Thermo Pride 13 Seer User manual
Thermo Pride
Packaged
Oil Heating and
Air Conditioning
Built Tough for Lifetime Comfort™
13/14 SEER
2
— this is stronger than less expensive steel used by some manu-
facturers. e unique, eight sided design holds flue gasses in the
heat exchanger longer to extract more heat — increasing the
unit’s efficiency and thus saving you money.
Central Air Conditioning
e ermoPack provides you with the comfort and convenience
of not only a quality furnace, but state-of-the-art electric central
air conditioning as well. Air conditioning, which was once a
luxury, is now a necessity to keep your home pleasant all summer
long.
ermoPacks provide you with increased air conditioning ef-
ficiency — up to 14 SEER, which saves you energy over older,
less efficient units. e ermoPack also enhances your comfort
by ensuring long unit life and quiet operation with a Copeland
scroll compressor which pumps the refrigerant through the
system.
ermoPacks are environmentally friendly using the new
non-ozone depleting R-410A refrigerant.
Plus, they use less electricity reducing the
pollution from power plants and are quieter
than other outdoor units cutting down on
noise pollution outside your home.
is unique combination of design and materials provides
ermo Pride ermoPack owners with the superior comfort of
both oil heating and air conditioning in a single outdoor unit
— as well as the confidence in knowing that your ermoPack is
environmentally friendly and made to last a lifetime!
Warranty
e proven longevity of ermo Pride’s heat exchanger,
combined with the Limited Lifetime Warranty and 10-year
warranty on the air conditioning compressor, condenser and
evaporator coil, virtually eliminates the worry of ever having to
replace your ermoPack. If you sell your home, the warranty
will automatically transfer to the new owners. ermo Pride
units also come with a “Peace of Mind” 5-year parts warranty.
Optional 5-year labor coverage is available, or you have the
opportunity to extend this warranty to a 10-year parts and labor
warranty.
Certified Value
ermo Products is an ISO 9001:2000 registered
company. is means that our products are quality
inspected to ensure a high level of value.
You can be proud that your ermoPack is
manufactured in America from steel that’s produced
right here in the United States.
ermo Pride —
Dependable Craftsmanship
For over 60 years, ermo Pride has listened
to consumers’ concerns about comfort and has
met the demand for the best, most reliable,
efficient furnaces and cooling systems. Every
ermo Pride product is built with traditional,
dependable craftsmanship. What this means to
you is quiet, reliable, long lasting performance.
One Unit for All Seasons
e ermoPack™ combination heating and air condition-
ing unit is engineered to provide year-round comfort for your
home. is high-efficiency system starts paying for itself with
easy outdoor installation and significant fuel savings over older
heating and air conditioning units. Since all mechanical func-
tions are outdoors, its operation is remarkably quiet. Plus, the
ECM blower motor’s variable speeds than mean your ermo-
Pack blower can operate at a lower speed than conventional
blowers providing you with a much quieter system. Best of all,
your ermoPack will keep saving money longer than any single
package unit because it is built ermo Pride tough — your best
assurance for long life and trouble-free operation.
Comfort
Comfort is the purpose behind any heating system. “Tempera-
ture rise” makes the difference between feeling warm, comfort-
able air from the registers in your home or the feeling of cool
drafts blowing across you when the furnace is on. (It is the
difference in air temperature from the point where it enters the
furnace to the point where it exits.) e higher the tempera-
ture rise — the warmer the air when it enters the rooms of
your home. e ermoPack has a 70°F temperature rise when
operating on high fire. is is an air temperature up to 30°F
warmer than the competition — providing a far superior level of
comfort. e ermoPack’s variable speed blower also provides
exceptional comfort by gradually ramping up to speed, avoiding
that undesirable blast of air in your home and saving on your
utility bill each month.
No One Builds a Single Packaged
Unit As Tough As ermo Pride
Your ermoPack is constructed from the best materials, includ-
ing heavy-gauge stainless steel and copper tubing.
Octatherm™ Heat Exchanger
At the heart of every ermo Pride oil-fired
furnaces is the “Octatherm” heat exchanger.
e ermoPack’s Octatherm heat exchanger
is fabricated out of 16-gauge stainless steel
Packaged Oil Heating and
Air Conditioning at its Best
3
Air Conditioner
Easy access, easy cleaning, permanent,
washable filter ensures a dirt-free air system
Extra large condenser coils, copper
tubing and raised lance aluminum fins
increase surface area for greater efficiency
Engineered fan runs quiet and saves money
Reliable and efficient
Copeland scroll compressor
Insulated blower compartment
for quieter operation
Evaporator coils with a
thermostatic expansion
valve consistently
monitors temperature
loads and regulates
refrigerant flow
Environmentally friendly
R-410A refrigerant does not
deplete the ozone layer.
Controls
Convenient service access
area, all standard mainte-
nance can be done here
High-pressure switch protects
the compressor for longer life
Easy access
refrigerant gauge ports
Intermittent ignition
system for quieter operation
Oil line heater keeps fuel oil warm and
flowing even on the coldest days
Pre-pruge, post-purge, positively closing
solenoid oil burner is safe and efficient
Quality controls and control
system for dependable, trouble-free service
Features and Benefits
Furnace
Foil-faced fiberglass insulation keeps
the heat inside, and the casing cool
Octatherm™ heat exchanger
retains combustion gases
longer for maximum heat
transfer
Heavy 16-gauge stainless
steel construction
Quiet, over-sized blower
for full air delivery and
maximum comfort
High-torque, variable speed
ECM motor for efficiency,
comfort and quiet operation.
Adjusts to provide optimal
air-flow for your home
Fiber refractory chamber
efficiently conducts more
heat to the heat exchanger
Corbel top maximizes
combustion and adds to the
life of the heat exchanger
by protecting it from the
direct flame
Flame retention, high
efficiency Beckett oil burner
Maintains optimum fuel
and air mixtures
Now with
R-410A Refrigerant
& ECM Motor!
4
Form No. PL81410021001-8/06-5Ms
Printed in the U.S.A.
© 2006 Thermo Products, LLC - North Judson, IN
Phone: 574-896-2133
www.thermopride.com
Specifications
Premiere Series Programmable ermostat
Perfect for a combination heating/
cooling system, the Premiere Series
Programmable ermostat maximizes
comfort while saving energy. Use up to
four different timed programs to save energy.
Accessories
ermo Pride offers a complete line of heating/cooling
equipment. e addition of accessories to your system
can provide greater comfort and a healthier indoor
environment.
UV Aire
Improve the indoor air quality of your home
by adding a UV Aire-Air Purifying System
to your home heating and cooling ductwork.
UV Aire silently and effectively reduces
airborne contaminates including molds, bacteria,
yeasts, dust mites, and viruses that can cause allergies.
MODEL
NUMBER
INPUT BTU/Hr
HIGH/LOW
OUTPUT
BTU/Hr
HIGH/LOW
AFUE %
HIGH/LOW
TEMP.
RISE °F
HIGH/LOW
COOLING
BTU/Hr
SEER COOLING
CFM
DIMENSIONS
(IN INCHES)
W x L x H
APPROX.
SHIPPING
WEIGHT
OPB24-80 105,000/85,000 85,000/68,000 80/82 70/60 22,800 14 800 47 x 47 x 34 610
OPB30-80 105,000/85,000 85,000/68,000 80/82 70/60 29,800 13 1000 47 x 47 x 34 610
OPB36-80 105,000/85,000 85,000/68,000 80/82 70/60 35,700 13 1200 47 x 47 x 34 610
