StarTech.com ICUSB232PRO User manual

ICUSB232PRO

Manual Revision: 01/26/2012

USB to RS232 Serial DB9 Adapter Cable

DE: Bedienungsanleitung - de.startech.com

FR: Guide de l'utilisateur - fr.startech.com

ES: Guía del usuario - es.startech.com

IT: Guida per l'uso - it.startech.com

NL: Gebruiksaanwijzing - nl.startech.com

PT: Guia do usuário - pt.startech.com

For the most up-to-date information, please visit: www.startech.com

*actual product may vary from photos

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital device,

pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This equipment generates, uses and can

radiate radio frequency energy and, if not installed and used in accordance with the instructions,

may cause harmful interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by turning the equipment

o and on, the user is encouraged to try to correct the interference by one or more of the following

measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is

connected.

• Consult the dealer or an experienced radio/TV technician for help.

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other protected names

and/or symbols of third-party companies not related in any way to StarTech.com. Where they

occur these references are for illustrative purposes only and do not represent an endorsement of

a product or service by StarTech.com, or an endorsement of the product(s) to which this manual

applies by the third-party company in question. Regardless of any direct acknowledgement

elsewhere in the body of this document, StarTech.com hereby acknowledges that all trademarks,

registered trademarks, service marks, and other protected names and/or symbols contained in this

manual and related documents are the property of their respective holders.

Instruction Manual i

Table of Contents

Introduction .......................................................................................................................................................1

Features...........................................................................................................................................................1

System Requirements ............................................................................................................................1

Contents.........................................................................................................................................................1

Installation............................................................................................................................................................2

Windows XP Installation.......................................................................................................................2

Connecting peripherals to the adapter......................................................................................2

Specications.....................................................................................................................................................3

Technical Support...........................................................................................................................................4

Warranty Information....................................................................................................................................4

Instruction Manual 1

Introduction

Thank for purchasing a StarTech.com USB-to-Serial Adapter with COM retention. Now you

can connect your serial devices like Personal Digital Assistants (PDA), modems, printers, or

scanners to your USB-enabled Mac or PC. With hassle-free connections and COM retention, your

conguration settings will never be lost.

Features

• Retains conguration settings in the event of a power loss or disconnection

• Adds a high-speed serial port to your USB-enabled Mac or PC

• Provides a 96-byte buer for each upstream and downstream transfer rate

• Transfers data at speeds up to 920 Kbits/sec

• Supports remote wakeup and power management control

System Requirements

• Operating System: Windows 98SE/ME/2000/XP/Vista/Server 2008 R2/7 (32/64-bit), or

Mac OS 10, or Linux

• An available USB port (USB 1.1 or higher)

Contents

This package should contain:

• 1 x USB to Serial Cable

• 1 x Driver CD

• 1 x Instruction Manual

Instruction Manual 2

Installation

To ensure a quick and easy device installation, please read through this section carefully and

complete each step in the order listed.

The following section identies how to install ICUSB232PRO on a computer running Windows XP.

Installation for other Windows operating systems (98SE, ME, 2000 etc.) are similar, if not identical.

Windows XP Installation

1. With your computer turned on, insert the driver disk into your CD-ROM/DVD-ROM drive.

2. Locate the driver installation package, titled 2303 Driver Installer.exe.

3. Once the InstallShield Wizard launches, it will indicate that it is ready to install the 2303

USB-to-Serial driver. Please click Next to continue.

4. Following installation, the InstallShield Wizard will notify you that the drivers have been

installed successfully. Please click on Finish to complete installation and close the installation

program.

5. Locate an available USB port on your computer. Connect the USB-to-Serial adapter.

6. Windows should detect the driver as a Prolic USB-to-Serial Comm Port. Prior to installing the

serial port, you may be notied that the device driver has not yet passed Windows XP Logo

compatibility. Click Continue Anyway. Windows will then start to install the driver for the

USB-to-Serial Comm Port.

7. When Windows has found the proper driver, click Next then Finish to complete the

installation.

Connecting peripherals to the adapter

1. With your computer turned on and the adapter already installed, plug the desired peripheral

into the adapter and apply power to the peripheral device.

2. If this is the rst time you are using the peripheral, consult the peripheral device’s installation

procedures and follow the on-screen prompts to install the device. If you have previously

installed the device on another of your computer’s RS-232 (COM) ports, the proper drivers

should be located and installed automatically.

NOTE: If you are connecting a modem under Windows 2000, you must specify it as a “Standard

Modem.”

Instruction Manual 3

Specications

Host Interface USB 1.1

Connectors 1 x USB Type A Male

1 x DB9 Serial Male

Maximum Data Transfer Rate 920 Kbits/sec

Chipset ID Prolic PL2303

Operating Systems Supported

Windows 98SE/ME/2000/XP/Vista/

Server 2008 R2/7 (32/-bit)

Mac OS 10, Linux

Certications (Regulatory and

other) FCC, CE, RoHS

Instruction Manual 4

Technical Support

StarTech.com’s lifetime technical support is an integral part of our commitment to provide

industry-leading solutions. If you ever need help with your product, visit www.startech.

com/support and access our comprehensive selection of online tools, documentation, and

downloads.

Warranty Information

This product is backed by a two year warranty.

In addition, StarTech.com warrants its products against defects in materials and workman-

ship for the periods noted, following the initial date of purchase. During this period, the

products may be returned for repair, or replacement with equivalent products at our dis-

cretion. The warranty covers parts and labor costs only. StarTech.com does not warrant its

products from defects or damages arising from misuse, abuse, alteration, or normal wear

and tear.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their of-

cers, directors, employees or agents) for any damages (whether direct or indirect, special,

punitive, incidental, consequential, or otherwise), loss of prots, loss of business, or any

pecuniary loss, arising out of or related to the use of the product exceed the actual price

paid for the product. Some states do not allow the exclusion or limitation of incidental or

consequential damages. If such laws apply, the limitations or exclusions contained in this

statement may not apply to you.

Hard-to-nd made easy. At StarTech.com, that isn’t a slogan. It’s a promise.

StarTech.com is your one-stop source for every connectivity part you need. From

the latest technology to legacy products — and all the parts that bridge the old and

new — we can help you nd the parts that connect your solutions.

We make it easy to locate the parts, and we quickly deliver them wherever they need

to go. Just talk to one of our tech advisors or visit our website. You’ll be connected to

the products you need in no time.

Visit www.startech.com for complete information on all StarTech.com products and

to access exclusive resources and time-saving tools.

StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology

parts. StarTech.com was founded in 1985 and has operations in the United States,

Canada, the United Kingdom and Taiwan servicing a worldwide market.
