Thomann The box TA12 User manual

TA12

full-rangespeaker

user manual

Musikhaus Thomann e.K.

Treppendorf 30

96138 Burgebrach

Germany

Telephone: +49 (0) 9546 9223-0

email: [email protected]

Internet: www.thomann.de

30.11.2011

Table of contents

1 General notes............................................................................................................................................... 4

2 Safety instructions..................................................................................................................................... 7

3 Operating elements............................................................................................................................... 12

4 Installation.................................................................................................................................................. 15

4.1 Pin assignment.................................................................................................................................. 17

4.2 Tips on speaker positioning......................................................................................................... 18

5 Technical specifications....................................................................................................................... 19

6 Cleaning and care.................................................................................................................................... 21

7 Protecting the environment.............................................................................................................. 22

Table of contents

TA12

1 General notes

This user manual contains important information on the safe operation of the device. Read and

follow all safety notes and all instructions. Save this manual for future reference. Make sure

that it is available to all persons using this device. If you sell the device to another user, be sure

that they also receive this manual.

Our products are subject to a process of continuous development. We therefore reserve the

right to make changes without notice.

This section gives an overview of the symbols and signal words used in this user manual.Symbols and signal words

General notes

full-rangespeaker

Signal word Meaning

DANGER! This combination of symbol and signal word

indicates an immediate dangerous situation

that will result in death or serious injury if it is

not avoided.

WARNING! This combination of symbol and signal word

indicates a possible dangerous situation that

can result in death or serious injury if it is not

avoided.

CAUTION! This combination of symbol and signal word

indicates a possible dangerous situation that

can result in minor injury if it is not avoided.

NOTICE! This combination of symbol and signal word

indicates a possible dangerous situation that

can result in material and environmental

damage if it is not avoided.

General notes

TA12

Warning signs Type of danger

Warning – high-voltage.

Warning – suspended load.

Warning – danger zone.

General notes

full-rangespeaker

2 Safety instructions

This device is intended to be used in a sound reinforcement system. Use the device only as

described in this user manual. Any other use or use under other operating conditions is consid‐

ered to be improper and may result in personal injury or property damage. No liability will be

assumed for damages resulting from improper use.

This device may be used only by persons with sufficient physical, sensorial, and intellectual

abilities and having corresponding knowledge and experience. Other persons may use this

device only if they are supervised or instructed by a person who is responsible for their safety.

DANGER!

Danger for children

Ensure that plastic bags, packaging, etc. are disposed of properly and are not

within reach of babies and young children. Choking hazard!

Ensure that children do not detach any small parts (e.g. knobs or the like) from

the unit. They could swallow the pieces and choke!

Never let children unattended use electrical devices.

Intended use

Safety instructions

TA12

DANGER!

Electric shock caused by high voltages inside

Within the device there are areas where high voltages may be present. Never

remove any covers.

There are no user-serviceable parts inside.

DANGER!

Electric shock caused by short-circuit

Always use proper ready-made insulated mains cabling (power cord) with a pro‐

tective contact plug. Do not modify the mains cable or the plug. Failure to do so

could result in electric shock/death or fire. If in doubt, seek advice from a regis‐

tered electrician.

Safety instructions

full-rangespeaker

CAUTION!

Possible hearing damage

The device can produce volume levels that may cause temporary or permanent

hearing impairment. Over an extended period of time, even levels that seem to

be uncritical can cause hearing damage.

Decrease the volume level immediately if you experience ringing in your ears or

hearing impairment. If this is not possible, keep a greater distance or use suffi‐

cient ear protectors.

NOTICE!

Risk of fire

Do not block areas of ventilation. Do not install the device near any direct heat

source. Keep the device away from naked flames.

Safety instructions

TA12

NOTICE!

Operating conditions

This device has been designed for indoor use only. To prevent damage, never

expose the device to any liquid or moisture. Avoid direct sunlight, heavy dirt, and

strong vibrations.

NOTICE!

Power supply

Before connecting the device, ensure that the input voltage (AC outlet) matches

the voltage rating of the device and that the AC outlet is protected by a residual

current circuit breaker. Failure to do so could result in damage to the device and

possibly injure the user.

Unplug the device before electrical storms occur and when it is unused for long

periods of time to reduce the risk of electric shock or fire.

Safety instructions

full-rangespeaker
