Sven Standard 306M User manual

www.sven.ﬁ

USER’S MANUAL

Multimedia Keyboard

standarD

306M

ENG

User’s Manual

CONTENTS

1. SPECIAL FEATURES ...............................................................................

2. PACKAGE CONTENTS ..............................................................................

3. SYSTEM REQUIREMENTS .........................................................................

4. INSTALLATION ........................................................................................

5. DESCRIPTION OF SHORTCUT KEYS FUNCTIONS ............................................

6. TROUBLE SHOOTING ...........................................................................

7. TECHNICAL SPECIFICATION .....................................................................

Technical support is on www.sven.ﬁ

Congratulations on your purchase of the Sven Multimedia Keyboard!

Please read this User’s Manual before using the unit and retain this User’s Manual in safe place for

future reference.

TRADEMARKS

All trademarks are the property of their legal holders.

NOTICE OF RESPONSIBILITY RESTRICTION

Despite the exerted eﬀorts to make this Manual more exact, some discrepancies may occur. The

information of this Manual is given on «as is» terms. The author and the publisher do not bear any

liability to a person or an organization for loss or damages which have arisen from the information,

contained in the given Manual.

UNPACKING

Unpack the device carefully. Make sure there are no accessories left in the box. Check up the device

for damages; if the product was damaged during transportation, address the ﬁrm which carried out

the delivery; if the product functions incorrectly, address the dealer at once.

standard

306M

ENG

Multimedia Keyboard

Notes:

• If there is a long pause in operation of the keyboard, it enters the Sleeping mode. To enter

working mode just press any button.

1. SPECIAL FEATURES

•Modern slim design

•Ukrainian and Russian layout

•High-quality membrane

•Compatible with Windows XP/Vista/7/8

•USB Interface

•Spill resistant

•Reduced noise level during operation, quiet and accurate keystroke

•9 shortcut keys for Internet, Multimedia etc.

•PC power supply control keys

2. PACKAGE CONTENTS

•Keyboard — 1 pc

•User’s Manual — 1 pc

•Warranty card — 1 pc

3. SYSTEM REQUIREMENTS

•Windows XP/Vista/7/8, MacOS 10.4 or higher, Linux

•Free USB port

4. INSTALLATION

•Connect the keyboard to an available USB-port of your PC.

•Installation of the keyboard is automatic after its connection to a USB port of the PC.

5. DESCRIPTION OF SHORTCUT KEYS FUNCTIONS

Оpen home web page

Refresh

Volume–

Volume+

Turn oﬀcomputer or

go into Sleeping mode

Start media player

Mute/turn on sound volume

Start default e-mail program

Open My Computer

ENG

User’s Manual standard

306M

6. TROUBLE SHOOTING

Problem

The keyboard is not working.

Problems with Sleep key

(Sleeping mode).

Problems with using additional

shortcut keys.

Solution

1. Make sure that BIOS of your PC has settings of USB cont-

roller for default operation.

2. Disconnect the keyboard from the PC and check connector

pins for possible damage. If there is no external damage found

and connector pins are OK, connect the keyboard to the PC

again.

3. Address your nearest authorized service center.

Make sure that power control has been activated both in BIOS

of the PC and Windows.

We recommend to address your nearest authorized service

center.

If none of the above methods can solve the problem, please seek professional advice at your nearest

service center. Never attempt to repair the product yourself.

Value

104 + 9 quick access keys

Eng/Rus/Ukr

Windows XP/Vista/7/8

USB

more than 20,000,000 strokes

475 × 31 × 180

740

Parameter, measurement unit

Number of keyboard keys

Keyboard layout

OS compatibility

Interface

Extrapolated mean life

Dimentions (W × H × L), mm

Weight, g

7. TECHNICAL SPECIFICATION

Notes:

• Technical speciﬁcation given in this table is supplemental information and can not give

occasion to claims.

• Technical speciﬁcation is subject to change without notice due to improvement of SVEN

production.

Модель: Standard 306M

Импортер вРоссии: ООО «СКАНДИТРЕЛ», 111024,

РФ, г. Москва, ул. Авиамоторная, д. 65, стр. 1.

Уполномоченная организация вРоссии: ООО «РТ-Ф»,

105082, г. Москва, ул. Фридриха Энгельса, д. 75,

стр. 5. Условия гарантийного обслуживания смот-

рите вгарантийном талоне или на сайте www.sven.ﬁ

Гарантийный срок: 12 мес. Срок службы: 2 года.

Производитель: «СВЕН ПТЕ. Лимитед»,

176 Джу Чиат Роуд, №02-02, Сингапур, 427447.

Произведено под контролем «Свен Скандинавия

Лимитед», 48310, Финляндия, Котка,

Котолахдентие, 15. Сделано вКитае.

Manufacturer: SVEN PTE. LTD., 176 Joo Chiat Road,

№02-02, Singapore, 427447. Produced under the

control of Oy Sven Scandinavia Ltd. 15, Kotolahdentie,

Kotka, Finland, 48310. Made in China.

® Registered Trademark of Oy SVEN

Scandinavia Ltd. Finland.

standarD

306M

Multimedia Keyboard
