StarTech.com IPUSB2HD3 User manual

HDMI Over IP Extender - 1080p

Product ID: IPUSB2HD3

This HDMI over IP extender lets you share an HDMI display or projector with the wireless or wired computer on your

network. With intuitive controls and effortless screen sharing, this extender makes it easier than ever for users to

collaborate and deliver presentations in boardrooms and office meetings.

The IP video extender supports resolutions up to 1080p and features two built-in USB ports, enabling you to connect

remote USB devices to your computer from your display. It’s the perfect solution for controlling a computer from

wherever the adapter is located.

The IP video extender helps you boost your office productivity, by making it easier for users to collaborate and

communicate. The included software lets you connect multiple computers and easily switch between which user is

sharing their content with the HDMI display, unlike some wireless video systems that are difficult to configure and

require users to disconnect and reconnect manually.

With this IP video extender, you can turn your HDMI television, monitor or projector into an IP display that can

connect to any Windows computer on your network, making it perfect for conference rooms and classrooms where

different ideas are shared by users who bring their own computers.

With a built-in USB hub, you can use your computer to access two remote USB devices at your remote display,

enabling you or your customers to control the computer from the remote location. Remote operation can be used to

create interactive digital signage, to engage your customers.

The IPUSB2HD3 is TAA compliant backed by a 2-year StarTech.com warranty with free lifetime technical support.

Note: This HDMI over IP video extender is intended for use on networks with dedicated bandwidth. See our FAQ for

further details.

Certifications, Reports and Compatibility

Applications

• Enable your employees or co-workers to share each other’s screens on a boardroom display

• Share information with clients at doctors offices and hospitals, while keeping the computer in a remote, secure

location

Features

• Collaborate with co-workers by using your network to easily switch between devices shown on a shared display

• Share video with a wireless or wired LAN connection using any Windows computer on your network

• Control the video-over-IP adapter, using the included software

• Built-in 2-port USB hub

• Supports resolutions up to 1080p

Hardware

Warranty

2 Years

Ports

Cabling

Cat 5e UTP or better

Audio

Yes

Chipset ID

DisplayLink - DL-195

Daisy-Chain

Performance

Maximum Data Transfer

Rate

USB - 480Mbps

Ethernet - 1000Mbps

Max Distance

100 m / 330 ft

Maximum Digital

Resolutions

1920x1080

Supported Resolutions

Widescreen (16/32 bit):

1920x1200, 1920x1080, 1680x1050, 1600x900, 1440x900, 1360x768,

1280x800, 1280x768, 1280x720

Standard(16/32 bit):

1600x1200, 1400x1050, 1280x1024, 1280x960, 1152x864, 1024x768,

800x600

Wide Screen Supported

Yes

Audio Specifications

Two channel stereo audio supported

General Specifications

This USB video adapter uses a DisplayLink family chipset. If you’re

connecting this device to a computer along with additional USB video

adapters or docking stations, please avoid using devices with a Trigger

or Fresco family chipset.

Connector(s)

Connector A

HDMI (19 pin)

USB Type-A (4 pin) USB 2.0

Connector B

USB B (4 pin)

RJ-45

Software

OS Compatibility

Windows 10, 8.1, 8, 7, Vista, XP

Power

Power Source

AC Adapter Included

Input Voltage

100 - 240 AC

Input Current

0.6 A

Output Voltage

5 DC

Output Current

2 A

Center Tip Polarity

Positive

Power Consumption (In

Watts)

Physical

Characteristics

Color

Black

Material

Aluminum

Product Length

4.0 in [10.2 cm]

Product Width

2.9 in [74 mm]

Product Height

0.9 in [24 mm]

Weight of Product

10.7 oz [304 g]

Packaging

Information

Package Length

5.6 in [14.3 cm]

Package Width

6.7 in [17 cm]

Package Height

2.6 in [66 mm]

Shipping (Package)

Weight

24.8 oz [702 g]

What's in the

Box

Included in Package

HDMI over IP extender

USB cable

CAT5 cable

universal power adapter (NA, EU, UK, ANZ)

mounting bracket

mounting screw kit

rubber foot set

quick start guide

*Product appearance and specifications are subject to change without notice.
