Sven Comfort 3600 User manual

www.sven.ﬁ

USER’S MANUAL

Multimedia Keyboard

Comfort

3600

CONTENTS

1. SPECIAL FEATURES ...............................................................................

2. PACKAGE CONTENTS ..............................................................................

3. SYSTEM REQUIREMENTS .........................................................................

4. INSTALLATION ........................................................................................

5. DESCRIPTION OF QUICK ACCESS KEYS FUNCTIONS .......................................

6. TROUBLE SHOOTING ...........................................................................

7. TECHNICAL SPECIFICATION .....................................................................

ENG

User’s Manual

Technical support is on www.sven.ﬁ

Congratulations on your purchase of the Sven Multimedia Keyboard!

Please read this operation manual before using the unit and retain this operation manual in safe place

for future reference.

TRADEMARKS

All trademarks are the property of their legal holders.

NOTICE OF RESPONSIBILITY RESTRICTION

Despite the exerted eﬀorts to make this manual more exact, some discrepancies may occur. The

information of this manual is given on «as is» terms. The author and the publisher do not bear any

liability to a person or an organization for loss or damages which have arisen from the information,

contained in the given manual.

UNPACKING

Unpack the device carefully. Make sure there are no accessories left in the box. Check up the device

for damages; if the product was damaged during transportation, address the ﬁrm which carried out

the delivery; if the product functions incorrectly, address the dealer at once.

COMfort

3600

Open My Favorites

Go to search page

Play / Pause

Turn oﬀmedia player

Go to next web page

Go to previous web page

Start/Close Calculator

Open My Computer



Оpen web page

Start default e-mail program

Refresh

Go to previous media track

Go to next media track

Volume +

Volume -

Turn oﬀcomputer or go into

«sleeping mode»

ENG

1. SPECIAL FEATURES

•Modern design, superslim construction

•Built-in High-speed USB-Hub

•High-quality membrane

•Compatible with Windows 2000/XP/Vista/7

•USB Interface

•Reduced noise level during operation, quiet and accurate keystroke

•16 quick access keys for Internet, Multimedia etc

2. PACKAGE CONTENTS

•Keyboard — 1 pc

•User’s manual — 1 pc

•Warranty card — 1 pc

3. SYSTEM REQUIREMENTS

•Windows 2000/XP/Vista/7 or higher, MacOS 10.4 or higher, Linux

•Free USB port

4. INSTALLATION

•Connect the keyboard to an available USB-port of your PC.

•Installation of the keyboard is automatic after its connection to a USB port of the PC.

•The keyboard has a comfortable volume control located in the upper left corner of the device.

5. DESCRIPTION OF QUICK ACCESS KEYS FUNCTIONS

Notes:

• If there is a long pause in operation of the keyboard, it enters the Sleeping mode. To enter

working mode just press any button.

Multimedia Keyboard

ENG

User’s Manual COMfort

3600

6. TROUBLE SHOOTING

Problem

Кeyboard is not working.

Problems with Sleep key

(Sleeping mode).

Problems with using additional

quick access keys of keyboard.

Solution

1. Make sure that BIOS settings of your PC have settings of

USB controller for default operation.

2. Disconnect the keyboard from the PC and check connector

pins for possible damage. If there is no external damage found

and connector pins are OK, connect the keyboard to PC again.

3. Address your nearest authorized service center.

Make sure that power control has been activated both in BIOS

and Windows.

We recommend to address your nearest authorized service

center.

Value

105 + 16 quick access keys

present

Eng/Rus/Ukr

Windows 2000/XP/Vista/7

USB

more than 10 000 000

485 × 10 × 185

1,2

Parameter, measurement unit

Q-ty of keyboard keys

Volume control

Keyboard layout

OS required

Interface

Extrapolated mean life

Size of keyboard (W × H × L), mm

Weight of keyboard, kg

7. TECHNICAL SPECIFICATION

Notes:

• Technical speciﬁcation given in this table is supplemental information and cannot give

occasion to claims.

• Technical speciﬁcation is subject to change without notice due to improvement of SVEN

production.

If none of the above methods can not solve the problem, please seek professional advice at your

nearest service center. Never attempt to repair the product yourself.

Multimedia Keyboard

Модель:

COMFORT 3600

Импортер вРоссии: ООО «СКАНДИТРЕЛ»,

111024, РФ, г. Москва, ул. Авиамоторная, д. 65, стр. 1.

Уполномоченная организация вРоссии: ООО «РТ-Ф»,

105082, г. Москва, ул. Фридриха Энгельса, д. 75, стр. 5.

Условия гарантийного обслуживания смотрите в

гарантийном талоне или на сайте www.sven.ﬁ

Гарантийный срок: 12 мес.

Срок службы: 2 года

Произведено под контролем «Свен Скандинавия

Лимитед», 48310, Финляндия, Котка,

Котолахдентие, 15. Сделано вКитае.

Модель:

COMFORT 3600

Постачальник/імпортер вУкраїні: ТОВ «СВЕН Центр».

Київська область, м. Переяслав-Хмельницький,

вул. Героїв Дніпра, 31.

Призначення, споживчі властивості та відомості

про безпеку товару див. укерівництві зексплуатації.

Умови гарантійного обслуговування дивіться в

гарантійному талоні або на сайті www.sven.ﬁ

Гарантійний термін: 12 міс.

Строк служби: 2 роки

Товар сертифіковано/має гігієнічний висновок.

Шкідливих речовин не містить.

Зберігати всухому місці.

Виготовлено під контролем «Свен Скандинавія

Лімітед», 48310, Фінляндія, Котка, Котолахдентіє, 15.

Зроблено вКитаї.

Produced under the control of Oy Sven Scandinavia Ltd.

15, Kotolahdentie, KOTKA, Finland, 48310.

Made in China.

® Registered Trademark of Oy SVEN

Scandinavia Ltd. Finland.
