CS2.4

• Very high performance 3-way loudspeaker

• Specially designed coincident tweeter/midrange array

• Completely time and phase coherent for greater realism

• Ultra-low distortion short-coil, long gap, copper-stabilized driver motor systems

• Uniform, resistive load improves performance when used with smaller amplifiers

• Provides great realism for both music and movies

A revolutionary departure from conventional speaker designs, the CS2.4 offers a new

perspective in loudspeaker performance. The three-way system incorporates all THIEL-

designed and built metal diaphragm drivers—a 1-inch dome tweeter, 3.5-inch

midrange driver, and 8-inch woofer—along with a 7.5 x 11-inch passive radiator. Metal

diaphragms provide much higher stiffness which eliminates diaphragm resonances in

the operating range for very clear and open reproduction. The CS2.4 drivers also use

unusual short coil/long gap, copper-stabilized motor systems to dramatically reduce

distortion. Coupled with the low resonance diaphragms and very high quality electrical

network components, a very high level of clarity and tonal accuracy is achieved.

—Marc Mickleson,

SoundStage

“At their price,

I have never

heard anything

better…”

—John E. Johnson,

Secrets of Home Theater and

High Fidelity

• Innovations Design & Engineering Award for 2004

• The Absolute Sound “Editors’ Choice” Award

• SoundStage “Reviewers’ Choice”Award

• Electronic House “Product of the Year”Award

“The THIEL CS2.4

is a great

loudspeaker, one

of the best I've

heard, regardless

of price.”

THIEL’s Award-winning sound

4

“[the CS2.4] exhibits a near-

obsessive attention to

detail…nearly faultless in so

many parameters ”

—Neil Gader,

The Absolute Sound,

Issue 144

“The CS2.4 further affirms

THIEL‘s reputation as one of

the world's leading

loudspeaker manufacturers”

—Electronic House Magazine

, September 2003

midrange

cone

voice

coil

tweeter

dome coupling

suspension

midrange

suspension

The CS2.4 tweeter/midrange

drivers are mounted

coaxially and share the

same

voice coil. A

mechanical crossover is

implemented by the

coupling suspension

between the two

diaphragms.

Compound Driver System

The difference is our engineering
