STI UB-2PN User manual

UB-2PN Universal 2”

Pneumatic Button

We protect the things that protect you.®

ADA

Compliant

ADA

Compliant

NOTES

It is important to read, understand and follow all instructions provided with

this product. It is the installer’s responsibility to comply with NFPA 70 &

101, NEC, mounting speciﬁcations according to ADA and other applicable

electrical codes.This switch is rated Type NM (Non-Monitored) for non-

emergency signaling. Not to be used in place of panic hardware. To avoid

electrical shock, DO NOT attempt to install this product when power is

on. ADA mounting compliance requires the operable part of the initiating

device shall not be less than 3 1/2 ft. (1.1m ) or greater than 4 1/2 ft. (1.37m)

above ﬁnished ﬂoor surface. After installation and testing are complete,

provide a copy of this manual to all personnel responsible for testing and

maintenance of this product.

* For access control installations, power for the UB-2PN must be supplied

by a power source Listed to UL294. When used for access control, this

device shall be used as a part of an access controlled egress door system.

It is up to the local AHJ to allow use of this device in place of an automatic

sensor. For higher security installations, lower time limits should be used.

SWITCH RATING

Independent Form “Z” contacts

Rated at: 10A @ 240 VAC

Operating Temp: 15° to 120°F (-9° to 49°C)

1,000,000 Cycles

- 2 -

.91 in.

(23mm)

1.47 in.

(38mm)

2 in.

(51mm)

3.22 in.

(82mm)

4.83 in.

(123mm)

DIE CAST PLATE

SPRING

PUSH BUTTON ACTUATOR

ACTUATOR CAP

2 in. BUTTON

ALIGN TAB ON ACTUATOR

WITH SLOT BUTTON.

TURN CLOCKWISE TO LOCK.

INSERT ASSEMBLY WITH

SPRING INTO PLATE.

REAR VIEW

1. TO CHANGE BUTTON COLOR AND ROUND MESSAGE

1. Choose button message and color. If same as existing, proceed to 2.

2. To remove push button actuator assembly, squeeze actuator tabs in direction of #1 arrows.

3. Push actuator through plate in direction of #2 arrow.

4. Align actuator cap to push button actuator. Align button slots to tabs on push button actuator.

5. Snap button onto push button actuator and rotate right to lock.

6. Insert spring into push button actuator.

7. Squeeze legs of push button actuator and align into die cast plate.

1. Remove LED circuit board.

2. Remove current message by pushing in and

down on tabs 1 and 2 with a small screwdriver.

If necessary, also push in and down on tabs 3

and 4. Once message is loose, remove from

the front of the plate.

3. Select new message and snap into place.

Blank plates are included to create your own

custom message.

2. CHANGE TOP MESSAGE

- 3 -

.91 in.

(23mm)

1.47 in.

(38mm)

2 in.

(51mm)

3.22 in.

(82mm)

4.83 in.

(123mm)

DIE CAST PLATE

SPRING

PUSH BUTTON ACTUATOR

ACTUATOR CAP

2 in. BUTTON

ALIGN TAB ON ACTUATOR

WITH SLOT BUTTON.

TURN CLOCKWISE TO LOCK.

INSERT ASSEMBLY WITH

SPRING INTO PLATE.

REAR VIEW

.91 in.

(23mm)

1.47 in.

(38mm)

2 in.

(51mm)

3.22 in.

(82mm)

4.83 in.

(123mm)

DIE CAST PLATE

SPRING

PUSH BUTTON ACTUATOR

ACTUATOR CAP

2 in. BUTTON

ALIGN TAB ON ACTUATOR

WITH SLOT BUTTON.

TURN CLOCKWISE TO LOCK.

INSERT ASSEMBLY WITH

SPRING INTO PLATE.

REAR VIEW

Power In

12–30 VDC/VAC

Safety Tech. Int’l Inc.

P/N UB-11. Ver 1.0

wwyy

DIFFUSER

TO SUPERVISED STATION

OR AUXILLARY DEVICE

SW1

SW2

COM

MAG LOCK

MESSAGE LENS PCB

12–24VDC

BUTTON LED

NORMAL POSITION BUTTON ACTIVATED

MAGNETIC LOCK

BUTTON LAMP

MESSAGE LAMP

OFF

COM

LED –

LED +

SWITCH 1

SWITCH 2

SCREWDRIVER

4.830 in.

(123mm)

3.220 in.

(82mm)

1.328 in.

(34mm)

.867 in.

(22mm)

UB-1L LED PCB

NYLON WASHER

SELF TAPPING SCREW

#6 - 32 x 1” OVAL

HEAD MACHINE SCREW

(2) PROVIDED

#8-10 7/8 in. ANCHOR

(4) PROVIDED

DRILL POINT PROVIDED TOP & BOTTOM

FOR 1/2 in. CONDUIT. DRILL AS NEEDED.

#6 x 1 1/4 in.

PHILLIPS PAN HEAD SCREW

(4) PROVIDED

DRILL (4)

3/16 in.

DIAMETER HOLES

KIT-71100A-* BACKBOX

*ADD ONE OF THE FOLLOWING:

R=red, B=blue, G=green,

W=white, Y=yellow

#6-32 x 1 in. PHILLIPS

OVAL HEAD MACHINE SCREW

18-8 SS(2) PROVIDED

DRILL OUT THE (4) MOUNTING

HOLES, ONE IN EACH CORNER,

USING 5/32 in. DRILL BIT

BACKBOX MUST BE MOUNTED

WITH ARROWS POINTING UP

.867 in.

(22mm) 1.575 in.

(40mm)

UB-1L LED PCB

TOP TAB

ACTUATOR

Power In

12–30 VDC/VAC

Safety Tech. Int’l Inc.

P/N UB-11. Ver 1.0

wwyy

CAP

BUTTON

SPRING

NEW DRAWING

3. INSTALL OR REMOVE CONTACT BLOCK

- 4 -

4.83 in.

(123mm)

3.22 in.

(82mm) .91 in.

(23mm)

1.47 in.

(38mm)

POWER IN

12-30 VDC/VAC

POWER IN

12-30 VDC/VAC

SQUEEZE TABS AND PUSH

ASSEMBLY INTO PLATE

SQUEEZE TABS

AND PUSH

ASSEMBLY

INTO PLATE

POWER IN

12-30 VDC/VAC

POWER IN

12-30 VDC/VAC

POWER IN

12-30 VDC/VAC

POWER IN

12-30 VDC/VAC

POWER IN

12-30 VDC/VAC

POWER IN

12-30 VDC/VAC

COM

LED –

LED +

SWITCH 1

SWITCH 2

SQUEEZE TABS

AND PUSH

ASSEMBLY

INTO PLATE

POWER IN

12-30 VDC/VAC

COM

MAG LOCK

UB-1L LED PCB

UL Listed

NORMAL POSITION BUTTON ACTIVATED

MAGNETIC LOCK

MESSAGE LAMP

OFF

12-24 VDC Power Supply

(BLACK) NC

(RED) NO

NC (GREEN)

NO (WHITE)

OFF

MAG LOCK

NC CONTACTS

NO CONTACTS

UB-1L LED PCB

UL Listed

12-24 VDC Power Supply

NORMAL POSITION BUTTON ACTIVATED

OFF

MAGNETIC LOCK

MESSAGE LAMP

UB-1L LED PCB

NYLON WASHER

SCREW

COUNTERCLOCKWISE

CLOCKWISE

TIMER RANGE ADJUSTMENT SCREW

ADJUSTMENT RANGE - 2 TO 60 SECONDS

TIMER FACTORY SET TO MINIMUM TIME

SETTING. TO INCREASE TIME, TURN

SCREW CLOCKWISE IN 1/4 TURN

INCREMENTS. WHEN CLOSE TO DESIRED

TIME, TURN SCREW IN VERY FINE

INCREMENTS TO DESIRED SETTING.

CAUTION: OVER-TIGHTENING MAY

CAUSE DAMAGE TO TIMER.

CONNECTION AND LEAD WIRE

COLOR CODE

SCREWDRIVER

4.83 in.

(123mm)

3.22 in.

(82mm) .91 in.

(23mm)

1.47 in.

(38mm)

POWER IN

12-30 VDC/VAC

POWER IN

12-30 VDC/VAC

SQUEEZE TABS AND PUSH

ASSEMBLY INTO PLATE

SQUEEZE TABS

AND PUSH

ASSEMBLY

INTO PLATE

POWER IN

12-30 VDC/VAC

POWER IN

12-30 VDC/VAC

POWER IN

12-30 VDC/VAC

POWER IN

12-30 VDC/VAC

POWER IN

12-30 VDC/VAC

POWER IN

12-30 VDC/VAC

COM

LED –

LED +

SWITCH 1

SWITCH 2

SQUEEZE TABS

AND PUSH

ASSEMBLY

INTO PLATE

POWER IN

12-30 VDC/VAC

COM

MAG LOCK

UB-1L LED PCB

UL Listed

NORMAL POSITION BUTTON ACTIVATED

MAGNETIC LOCK

MESSAGE LAMP

OFF

12-24 VDC Power Supply

(BLACK) NC

(RED) NO

NC (GREEN)

NO (WHITE)

OFF

MAG LOCK

NC CONTACTS

NO CONTACTS

UB-1L LED PCB

UL Listed

12-24 VDC Power Supply

NORMAL POSITION BUTTON ACTIVATED

OFF

MAGNETIC LOCK

MESSAGE LAMP

UB-1L LED PCB

NYLON WASHER

SCREW

COUNTERCLOCKWISE

CLOCKWISE

TIMER RANGE ADJUSTMENT SCREW

ADJUSTMENT RANGE - 2 TO 60 SECONDS

TIMER FACTORY SET TO MINIMUM TIME

SETTING. TO INCREASE TIME, TURN

SCREW CLOCKWISE IN 1/4 TURN

INCREMENTS. WHEN CLOSE TO DESIRED

TIME, TURN SCREW IN VERY FINE

INCREMENTS TO DESIRED SETTING.

CAUTION: OVER-TIGHTENING MAY

CAUSE DAMAGE TO TIMER.

CONNECTION AND LEAD WIRE

COLOR CODE

SCREWDRIVER

INSTALL

To attach, align tabs (as shown)

and gently snap top, then bottom.

Be sure to hear BOTH tabs snap

into place. Contacts can be rotated

180° if desired.

REMOVE

To remove, use a small

ﬂat blade screwdriver.

Position screwdriver

blade under tab

and gently rotate

screwdriver until tab

disengages. Repeat for

opposite tab.

CONTACT INFORMATION

CONTACT REMOVAL

DETAIL A

- 5 -

4. ATTACH POWER FOR MESSAGE LED (if desired - see drawing)

4.83 in.

(123mm)

3.22 in.

(82mm) .91 in.

(23mm)

1.47 in.

(38mm)

POWER IN

12-30 VDC/VAC

POWER IN

12-30 VDC/VAC

SQUEEZE TABS AND PUSH

ASSEMBLY INTO PLATE

SQUEEZE TABS

AND PUSH

ASSEMBLY

INTO PLATE

POWER IN

12-30 VDC/VAC

POWER IN

12-30 VDC/VAC

POWER IN

12-30 VDC/VAC

POWER IN

12-30 VDC/VAC

POWER IN

12-30 VDC/VAC

POWER IN

12-30 VDC/VAC

COM

LED –

LED +

SWITCH 1

SWITCH 2

SQUEEZE TABS

AND PUSH

ASSEMBLY

INTO PLATE

POWER IN

12-30 VDC/VAC

COM

MAG LOCK

UB-1L LED PCB

UL Listed

NORMAL POSITION BUTTON ACTIVATED

MAGNETIC LOCK

MESSAGE LAMP

OFF

12-24 VDC Power Supply

(BLACK) NC

(RED) NO

NC (GREEN)

NO (WHITE)

OFF

MAG LOCK

NC CONTACTS

NO CONTACTS

UB-1L LED PCB

UL Listed

12-24 VDC Power Supply

NORMAL POSITION BUTTON ACTIVATED

OFF

MAGNETIC LOCK

MESSAGE LAMP

UB-1L LED PCB

NYLON WASHER

SCREW

COUNTERCLOCKWISE

CLOCKWISE

TIMER RANGE ADJUSTMENT SCREW

ADJUSTMENT RANGE - 2 TO 60 SECONDS

TIMER FACTORY SET TO MINIMUM TIME

SETTING. TO INCREASE TIME, TURN

SCREW CLOCKWISE IN 1/4 TURN

INCREMENTS. WHEN CLOSE TO DESIRED

TIME, TURN SCREW IN VERY FINE

INCREMENTS TO DESIRED SETTING.

CAUTION: OVER-TIGHTENING MAY

CAUSE DAMAGE TO TIMER.

CONNECTION AND LEAD WIRE

COLOR CODE

SCREWDRIVER

CONTACT DIAGRAM

4.83 in.

(123mm)

3.22 in.

(82mm) .91 in.

(23mm)

1.47 in.

(38mm)

POWER IN

12-30 VDC/VAC

POWER IN

12-30 VDC/VAC

SQUEEZE TABS AND PUSH

ASSEMBLY INTO PLATE

SQUEEZE TABS

AND PUSH

ASSEMBLY

INTO PLATE

POWER IN

12-30 VDC/VAC

POWER IN

12-30 VDC/VAC

POWER IN

12-30 VDC/VAC

POWER IN

12-30 VDC/VAC

POWER IN

12-30 VDC/VAC

POWER IN

12-30 VDC/VAC

COM

LED –

LED +

SWITCH 1

SWITCH 2

SQUEEZE TABS

AND PUSH

ASSEMBLY

INTO PLATE

POWER IN

12-30 VDC/VAC

COM

MAG LOCK

UB-1L LED PCB

UL Listed

NORMAL POSITION BUTTON ACTIVATED

MAGNETIC LOCK

MESSAGE LAMP

OFF

12-24 VDC Power Supply

(BLACK) NC

(RED) NO

NC (GREEN)

NO (WHITE)

OFF

MAG LOCK

NC CONTACTS

NO CONTACTS

UB-1L LED PCB

UL Listed

12-24 VDC Power Supply

NORMAL POSITION BUTTON ACTIVATED

OFF

MAGNETIC LOCK

MESSAGE LAMP

UB-1L LED PCB

NYLON WASHER

SCREW

COUNTERCLOCKWISE

CLOCKWISE

TIMER RANGE ADJUSTMENT SCREW

ADJUSTMENT RANGE - 2 TO 60 SECONDS

TIMER FACTORY SET TO MINIMUM TIME

SETTING. TO INCREASE TIME, TURN

SCREW CLOCKWISE IN 1/4 TURN

INCREMENTS. WHEN CLOSE TO DESIRED

TIME, TURN SCREW IN VERY FINE

INCREMENTS TO DESIRED SETTING.

CAUTION: OVER-TIGHTENING MAY

CAUSE DAMAGE TO TIMER.

CONNECTION AND LEAD WIRE

COLOR CODE

SCREWDRIVER

4.83 in.

(123mm)

3.22 in.

(82mm) .91 in.

(23mm)

1.47 in.

(38mm)

POWER IN

12-30 VDC/VAC

POWER IN

12-30 VDC/VAC

SQUEEZE TABS AND PUSH

ASSEMBLY INTO PLATE

SQUEEZE TABS

AND PUSH

ASSEMBLY

INTO PLATE

POWER IN

12-30 VDC/VAC

POWER IN

12-30 VDC/VAC

POWER IN

12-30 VDC/VAC

POWER IN

12-30 VDC/VAC

POWER IN

12-30 VDC/VAC

POWER IN

12-30 VDC/VAC

COM

LED –

LED +

SWITCH 1

SWITCH 2

SQUEEZE TABS

AND PUSH

ASSEMBLY

INTO PLATE

POWER IN

12-30 VDC/VAC

COM

MAG LOCK

UB-1L LED PCB

UL Listed

NORMAL POSITION BUTTON ACTIVATED

MAGNETIC LOCK

MESSAGE LAMP

OFF

12-24 VDC Power Supply

(BLACK) NC

(RED) NO

NC (GREEN)

NO (WHITE)

OFF

MAG LOCK

NC CONTACTS

NO CONTACTS

UB-1L LED PCB

UL Listed

12-24 VDC Power Supply

NORMAL POSITION BUTTON ACTIVATED

OFF

MAGNETIC LOCK

MESSAGE LAMP

UB-1L LED PCB

NYLON WASHER

SCREW

COUNTERCLOCKWISE

CLOCKWISE

TIMER RANGE ADJUSTMENT SCREW

ADJUSTMENT RANGE - 2 TO 60 SECONDS

TIMER FACTORY SET TO MINIMUM TIME

SETTING. TO INCREASE TIME, TURN

SCREW CLOCKWISE IN 1/4 TURN

INCREMENTS. WHEN CLOSE TO DESIRED

TIME, TURN SCREW IN VERY FINE

INCREMENTS TO DESIRED SETTING.

CAUTION: OVER-TIGHTENING MAY

CAUSE DAMAGE TO TIMER.

CONNECTION AND LEAD WIRE

COLOR CODE

SCREWDRIVER

CONTACTS

One set NO and one set NC

- 6 -

6. CUSTOM LABELS

To create your own custom label, size to ﬁt in .48h x 2.23w as shown below.

Also available online at: www.sti-usa.com/ublabel

2.23 in.

.48 in.

5. MOUNT BUTTON

ONTO ELECTRICAL BOX

SWITCH INFORMATION

4.83 in.

(123mm)

3.22 in.

(82mm) .91 in.

(23mm)

1.47 in.

(38mm)

POWER IN

12-30 VDC/VAC

POWER IN

12-30 VDC/VAC

SQUEEZE TABS AND PUSH

ASSEMBLY INTO PLATE

SQUEEZE TABS

AND PUSH

ASSEMBLY

INTO PLATE

POWER IN

12-30 VDC/VAC

POWER IN

12-30 VDC/VAC

POWER IN

12-30 VDC/VAC

POWER IN

12-30 VDC/VAC

POWER IN

12-30 VDC/VAC

POWER IN

12-30 VDC/VAC

COM

LED –

LED +

SWITCH 1

SWITCH 2

SQUEEZE TABS

AND PUSH

ASSEMBLY

INTO PLATE

POWER IN

12-30 VDC/VAC

COM

MAG LOCK

UB-1L LED PCB

UL Listed

NORMAL POSITION BUTTON ACTIVATED

MAGNETIC LOCK

MESSAGE LAMP

OFF

12-24 VDC Power Supply

(BLACK) NC

(RED) NO

NC (GREEN)

NO (WHITE)

OFF

MAG LOCK

NC CONTACTS

NO CONTACTS

UB-1L LED PCB

UL Listed

12-24 VDC Power Supply

NORMAL POSITION BUTTON ACTIVATED

OFF

MAGNETIC LOCK

MESSAGE LAMP

UB-1L LED PCB

NYLON WASHER

SCREW

COUNTERCLOCKWISE

CLOCKWISE

TIMER RANGE ADJUSTMENT SCREW

ADJUSTMENT RANGE - 2 TO 60 SECONDS

TIMER FACTORY SET TO MINIMUM TIME

SETTING. TO INCREASE TIME, TURN

SCREW CLOCKWISE IN 1/4 TURN

INCREMENTS. WHEN CLOSE TO DESIRED

TIME, TURN SCREW IN VERY FINE

INCREMENTS TO DESIRED SETTING.

CAUTION: OVER-TIGHTENING MAY

CAUSE DAMAGE TO TIMER.

CONNECTION AND LEAD WIRE

COLOR CODE

SCREWDRIVER

4.83 in.

(123mm)

3.22 in.

(82mm) .91 in.

(23mm)

1.47 in.

(38mm)

POWER IN

12-30 VDC/VAC

POWER IN

12-30 VDC/VAC

SQUEEZE TABS AND PUSH

ASSEMBLY INTO PLATE

SQUEEZE TABS

AND PUSH

ASSEMBLY

INTO PLATE

POWER IN

12-30 VDC/VAC

POWER IN

12-30 VDC/VAC

POWER IN

12-30 VDC/VAC

POWER IN

12-30 VDC/VAC

POWER IN

12-30 VDC/VAC

POWER IN

12-30 VDC/VAC

COM

LED –

LED +

SWITCH 1

SWITCH 2

SQUEEZE TABS

AND PUSH

ASSEMBLY

INTO PLATE

POWER IN

12-30 VDC/VAC

COM

MAG LOCK

UB-1L LED PCB

UL Listed

NORMAL POSITION BUTTON ACTIVATED

MAGNETIC LOCK

MESSAGE LAMP

OFF

12-24 VDC Power Supply

(BLACK) NC

(RED) NO

NC (GREEN)

NO (WHITE)

OFF

MAG LOCK

NC CONTACTS

NO CONTACTS

UB-1L LED PCB

UL Listed

12-24 VDC Power Supply

NORMAL POSITION BUTTON ACTIVATED

OFF

MAGNETIC LOCK

MESSAGE LAMP

UB-1L LED PCB

NYLON WASHER

SCREW

COUNTERCLOCKWISE

CLOCKWISE

TIMER RANGE ADJUSTMENT SCREW

ADJUSTMENT RANGE - 2 TO 60 SECONDS

TIMER FACTORY SET TO MINIMUM TIME

SETTING. TO INCREASE TIME, TURN

SCREW CLOCKWISE IN 1/4 TURN

INCREMENTS. WHEN CLOSE TO DESIRED

TIME, TURN SCREW IN VERY FINE

INCREMENTS TO DESIRED SETTING.

CAUTION: OVER-TIGHTENING MAY

CAUSE DAMAGE TO TIMER.

CONNECTION AND LEAD WIRE

COLOR CODE

SCREWDRIVER

WARRANTY

ACCESSORIES

DESCRIPTION PART #

COLOR MATCH BACK BOX KIT KIT-71100A-*

* (R=red, B=blue, G=green, W=white or Y=yellow)

CUSTOM LABEL APPLIED TO UB-1CL-*

BLANK MESSAGE PLATES * (B=blue, G=green, W=white or Y=yellow)

2” LENS KIT FOR UNIVERSAL BUTTON UB-2LENS

CONTACT ASSEMBLY FOR UB-1 KIT-UB-1C

COVERS

BOPPER STOPPER STI-6518

UNIVERSAL STOPPER STI-13000 Series

STOPPER II®STI-1100 Series

– See website for complete cover details –

- 7 -

Printed in USA Inst. Sht. UB-2PN Button 07_15

2306 Airport Rd • Waterford, MI 48327, USA

Phone: 248-673-9898 • Fax: 248-673-1246

[email protected] • www.sti-usa.com

Taylor House • 34 Sherwood Road • Bromsgrove, Worcestershire • B60 3DR • England

Tel: +44 (0)1527 520 999 • Fax: +44 (0)1527 501 999 • [email protected] • www.sti-emea.com

WARRANTY

Three year guarantee against breakage of polycarbonate in normal use (one year on electro

mechanical and electronic components). Electronic warranty form a www.sti-usa.com/wc14.

WARNING: This product can expose you to chemicals including Dichloromethane, which is

known to the State of California to cause cancer, and Bisphenol A (BPA), which is known

to the State of California to cause birth defects or other reproductive harm. For more

information go to www.P65Warnings.ca.gov.

Table of contents

Popular Security System manuals by other brands

Inner Range

Inner Range Concept 2000 user manual

Climax

Climax Mobile Lite R32 Installer's guide

CADDX

CADDX NX-6 user manual

FBII

FBII XL-31 Series installation instructions

Johnson Controls

Johnson Controls PENN Connected PC10 Install and Commissioning Guide

Aeotec

Aeotec Siren Gen5 quick start guide

Blaupunkt

Blaupunkt SA 2700 quick start guide

IDEAL

IDEAL Accenta Engineering information

AJAX

AJAX DoubleButton user manual

Swann

Swann SW-P-MC2 Specifications

Ecolink

Ecolink Siren+Chime user manual

Digital Monitoring Products

Digital Monitoring Products XR150 user guide

EDM

EDM Solution 6+6 Wireless-AE installation manual

Highway Safety Group

Highway Safety Group EA401 user manual

Siren

Siren LED GSM operating manual

Detection Systems

Detection Systems 7090i Installation and programming manual

Se-Kure Controls

Se-Kure Controls MicroMini SK-4841 instructions

Siemens

Siemens FDM273 manual
