Star Trac S-TRc Reference guide

Technical Procedure

Page 1

620-8637 Rev. F

S-TRc/8-TR/8-TRx Resistor Kit Install Instructions

Applies to: S-TRc, 8-TR ( 9-9191, 9-9192, 9-9194, 8-TRx (9-9201, 9-9202, 9-9204, 9-9251, 9-9252, 9-9254)

Required Tools:

• PHILLIPS SCREWDRIVER

• CABLE TIE FLUSH CUTTERS

Required Parts:

• 715-4286 “KIT, UPGRADE, RESISTOR, 100OHM, 8-TR/TRx”

If 715-4286 “KIT, UPGRADE, RESISTOR, 100OHM,

8-TR/TRx” arrives and the resistor is not assembled

to the dust shield, insert one clip into each end

of the resistor then use the supplied hardware to

mount the resistor to the dust shield

1. Remove the motor cover shroud, then using a

phillips screwdriver, remove the four (4) #10-

24 x 1/2” pan head screws securing the dust

shield to the frame, then remove the dust

shield.

2. Install the dust shield-resistor assembly back

into the treadmill, securing with the four (4)

screws removed in Step 1.

Technical Procedure

Page 2

620-8637 Rev. F

3. Plug the resistor cable into the MCB where

shown, location “8d.”

TO RESISTOR

4. Use the supplied cable tie to secure the re-

sistor wire to the upper-right stando on the

MCB. Be sure to clip any excess tail o of the

cable tie once secure.

TO RESISTOR

5. Update MCB with latest rmware, V1.0E or

newer.

For help with updating the MCB software, please

see doc # 637-1438

For the latest software please see https://support.

corehandf.com/Software/

6. Once the MCB and console have been updat-

ed, run a speed/motor calibration from the

service menu.

Console Code

LCD 0+2+OK, use hotbar + “OK” to

select “Motor Calibration.”

10”

Touchscreen

Tap top left corner, middle

screen, then top left corner

again. Code is 218, then enter

“Calibration and Setup.”

15”

Embedded

Vol+, CH+, 3 at the same time,

enter code“218”, then enter

“Calibration and Setup.”

This manual suits for next models

11

Other Star Trac Fitness Equipment manuals

Star Trac

Star Trac S-TBT User manual

Star Trac

Star Trac BICEP TRICEP MACHINES User manual

Star Trac

Star Trac E-ST User manual

Star Trac

Star Trac E-TBT 9-6080 User manual

Star Trac

Star Trac Leverage IP-L3005 User manual

Star Trac

Star Trac Instinct User manual

Star Trac

Star Trac Inspiration Strength IP-S1313 User manual

Star Trac

Star Trac Inspiration Strength IP-S4306 User manual

Star Trac

Star Trac eSPINNER Operating instructions

Star Trac

Star Trac Pro Stepper User manual

Star Trac

Star Trac Instinct Strength IL-2002 User manual

Star Trac

Star Trac eSPINNER Operating instructions

Star Trac

Star Trac TreadClimber Operating instructions

Star Trac

Star Trac 3100 Basic User manual
