StarTech.com ST121WHDST User manual

Manual Revision: 04/17/2014

For the most up-to-date information, please visit: www.startech.com

DE: Bedienungsanleitung - de.startech.com

FR: Guide de l'utilisateur - fr.startech.com

ES: Guía del usuario - es.startech.com

IT: Guida per l'uso - it.startech.com

NL: Gebruiksaanwijzing - nl.startech.com

PT: Guia do usuário - pt.startech.com

ST121WHDST

HDMI® Extender Over WHDI Wireless -

50ft (15m)

*actual product may vary from photos

Instruction Manual

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment generates,

uses and can radiate radio frequency energy and, if not installed and used in accordance with

the instructions, may cause harmful interference to radio communications. However, there

is no guarantee that interference will not occur in a particular installation. If this equipment

does cause harmful interference to radio or television reception, which can be determined by

turning the equipment o and on, the user is encouraged to try to correct the interference by

one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the receiver

is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only and do not

represent an endorsement of a product or service by StarTech.com, or an endorsement of the

product(s) to which this manual applies by the third-party company in question. Regardless

of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby

acknowledges that all trademarks, registered trademarks, service marks, and other protected

names and/or symbols contained in this manual and related documents are the property of

their respective holders.

Instruction Manual

Table of Contents

Product Diagram ....................................................................................1

Transmitter .................................................................................................................................................. 1

Receiver ........................................................................................................................................................ 2

Introduction............................................................................................3

Packaging Contents ................................................................................................................................. 3

System Requirements.............................................................................................................................. 3

Preparing Your Site ................................................................................4

Hardware Installation............................................................................4

Additional Operation............................................................................................................................... 5

Specications..........................................................................................7

Technical Support ..................................................................................8

Warranty Information............................................................................8

Instruction Manual

Product Diagram

Transmitter

Port Protecting

Cap

Sync Button

Male HDMI Port

(Hidden)

Mini USB B Power

Port (Power)

Instruction Manual

Receiver

Link LED (Wireless

Network Status)

Sync Button

Power

Adapter Port

HDMI Out

Port

Video LED (Video

Source Connected)

Stand

Power LED

USB Port

(Firmware updates only)

Instruction Manual

Introduction

Packaging Contents

• 1x Wireless HDMI Transmitter

• 1x Wireless HDMI Receiver

• 1x Remote Control

• 1x USB Cable (for Transmitter power)

• 1x Power Adapter (for Receiver)

• 1x Stand (for Receiver)

• 1x Right Angle HDMI Adapter (for Transmitter)

• 1x Manual

System Requirements

• HDMI enabled video source device (i.e. computer, Blu-ray Player)

• HDMI enabled display device (i.e. television, projector)

• Available AC electrical outlet Receiver

• USB power source for Transmitter

• HDMI cable (for Receiver to display)

Instruction Manual

Preparing Your Site

1. Determine where the remote display will be located and place/ mount the

display appropriately.

NOTE:

The maximum distance between the transmitter and the receiver is 15 meters (50ft). If the

wireless signal is obstructed by walls, or other interference the signal quality and maximum

distance will likely be reduced.

Ensure the Receiver Unit is situated near an available AC electrical outlet.

Hardware Installation

1. Installation of Transmitter Unit

a) Remove the Port Protecting Cap from the Transmitter Unit, and connect the Male

HDMI port on the Transmitter to the HDMI out port on your video source device (i.e.

Computer, Blu-ray Player).

NOTE: If it is more convenient the Right Angle HDMI Adapter can be added to angle

the Transmitter upward or downward.

b) Connect the USB cable from the Mini USB B Power Port (Power) on the

Transmitter unit to an available USB A power source.

2. Installation of Receiver Unit

a) Position the Receiver Unit near the video display (i.e. television, projector).

NOTE: If it is more convenient the Stand can be used to position the Receiver

Unit, vertically.

b) Connect the provided Receiver Unit power supply. The wireless network status

indicator (Link) will turn on after a successful wireless connection between both

units is established. This may take several seconds.

c) Connect the video source to the HDMI port on the rear panel of the Receiver Unit,

using a male/male HD cable (Not included).

d) The video source will now be displayed on the remote receiver.

NOTE: If video source is not displayed on the remote wireless Receiver, press the

sync button on the transmitter unit followed by the sync button on the Receiver

unit to resolve the issue.

Instruction Manual

Additional Operation

IR Remote Control

1 PWR Power On/O

2 Menu Open on screen display

(OSD) menu

3 Exit Close OSD menu / Cancel

connection

4 Source Switch transmitters (If more

than one is connected)

5 Next Source Switch transmitters (to next

logical source if more than

one is connected)

6 Pre Source Switch transmitters (to

previous logical source if

more than one is connected

7 Move Cursor

8 OK Select OSD option

9 Delete Delete a Transmitter

10 Add Add a Transmitter

11 Guest Power On/O

12 Input

Devices

Select to switch between

added Transmitters

NOTE: Before the remote control can operate, the battery protector must be removed

from the battery compartment. IR remote must be pointed at the receiver your display

is connected to.

Instruction Manual

Add Additional Video Transmitter Sources (Must have multiple

transmitting units)

By default the ST121WHDST’s transmitter and receiver units are paired together. If you

have more than one transmitter, this device you can add additional transmitters to

switch between sources.

1. Using the IR remote control, press MENU - > Select Add new Video Source

2. Please Activate Registration on Transmitter Unit will now appear on the display.

Physically return to the transmitter unit hold down the reset button on the

transmitter for 3 seconds to activate registration.

3. The additional transmitter is now registered. This action can be performed for up to

2 additional transmitters for a total of 3.

Remove add Video Transmitters (Must have multiple transmitting units)

4. Using the IR remote control, Press MENU - > Select Remove Video Source

5. Move the cursor and select the desired transmitter to be remove

Modify Video Source Name

To more easily distinguish between added transmitters, the generic hardware name,

given during the“Add additional Video Transmitter Sources”steps, can be modied.

1. Using the remote control, Press MENU - > Select Modify Video Source Name

2. Using the cursor select a name that better suits specic transmitter.

Instruction Manual

Specications

Max Distance 15m (50ft)

Maximum Digital Resolutions 1920x1080

Supported Resolutions

TV: 1080p, 1080i, 720p, 480p

PC: VGA(640X480), SVGA(800X600),

XGA(1024X768), SXGA(1280X1024)

Frequency 5.1-5.9HGHz
