ø9.52 Ø6.35/Ø9.52

C unit liquid side/gas side Ø6.35/Ø9.52 Ø6.35/Ø9.52

Outdoor unit

D unit liquid side/gas side Ø6.35/Ø9.52 —

Maximum length (per unit)

(

)

25 25

Maximum length (total)

(

)

70 50

Maximum chargeless length

(

)

70 50

Piping

connection

Maximum height difference

(

)

15 15

Name of refrigerant R410ARefrigerant Weight

(

2.4

Power supply 3 wires : includes earthWiring connection Interconnection 4 wires : includes earth

Indoor

(

°C

)

21 –32/0 –28Usable temperature range Outdoor

(

°C

)

10 –43/–10–21

Installation plate 1

Wireless remote controller 1

Label 2

Remote controller holder 1

Pan head wood screw 2 (Ø3.1 x 16L)

Purifying filter 1

Deodorizing filter 1

Battery 2

Mounting screw 6 (Ø4 x 25L)

Indoor unit

Installation manual 1

Accessory

Outdoor unit Owner's manual 1

–4 –

RAS-M10UKCV-E3, RAS-M13UKCV-E3, RAS-M16UKCV-E3/RAS-4M27YACV-E

•For performance when each indoor unit is combined with other unit, refer to the separate table.

•The specifications may be subject to change without notice for purpose of improvement.

Indoor RAS-M10UKCV-E3, RAS-M13UKCV-E3, RAS-M16UKCV-E3Unit model Outdoor RAS-4M27YACV-E

Cooling capacity (kW) 8.0

Cooling capacity range (kW) 1.4 –9.2

Power supply 220/230/240V, 1Ph, 50/60Hz

Unit model RAS-M10UKCV-E3 RAS-M13UKCV-E3 RAS-M16UKCV-E3

Running current (A) 0.15 0.15 0.15

Power consumption (W) 30 30 30

Indoor

Power factor (%) 91/87/83 91/87/83 91/87/83

Running current (A) 11.60/11.09/10.63

Power consumption (W) 2500

Power factor (%) 98

Electric

characteristics

Total

Starting current (A) 11.60/11.09/10.63

C.O.P. 3.20

Unit model RAS-M10UKCV-E3 RAS-M13UKCV-E3 RAS-M16UKCV-E3

High dB (A) 36 39 42

MediumdB(A)333539

Indoor

LowB (A) 28 28 33

Unit model RAS-4M27YACV-E

Operating

noise

Outdoor 4 indoor units operating dB (A) 48

Unit model RAS-M10UKCV-E3 RAS-M13UKCV-E3 RAS-M16UKCV-E3

Height (mm) 275275275

Width (mm) 790 790 790

Dimension

Depth (mm) 208208208

Net weight (kg) 10 10 10

Fan motor output (W) 19 19 19

Indoor unit

Air flow rate (m³/h) 470 520 600

Unit model RAS-4M27YACV-E

Height (mm) 795

Width (mm) 900

Dimension

Depth (mm) 320

Net weight (kg) 63

Motor output (W) 2000

Type Twin rotary type with DC-inverter variable speed control

Compressor

Model DA220A2F-20L

Fan motor output (W) 60

Outdoor unit

Air flow rate (m³/h) High : 3000, Medium : 2800

Type Flare connection

Unit model RAS-M10UKCV-E3 RAS-M13UKCV-E3 RAS-M16UKCV-E3

Liquid side Ø6.35 Ø6.35 Ø6.35

Indoor unit

Gas side Ø9.52 Ø9.52 Ø12.7

Unit model RAS-4M27YACV-E

A unit liquid side/gas side Ø6.35/Ø12.7

B unit liquid side/gas side Ø6.35/Ø9.52

C unit liquid side/gas side Ø6.35/Ø9.52

Outdoor unit

D unit liquid side/gas side Ø6.35/Ø9.52

Maximum length (per unit) (m) 25

Maximum length (total) (m) 70

Maximum chargeless length (m) 70

Piping

connection

Maximum height difference (m) 15

Name of refrigerant R410ARefrigerant Weight (kg) 2.2

Power supply 3 wires : includes earthWiring connection Interconnection 4 wires : includes earth

Indoor (°C) 21 –32Usable temperature range Outdoor (°C) 10 –43

Installation plate 1

Wireless remote controller 1

Label 2

Remote controller holder 1

Pan head wood screw 2 (Ø3.1 x 16L)

Purifying filter 1

Deodorizing filter 1

Battery 2

Mounting screw 6 (Ø4 x 25L)

Indoor unit

Installation manual 1

Accessory

Outdoor unit Owner's manual 1

–5 –

1-2. Specifications of Performance When Each Indoor Unit is Combined with other Unit

Outdoor Unit : RAS-4M27YAV-E

•The above specification values are those under the conditions that the indoor DB/WB=27/19°C and the outdoor DB/

WB=35/–°C.

•Indoor unit 10 : RAS-M10UKV-E3, 13 : RAS-M13UKV-E3, 16 : RAS-M16UKV-E3

Indoor unit Unit capacity (kW)

Power

(V)

eratin

status ABCD A B C D

Cooling

capacity

(kW)

Power

consum

tion

(W)

Operating

current

(A)

Outdoor

noise

(dB)

220 1 unit 10 –––2.7 ––– 2.7

(1.4 to 3.2) 750

(640 to 950) 3.87

(3.68 to 4.64) 48

13 –––3.7 ––– 3.7

(1.4 to 4.4) 1200

(640 to 1520) 5.74

(3.68 to 7.20) 48

16 –––4.5 ––– 4.5

(1.4 to 5.0) 1650

(640 to 2000) 7.81

(3.68 to 9.28) 48

2 units 10 10 ––2.70 2.70 –– 5.4

(2.5 to 6.3) 1530

(640 to 2040) 7.10

(3.64 to 9.46) 48

13 10 ––3.41 2.49 –– 5.9

(2.7 to 6.6) 1810

(660 to 2220) 8.40

(3.75 to 10.30) 48

16 10 ––3.94 2.36 –– 6.3

(2.9 to 6.9) 2040

(670 to 2400) 9.46

(3.81 to 11.13) 48

13 13 ––3.15 3.15 –– 6.3

(2.9 to 6.9) 2040

(670 to 2400) 9.46

(3.81 to 11.13) 48

16 13 ––3.73 3.07 –– 6.8

(3.0 to 7.2) 2320

(690 to 2570) 10.76

(3.92 to 11.92) 48

16 16 ––3.60 3.60 –– 7.2

(3.2 to 7.5) 2550

(700 to 2750) 11.83

(3.98 to 12.76) 48

3 units 10 10 10 –2.53 2.53 2.53 –7.6

(3.8 to 8.2) 2400

(950 to 2720) 11.13

(4.80 to 12.62) 48

13 10 10 –3.13 2.28 2.28 –7.7

(3.9 to 8.3) 2410

(960 to 2740) 11.18

(4.85 to 12.71) 48

16 10 10 –3.50 2.10 2.10 –7.7

(4.0 to 8.5) 2410

(960 to 2790) 11.18

(4.85 to 12.94) 48

13 13 10 –2.82 2.82 2.06 –7.7

(4.0 to 8.5) 2410

(960 to 2790) 11.18

(4.85 to 12.94) 48

16 13 10 –3.22 2.65 1.93 –7.8

(4.1 to 8.6) 2430

(970 to 2810) 11.27

(4.90 to 13.03) 48

13 13 13 –2.60 2.60 2.60 –7.8

(4.1 to 8.6) 2430

(970 to 2810) 11.27

(4.90 to 13.03) 48

16 16 10 –3.04 3.04 1.82 –7.9

(4.1 to 8.7) 2440

(970 to 2830) 11.32

(4.90 to 13.13) 48

16 13 13 –2.99 2.46 2.46 –7.9

(4.1 to 8.7) 2440

(970 to 2830) 11.32

(4.90 to 13.13) 48

16 16 13 –2.80 2.80 2.30 –7.9

(4.2 to 8.9) 2440

(970 to 2880) 11.32

(4.90 to 13.36) 48

16 16 16 –2.67 2.67 2.67 –8.0

(4.3 to 9.0) 2450

(980 to 2900) 11.36

(4.95 to 13.45) 48

4 units 10 10 10 10 1.98 1.98 1.98 1.98 7.9

(4.0 to 8.7) 2450

(930 to 2800) 11.36

(4.70 to 12.99) 48

13 10 10 10 2.48 1.81 1.81 1.81 7.9

(4.1 to 8.8) 2450

(940 to 2820) 11.36

(4.75 to 13.08) 48

16 10 10 10 2.86 1.71 1.71 1.71 8.0

(4.1 to 9.0) 2500

(940 to 2860) 11.60

(4.75 to 13.27) 48

13 13 10 10 2.31 2.31 1.69 1.69 8.0

(4.1 to 9.0) 2500

(940 to 2860) 11.60

(4.75 to 13.27) 48

16 13 10 10 2.65 2.18 1.59 1.59 8.0

(4.2 to 9.1) 2500

(950 to 2880) 11.60

(4.80 to 13.36) 48

13 13 13 10 2.14 2.14 2.14 1.57 8.0

(4.2 to 9.1) 2500

(950 to 2880) 11.60

(4.80 to 13.36) 48

16 13 13 10 2.47 2.03 2.03 1.48 8.0

(4.2 to 9.2) 2500

(950 to 2900) 11.60

(4.80 to 13.45) 48

13 13 13 13 2.00 2.00 2.00 2.00 8.0

(4.2 to 9.2) 2500

(950 to 2900) 11.60

(4.80 to 13.45) 48

16 16 10 10 2.50 2.50 1.50 1.50 8.0

(4.2 to 9.2) 2500

(950 to 2900) 11.60

(4.80 to 13.45) 48

–6 –

Outdoor Unit : RAS-4M27YAV-E

•The above specification values are those under the conditions that the indoor DB/WB=27/19°C and the outdoor DB/

WB=35/–°C.

•Indoor unit 10 : RAS-M10UKV-E3, 13 : RAS-M13UKV-E3, 16 : RAS-M16UKV-E3

Indoor unit Unit capacity (kW)Power

(V)

eratin

status ABCD A B C D

Cooling

capacity

(kW)

Power

consum

tion

(W)

Operating

current

(A)

Outdoor

noise

(dB)

230 1 unit 10 –––2.7 ––– 2.7

(1.4 to 3.2) 750

(640 to 950) 3.71

(3.52 to 4.44) 48

13 –––3.7 ––– 3.7

(1.4 to 4.4) 1200

(640 to 1520) 5.49

(3.52 to 6.88) 48

16 –––4.5 ––– 4.5

(1.4 to 5.0) 1650

(640 to 2000) 7.47

(3.52 to 8.87) 48

2 units 10 10 ––2.70 2.70 –– 5.4

(2.5 to 6.3) 1530

(640 to 2040) 6.79

(3.48 to 9.05) 48

13 10 ––3.41 2.49 –– 5.9

(2.7 to 6.6) 1810

(660 to 2220) 8.03

(3.59 to 9.85) 48

16 10 ––3.94 2.36 –– 6.3

(2.9 to 6.9) 2040

(670 to 2400) 9.05

(3.64 to 10.65) 48

13 13 ––3.15 3.15 –– 6.3

(2.9 to 6.9) 2040

(670 to 2400) 9.05

(3.64 to 10.65) 48

16 13 ––3.73 3.07 –– 6.8

(3.0 to 7.2) 2320

(690 to 2570) 10.29

(3.75 to 11.40) 48

16 16 ––3.60 3.60 –– 7.2

(3.2 to 7.5) 2550

(700 to 2750) 11.31

(3.80 to 12.20) 48

3 units 10 10 10 –2.53 2.53 2.53 –7.6

(3.8 to 8.2) 2400

(950 to 2720) 10.65

(4.59 to 12.07) 48

13 10 10 –3.13 2.28 2.28 –7.7

(3.9 to 8.3) 2410

(960 to 2740) 10.69

(4.64 to 12.16) 48

16 10 10 –3.50 2.10 2.10 –7.7

(4.0 to 8.5) 2410

(960 to 2790) 10.69

(4.64 to 12.38) 48

13 13 10 –2.82 2.82 2.06 –7.7

(4.0 to 8.5) 2410

(960 to 2790) 10.69

(4.64 to 12.38) 48

16 13 10 –3.22 2.65 1.93 –7.8

(4.1 to 8.6) 2430

(970 to 2810) 10.78

(4.69 to 12.47) 48

13 13 13 –2.60 2.60 2.60 –7.8

(4.1 to 8.6) 2430

(970 to 2810) 10.78

(4.69 to 12.47) 48

16 16 10 –3.04 3.04 1.82 –7.9

(4.1 to 8.7) 2440

(970 to 2830) 10.83

(4.69 to 12.56) 48

16 13 13 –2.99 2.46 2.46 –7.9

(4.1 to 8.7) 2440

(970 to 2830) 10.83

(4.69 to 12.56) 48

16 16 13 –2.80 2.80 2.30 –7.9

(4.2 to 8.9) 2440

(970 to 2880) 10.83

(4.69 to 12.78) 48

16 16 16 –2.67 2.67 2.67 –8.0

(4.3 to 9.0) 2450

(980 to 2900) 10.87

(4.73 to 12.87) 48

4 units 10 10 10 10 1.98 1.98 1.98 1.98 7.9

(4.0 to 8.7) 2450

(930 to 2800) 10.87

(4.49 to 12.42) 48

13 10 10 10 2.48 1.81 1.81 1.81 7.9

(4.1 to 8.8) 2450

(940 to 2820) 10.87

(4.54 to 12.51) 48

16 10 10 10 2.86 1.71 1.71 1.71 8.0

(4.1 to 9.0) 2500

(940 to 2860) 11.09

(4.54 to 12.69) 48

13 13 10 10 2.31 2.31 1.69 1.69 8.0

(4.1 to 9.0) 2500

(940 to 2860) 11.09

(4.54 to 12.69) 48

16 13 10 10 2.65 2.18 1.59 1.59 8.0

(4.2 to 9.1) 2500

(950 to 2880) 11.09

(4.59 to 12.78) 48

13 13 13 10 2.14 2.14 2.14 1.57 8.0

(4.2 to 9.1) 2500

(950 to 2880) 11.09

(4.59 to 12.78) 48

16 13 13 10 2.47 2.03 2.03 1.48 8.0

(4.2 to 9.2) 2500

(950 to 2900) 11.09

(4.59 to 12.87) 48

13 13 13 13 2.00 2.00 2.00 2.00 8.0

(4.2 to 9.2) 2500

(950 to 2900) 11.09

(4.59 to 12.87) 48

16 16 10 10 2.50 2.50 1.50 1.50 8.0

(4.2 to 9.2) 2500

(950 to 2900) 11.09

(4.59 to 12.87) 48

–7 –

Outdoor Unit : RAS-4M27YAV-E

•The above specification values are those under the conditions that the indoor DB/WB=27/19°C and the outdoor DB/

WB=35/–°C.

•Indoor unit 10 : RAS-M10UKV-E3, 13 : RAS-M13UKV-E3, 16 : RAS-M16UKV-E3

Indoor unit Unit capacity (kW)Power

(V)

eratin

status ABCD A B C D

Cooling

capacity

(kW)

Power

consum

tion

(W)

Operating

current

(A)

Outdoor

noise

(dB)

240 1 unit 10 –––2.7 ––– 2.7

(1.4 to 3.2) 750

(640 to 950) 3.55

(3.38 to 4.26) 48

13 –––3.7 ––– 3.7

(1.4 to 4.4) 1200

(640 to 1520) 5.26

(3.38 to 6.60) 48

16 –––4.5 ––– 4.5

(1.4 to 5.0) 1650

(640 to 2000) 7.16

(3.38 to 8.50) 48

2 units 10 10 ––2.70 2.70 –– 5.4

(2.5 to 6.3) 1530

(640 to 2040) 6.51

(3.33 to 8.67) 48

13 10 ––3.41 2.49 –– 5.9

(2.7 to 6.6) 1810

(660 to 2220) 7.70

(3.44 to 9.44) 48

16 10 ––3.94 2.36 –– 6.3

(2.9 to 6.9) 2040

(670 to 2400) 8.67

(3.49 to 10.20) 48

13 13 ––3.15 3.15 –– 6.3

(2.9 to 6.9) 2040

(670 to 2400) 8.67

(3.49 to 10.20) 48

16 13 ––3.73 3.07 –– 6.8

(3.0 to 7.2) 2320

(690 to 2570) 9.86

(3.59 to 10.93) 48

16 16 ––3.60 3.60 –– 7.2

(3.2 to 7.5) 2550

(700 to 2750) 10.84

(3.65 to 11.69) 48

3 units 10 10 10 –2.53 2.53 2.53 –7.6

(3.8 to 8.2) 2400

(950 to 2720) 10.20

(4.40 to 11.56) 48

13 10 10 –3.13 2.28 2.28 –7.7

(3.9 to 8.3) 2410

(960 to 2740) 10.25

(4.44 to 11.65) 48

16 10 10 –3.50 2.10 2.10 –7.7

(4.0 to 8.5) 2410

(960 to 2790) 10.25

(4.44 to 11.86) 48

13 13 10 –2.82 2.82 2.06 –7.7

(4.0 to 8.5) 2410

(960 to 2790) 10.25

(4.44 to 11.86) 48

16 13 10 –3.22 2.65 1.93 –7.8

(4.1 to 8.6) 2430

(970 to 2810) 10.33

(4.49 to 11.95) 48

13 13 13 –2.60 2.60 2.60 –7.8

(4.1 to 8.6) 2430

(970 to 2810) 10.33

(4.49 to 11.95) 48

16 16 10 –3.04 3.04 1.82 –7.9

(4.1 to 8.7) 2440

(970 to 2830) 10.37

(4.49 to 12.03) 48

16 13 13 –2.99 2.46 2.46 –7.9

(4.1 to 8.7) 2440

(970 to 2830) 10.37

(4.49 to 12.03) 48

16 16 13 –2.80 2.80 2.30 –7.9

(4.2 to 8.9) 2440

(970 to 2880) 10.37

(4.49 to 12.24) 48

16 16 16 –2.67 2.67 2.67 –8.0

(4.3 to 9.0) 2450

(980 to 2900) 10.42

(4.54 to 12.33) 48

4 units 10 10 10 10 1.98 1.98 1.98 1.98 7.9

(4.0 to 8.7) 2450

(930 to 2800) 10.42

(4.31 to 11.90) 48

13 10 10 10 2.48 1.81 1.81 1.81 7.9

(4.1 to 8.8) 2450

(940 to 2820) 10.42

(4.35 to 11.99) 48

16 10 10 10 2.86 1.71 1.71 1.71 8.0

(4.1 to 9.0) 2500

(940 to 2860) 10.63

(4.35 to 12.16) 48

13 13 10 10 2.31 2.31 1.69 1.69 8.0

(4.1 to 9.0) 2500

(940 to 2860) 10.63

(4.35 to 12.16) 48

16 13 10 10 2.65 2.18 1.59 1.59 8.0

(4.2 to 9.1) 2500

(950 to 2880) 10.63

(4.40 to 12.24) 48

13 13 13 10 2.14 2.14 2.14 1.57 8.0

(4.2 to 9.1) 2500

(950 to 2880) 10.63

(4.40 to 12.24) 48

16 13 13 10 2.47 2.03 2.03 1.48 8.0

(4.2 to 9.2) 2500

(950 to 2900) 10.63

(4.40 to 12.33) 48

13 13 13 13 2.00 2.00 2.00 2.00 8.0

(4.2 to 9.2) 2500

(950 to 2900) 10.63

(4.40 to 12.33) 48

16 16 10 10 2.50 2.50 1.50 1.50 8.0

(4.2 to 9.2) 2500

(950 to 2900) 10.63

(4.40 to 12.33) 48

–8 –

Outdoor Unit : RAS-4M27YAV-E

•The above specification values are those under the conditions that the indoor DB/WB=27/19°C and the outdoor DB/

WB=35/–°C.

•Indoor unit 10 : RAS-M10UKV-E3, 13 : RAS-M13UKV-E3, 16 : RAS-M16UKV-E3

Indoor unit Unit capacity (kW)Power

(V)

eratin

status ABCD A B C D

Heating

capacity

(kW)

Power

consum

tion

(W)

Operating

current

(A)

Outdoor

noise

(dB)

220 1 unit 10 –––4.0 ––– 4.0

(0.8 to 5.2) 1450

(300 to 1980) 6.73

(1.87 to 9.18) 48

13 –––5.0 ––– 5.0

(0.8 to 6.5) 2050

(310 to 2750) 9.51

(1.93 to 12.76) 48

16 –––5.5 ––– 5.5

(0.8 to 6.9) 2400

(310 to 3000) 11.13

(1.93 to 13.91) 48

2 units 10 10 ––3.60 3.60 –– 7.2

(1.5 to 10.0) 2100

(320 to 3200) 9.74

(1.94 to 14.84) 48

13 10 ––4.22 3.38 –– 7.6

(1.5 to 10.1) 2320

(320 to 3210) 10.76

(1.94 to 14.89) 48

16 10 ––4.57 3.33 –– 7.9

(1.5 to 10.1) 2480

(320 to 3230) 11.50

(1.94 to 14.98) 48

13 13 ––3.95 3.95 –– 7.9

(1.5 to 10.1) 2480

(320 to 3230) 11.50

(1.94 to 14.98) 48

16 13 ––4.35 3.95 –– 8.3

(1.5 to 10.2) 2700

(320 to 3240) 12.52

(1.94 to 15.03) 48

16 16 ––4.30 4.30 –– 8.6

(1.5 to 10.2) 2860

(320 to 3250) 13.27

(1.94 to 15.07) 48

3 units 10 10 10 –2.87 2.87 2.87 –8.6

(2.0 to 10.4) 2300

(380 to 2750) 10.67

(2.16 to 12.76) 48

13 10 10 –3.35 2.68 2.68 –8.7

(2.0 to 10.5) 2350

(380 to 2760) 10.90

(2.16 to 12.80) 48

16 10 10 –3.54 2.58 2.58 –8.7

(2.0 to 10.5) 2350

(380 to 2760) 10.90

(2.16 to 12.80) 48

13 13 10 –3.11 3.11 2.49 –8.7

(2.0 to 10.5) 2350

(380 to 2760) 10.90

(2.16 to 12.80) 48

16 13 10 –3.34 3.03 2.43 –8.8

(2.0 to 10.6) 2400

(380 to 2780) 11.13

(2.16 to 12.89) 48

13 13 13 –2.93 2.93 2.93 –8.8

(2.0 to 10.6) 2400

(380 to 2780) 11.13

(2.16 to 12.89) 48

16 16 10 –3.26 3.26 2.37 –8.9

(2.0 to 10.7) 2450

(380 to 2790) 11.36

(2.16 to 12.94) 48

16 13 13 –3.16 2.87 2.87 –8.9

(2.0 to 10.7) 2450

(380 to 2790) 11.36

(2.16 to 12.94) 48

16 16 13 –3.06 3.06 2.78 –8.9

(2.0 to 10.7) 2450

(380 to 2790) 11.36

(2.16 to 12.94) 48

16 16 16 –3.00 3.00 3.00 –9.0

(2.0 to 10.8) 2500

(380 to 2800) 11.60

(2.16 to 12.99) 48

4 units 10 10 10 10 2.23 2.23 2.23 2.23 8.9

(2.2 to 10.8) 2100

(450 to 2810) 9.74

(2.56 to 13.03) 48

13 10 10 10 2.62 2.09 2.09 2.09 8.9

(2.2 to 10.9) 2100

(460 to 2830) 9.74

(2.61 to 13.13) 48

16 10 10 10 2.83 2.06 2.06 2.06 9.0

(2.2 to 10.9) 2250

(460 to 2830) 10.44

(2.61 to 13.13) 48

13 13 10 10 2.50 2.50 2.00 2.00 9.0

(2.2 to 10.9) 2250

(470 to 2830) 10.44

(2.67 to 13.13) 48

16 13 10 10 2.68 2.43 1.95 1.95 9.0

(2.2 to 11.0) 2250

(480 to 2850) 10.44

(2.73 to 13.22) 48

13 13 13 10 2.37 2.37 2.37 1.89 9.0

(2.2 to 11.0) 2250

(480 to 2850) 10.44

(2.73 to 13.22) 48

16 13 13 10 2.54 2.31 2.31 1.85 9.0

(2.2 to 11.0) 2250

(490 to 2850) 10.44

(2.78 to 13.22) 48

13 13 13 13 2.25 2.25 2.25 2.25 9.0

(2.2 to 11.0) 2250

(490 to 2850) 10.44

(2.78 to 13.22) 48

16 16 10 10 2.61 2.61 1.89 1.89 9.0

(2.2 to 11.0) 2250

(500 to 2850) 10.44

(2.84 to 13.22) 48

–9 –

•The above specification values are those under the conditions that the indoor DB/WB=27/19°C and the outdoor DB/

WB=35/–°C.

•Indoor unit 10 : RAS-M10UKV-E3, 13 : RAS-M13UKV-E3, 16 : RAS-M16UKV-E3

Outdoor Unit : RAS-4M27YAV-E

Indoor unit Unit capacity (kW)Power

(V)

eratin

status ABCD A B C D

Heating

capacity

(kW)

Power

consum

tion

(W)

Operating

current

(A)

Outdoor

noise

(dB)

230 1 unit 10 –––4.0 ––– 4.0

(0.8 to 5.2) 1450

(300 to 1980) 6.43

(1.79 to 8.78) 48

13 –––5.0 ––– 5.0

(0.8 to 6.5) 2050

(310 to 2750) 9.09

(1.85 to 12.20) 48

16 –––5.5 ––– 5.5

(0.8 to 6.9) 2400

(310 to 3000) 10.65

(1.85 to 13.31) 48

2 units 10 10 ––3.60 3.60 –– 7.2

(1.5 to 10.0) 2100

(320 to 3200) 9.32

(1.86 to 14.20) 48

13 10 ––4.22 3.38 –– 7.6

(1.5 to 10.1) 2320

(320 to 3210) 10.29

(1.86 to 14.24) 48

16 10 ––4.57 3.33 –– 7.9

(1.5 to 10.1) 2480

(320 to 3230) 11.00

(1.86 to 14.33) 48

13 13 ––3.95 3.95 –– 7.9

(1.5 to 10.1) 2480

(320 to 3230) 11.00

(1.86 to 14.33) 48

16 13 ––4.35 3.95 –– 8.3

(1.5 to 10.2) 2700

(320 to 3240) 11.98

(1.86 to 14.37) 48

16 16 ––4.30 4.30 –– 8.6

(1.5 to 10.2) 2860

(320 to 3250) 12.69

(1.86 to 14.42) 48

3 units 10 10 10 –2.87 2.87 2.87 –8.6

(2.0 to 10.4) 2300

(380 to 2750) 10.20

(2.07 to 12.20) 48

13 10 10 –3.35 2.68 2.68 –8.7

(2.0 to 10.5) 2350

(380 to 2760) 10.43

(2.07 to 12.24) 48

16 10 10 –3.54 2.58 2.58 –8.7

(2.0 to 10.5) 2350

(380 to 2760) 10.43

(2.07 to 12.24) 48

13 13 10 –3.11 3.11 2.49 –8.7

(2.0 to 10.5) 2350

(380 to 2760) 10.43

(2.07 to 12.24) 48

16 13 10 –3.34 3.03 2.43 –8.8

(2.0 to 10.6) 2400

(380 to 2780) 10.65

(2.07 to 12.33) 48

13 13 13 –2.93 2.93 2.93 –8.8

(2.0 to 10.6) 2400

(380 to 2780) 10.65

(2.07 to 12.33) 48

16 16 10 –3.26 3.26 2.37 –8.9

(2.0 to 10.7) 2450

(380 to 2790) 10.87

(2.07 to 12.38) 48

16 13 13 –3.16 2.87 2.87 –8.9

(2.0 to 10.7) 2450

(380 to 2790) 10.87

(2.07 to 12.38) 48

16 16 13 –3.06 3.06 2.78 –8.9

(2.0 to 10.7) 2450

(380 to 2790) 10.87

(2.07 to 12.38) 48

16 16 16 –3.00 3.00 3.00 –9.0

(2.0 to 10.8) 2500

(380 to 2800) 11.09

(2.07 to 12.42) 48

4 units 10 10 10 10 2.23 2.23 2.23 2.23 8.9

(2.2 to 10.8) 2100

(450 to 2810) 9.32

(2.45 to 12.47) 48

13 10 10 10 2.62 2.09 2.09 2.09 8.9

(2.2 to 10.9) 2100

(460 to 2830) 9.32

(2.50 to 12.56) 48

16 10 10 10 2.83 2.06 2.06 2.06 9.0

(2.2 to 10.9) 2250

(460 to 2830) 9.98

(2.50 to 12.56) 48

13 13 10 10 2.50 2.50 2.00 2.00 9.0

(2.2 to 10.9) 2250

(470 to 2830) 9.98

(2.55 to 12.56) 48

16 13 10 10 2.68 2.43 1.95 1.95 9.0

(2.2 to 11.0) 2250

(480 to 2850) 9.98

(2.61 to 12.64) 48

13 13 13 10 2.37 2.37 2.37 1.89 9.0

(2.2 to 11.0) 2250

(480 to 2850) 9.98

(2.61 to 12.64) 48

16 13 13 10 2.54 2.31 2.31 1.85 9.0

(2.2 to 11.0) 2250

(490 to 2850) 9.98

(2.66 to 12.64) 48

13 13 13 13 2.25 2.25 2.25 2.25 9.0

(2.2 to 11.0) 2250

(490 to 2850) 9.98

(2.66 to 12.64) 48

16 16 10 10 2.61 2.61 1.89 1.89 9.0

(2.2 to 11.0) 2250

(500 to 2850) 9.98

(2.72 to 12.64) 48

–10 –

Outdoor Unit : RAS-4M27YAV-E

•The above specification values are those under the conditions that the indoor DB/WB=27/19°C and the outdoor DB/

WB=35/–°C.

•Indoor unit 10 : RAS-M10UKV-E3, 13 : RAS-M13UKV-E3, 16 : RAS-M16UKV-E3

Indoor unit Unit capacity (kW)Power

(V)

eratin

status ABCD A B C D

Heating

capacity

(kW)

Power

consum

tion

(W)

Operating

current

(A)

Outdoor

noise

(dB)

240 1 unit 10 –––4.0 ––– 4.0

(0.8 to 5.2) 1450

(300 to 1980) 6.16

(1.71 to 8.42) 48

13 –––5.0 ––– 5.0

(0.8 to 6.5) 2050

(310 to 2750) 8.72

(1.77 to 11.69) 48

16 –––5.5 ––– 5.5

(0.8 to 6.9) 2400

(310 to 3000) 10.20

(1.77 to 12.76) 48

2 units 10 10 ––3.60 3.60 –– 7.2

(1.5 to 10.0) 2100

(320 to 3200) 8.93

(1.78 to 13.61) 48

13 10 ––4.22 3.38 –– 7.6

(1.5 to 10.1) 2320

(320 to 3210) 9.86

(1.78 to 13.65) 48

16 10 ––4.57 3.33 –– 7.9

(1.5 to 10.1) 2480

(320 to 3230) 10.54

(1.78 to 13.73) 48

13 13 ––3.95 3.95 –– 7.9

(1.5 to 10.1) 2480

(320 to 3230) 10.54

(1.78 to 13.73) 48

16 13 ––4.35 3.95 –– 8.3

(1.5 to 10.2) 2700

(320 to 3240) 11.48

(1.78 to 13.78) 48

16 16 ––4.30 4.30 –– 8.6

(1.5 to 10.2) 2860

(320 to 3250) 12.16

(1.78 to 13.82) 48

3 units 10 10 10 –2.87 2.87 2.87 –8.6

(2.0 to 10.4) 2300

(380 to 2750) 9.78

(1.98 to 11.69) 48

13 10 10 –3.35 2.68 2.68 –8.7

(2.0 to 10.5) 2350

(380 to 2760) 9.99

(1.98 to 11.73) 48

16 10 10 –3.54 2.58 2.58 –8.7

(2.0 to 10.5) 2350

(380 to 2760) 9.99

(1.98 to 11.73) 48

13 13 10 –3.11 3.11 2.49 –8.7

(2.0 to 10.5) 2350

(380 to 2760) 9.99

(1.98 to 11.73) 48

16 13 10 –3.34 3.03 2.43 –8.8

(2.0 to 10.6) 2400

(380 to 2780) 10.20

(1.98 to 11.82) 48

13 13 13 –2.93 2.93 2.93 –8.8

(2.0 to 10.6) 2400

(380 to 2780) 10.20

(1.98 to 11.82) 48

16 16 10 –3.26 3.26 2.37 –8.9

(2.0 to 10.7) 2450

(380 to 2790) 10.42

(1.98 to 11.86) 48

16 13 13 –3.16 2.87 2.87 –8.9

(2.0 to 10.7) 2450

(380 to 2790) 10.42

(1.98 to 11.86) 48

16 16 13 –3.06 3.06 2.78 –8.9

(2.0 to 10.7) 2450

(380 to 2790) 10.42

(1.98 to 11.86) 48

16 16 16 –3.00 3.00 3.00 –9.0

(2.0 to 10.8) 2500

(380 to 2800) 10.63

(1.98 to 11.90) 48

4 units 10 10 10 10 2.23 2.23 2.23 2.23 8.9

(2.2 to 10.8) 2100

(450 to 2810) 8.93

(2.34 to 11.95) 48

13 10 10 10 2.62 2.09 2.09 2.09 8.9

(2.2 to 10.9) 2100

(460 to 2830) 8.93

(2.40 to 12.03) 48

16 10 10 10 2.83 2.06 2.06 2.06 9.0

(2.2 to 10.9) 2250

(460 to 2830) 9.57

(2.40 to 12.03) 48

13 13 10 10 2.50 2.50 2.00 2.00 9.0

(2.2 to 10.9) 2250

(470 to 2830) 9.57

(2.45 to 12.03) 48

16 13 10 10 2.68 2.43 1.95 1.95 9.0

(2.2 to 11.0) 2250

(480 to 2850) 9.57

(2.50 to 12.12) 48

13 13 13 10 2.37 2.37 2.37 1.89 9.0

(2.2 to 11.0) 2250

(480 to 2850) 9.57

(2.50 to 12.12) 48

16 13 13 10 2.54 2.31 2.31 1.85 9.0

(2.2 to 11.0) 2250

(490 to 2850) 9.57

(2.55 to 12.12) 48

13 13 13 13 2.25 2.25 2.25 2.25 9.0

(2.2 to 11.0) 2250

(490 to 2850) 9.57

(2.55 to 12.12) 48

16 16 10 10 2.61 2.61 1.89 1.89 9.0

(2.2 to 11.0) 2250

(500 to 2850) 9.57

(2.60 to 12.12) 48

This manual suits for next models

Table of contents

Other Toshiba Air Conditioner manuals

Toshiba

Toshiba RB-B11MC(W)E User manual

Toshiba

Toshiba TCB-LK2801DP-E User manual

Toshiba

Toshiba RAS-07YKX User manual

Toshiba

Toshiba RAC-WK1823ESCWR User manual

Toshiba

Toshiba RAS-2M10U2AVG-E User manual

Toshiba

Toshiba RAV-SM562UT-E User manual

Toshiba

Toshiba RAS-18PKVSG-E User manual

Toshiba

Toshiba 35UFV-ND User manual

Toshiba

Toshiba RAV-SM404SDT-E User manual

Toshiba

Toshiba RAV-SM408CTP-E User manual

Toshiba

Toshiba R410A User manual

Toshiba

Toshiba OSK102 User manual

Toshiba

Toshiba RAV-RM561CTP-E User manual

Toshiba

Toshiba RAV-104 Series User manual

Toshiba

Toshiba RAS-24UKX User manual

Toshiba

Toshiba RAS-10S3AV-E User manual

Toshiba

Toshiba MMK-AP0054MHP-E User manual

Toshiba

Toshiba RAS-M10PKVP-E User manual

Toshiba

Toshiba RAC-61SE2B Mounting instructions

Toshiba

Toshiba RAS-24BKX User manual

Toshiba

Toshiba RAS-18N3KCV Series User manual

Toshiba

Toshiba RAS-12KSX-1 User manual

Toshiba

Toshiba RB-N105S-G User manual

Toshiba

Toshiba RAS-07BKV-E User manual

Popular Air Conditioner manuals by other brands

Spheros

Spheros CC 355 instructions

Bosch

Bosch Climate 5000 SCI 24 CAS/ OU- OUE owner's manual

Panasonic

Panasonic CS-E12HKEW operating instructions

nedis

nedis ACMB1WT7 quick start guide

Samsung

Samsung AR KV Series User & installation manual

Daikin

Daikin FCFV50A Operation manual

Fujitsu

Fujitsu Inverter ASBA30JFC operating manual

Daikin

Daikin FXLQ20MAVE Operation manual

Hitachi

Hitachi RAS-E24CAK instruction manual

CIAT

CIAT Magister 2 Series Installation, Operation, Commissioning, Maintenance

Bestron

Bestron AAC6000 instruction manual

Hisense

Hisense 7K Use and Installation Instructions

Frigidaire

Frigidaire FFRE0533S1E0 Use & care guide

Samsung

Samsung AS09HM3N user manual

Frigidaire

Frigidaire CRA073PU11 use & care

Soleus Air

Soleus Air GB-PAC-08E4 operating instructions

McQuay

McQuay MCK020A Technical manual

Webasto

Webasto Frigo Top 25 DS Instructions for use
