StarTech.com ST3504USB User manual

4 Port USB 1.1 3.5" Bay Hub

StarTech ID: ST3504USB

The StarTech.com Internal 4 port USB hub can be mounted into any 3.5 inch drive bay and will turn

1 USB port into 4 USB ports. This product will allow for the hassle free connection of USB devices such

as digital cameras, Zip drives, portable USB CD-R drives, USB file transfer cables and printers from

front access ports. The ST3504USB provides both self-powered and bus powered modes of operation, and

also provides per-port over current detection and protection.

Features

> Easily mounts internally into any available 3.5" drive bay

> Includes 1 internal USB cable for connection to the PC USB port

> Supports both Open Host Controller Interface (OHCI) and Universal Host Controller Interface (UHCI)

> Works with USB-compliant Windows and Mac computers

Specifications

> Color Beige

> Connector Types 1 - USB A Male

> Connector Types 4 - USB A Female

> LED Indicators 1 - Power

> LED Indicators 1 - Activity

> Number of Ports 4

> Carton Quantity 32

> Shipping (Package) Weight 0.57 lb [0.26 kg]

> Upstream (Root) Ports 1

> Downstream (Peripheral) Ports 4

> Output Voltage + 5V DC per port

> Output Current 500 mA (maximum) per port

> Connectors (Front) 4 x USB A female (Rear) 1 x USB B female

> Power Supplied by LP-4 power supply connector

> Industry Standards USB 1.1 compliant
