StarTech.com 5port System manual

5-port 10BaseT Micro Hub

StarTech ID: 5PORT

Running a small business? Need a small network? Want to add small workgroups to your existing network?

The StarTech.com 5 Port 10BaseT micro hub is just what you need. The 5PORT is small in size, with

plenty of potential for expandability. Features 5 UTP/STP ports with data transfer rates up

to 10 Mbits/sec, and the ability to be daisy chained with up to 4 other hubs when your needs grow.

Connected computers can be located up to 100 m away - perfect for any small office space. Backed by

StarTech.com’s 2-year warranty and FREE lifetime tech support.

Applications and Solutions

> For small networks with UTP/STP wiring and RJ-45 connectors

> Perfect for creating a small business network

> Great for adding small workgroups to an existing network

Features

> 2-year warranty and FREE LIFETIME technical support

> Allows data recovery without signal distortion

> Automatic bad port partitioning isolates problem-causing workstations

> Compact design sits discreetly on desktop or mounts easily to wall (screws included)

> Fully conforms to IEEE 802.3 10BaseT repeater specifications

> Includes AC power adapter (120V) and wall-mounting screws

> LED indicators provide Link/Activity, Collision, Power status

> Uplink port allows for cascade expansion

Specifications

> Auto MDIX No

> Color Beige

> Connector Types 5 - RJ45 Female

> Product Height 1.18 in [3 cm]

> Product Length 5.12 in [130 mm]

> Number of Ports 5

> Power Adapter Included Yes

> Carton Quantity 25

> Shipping (Package) Weight 1.06 lb [0.48 kg]

> Product Weight 3.18 oz [90 g]

> Product Width 39.37 in [1000 mm]

> Standards IEEE 802.3 10BaseT

> Data Transfer Rate 10Mbps

> Protocol CSMA/CD

> Maximum Distance 100m

> STP/UTP Ports (5) RJ-45

> Uplink Port (1) RJ-45

> LEDs (5) Link/Activity, Collision, Power

> Supported Hardware PCs, MACs, Sun, DEC, any 10Base2/T compatible

> Power Requirements 7.5V AC, 500mA

> Dimensions 130x90x30mm (4.7x3.0x1.2 in.)

> Weight 1kg

> Operating Environment 0~45 deg C, 10~80% Humidity

> Certifications FCC Class A, CE Mark
