USA Parts list
Part #
Part name
Material, dimensions
Loose
In bag
building instruction 01 -
1A fuselage front part fibreglass 01 -
1B fuselage tube carbon tube 01
1-1 engine mount fibreglass 2 mm - 01+01
1-2 servo tray rudder + elevator plywood 3 x 41 x 35 mm - 01
1-3 link support balsa 3 x 6 x 40 mm - 01
1-4 air hole cover ABS plastic - 01
1-6 tail skid fibreglass 1 mm - 01
2 wing balsa assembly 02 -
2-1 aileron balsa assembly 02 -
2-11 flap balsa assembly 02 -
24 wing joiner carbon tube ∅7/5 x 160 mm - 01
2-2 wing fixing screw nylon screw M 4 x 15 mm - 02
2-21 centering pin fibreglass ∅2 x 20 mm - 01
2-22 screw mount plastic 0,7 x 20 x 37mm - 01
2-25 centering pin fibreglass ∅3 x 40 mm - 02
2-3 captive nut M4 - 02
2-31 nut mount plywood 3 x 20 x 35 mm - 01
2-41 wing servo cover ABS plastic - 04
2-5 aileron-flap pushrod piano wire M2 x 31 mm - 04
2-7 clevis MPJ 2110 - 08
2-8 aileron horn fibreglass plate 1 mm - 02
2-81 flap horn fibreglass plate 1 mm - 02
3 horizontal stabilizer balsa assembly 01 -
3-5 elevator link bowden ∅2 mm L=810mm,
piano wire ∅0,8 mm L= 860mm 01+01 -
3-6 threaded link brass MPJ 2764 - 01
3-8 elevator horn fibreglass plate 1 mm - 01
4 vertical tail construction balsa 01 -
4-5 rudder link bowden ∅2 mm L=700mm,
piano wire ∅0,8 mm L= 780mm 01+01 -
4-6 screw-lock pushrod connector MPJ 2764 - 01
4-8 rudder horn fibreglass 1 mm - 01
6 canopy fibreglass 01 -
6-2 canopy fixing wood screw ∅2,9 x 6,5 mm - 01
7 stickers 01
RECOMMENDED RC EQUIPMENT:
Radio : 5 channel + 7 channel (receiver)
Servos : 6 x pico servo ( TS 1118 )
Motor : SPEED (MIG) – 400 / 6V + gearbox 3,8 :1 ( Mega ACn 16/15/6)
Controller: JETI JES 20, JETI SPIN 22
ATTENTION:
This model costruction kit is not a toy and is not suitable for childern under the age of 14.
Incorrect use of this material could cause material damage or person injury. You are fully responsable for your
actions when you use this model.
Fly at a safe distance from occupied zones. Be sure tha
t no one else is using the same frequency as you.
