Southern Enterprises HZ349500TX User manual

HZ349500TX Wall Mount Shelf W/Hook-

Dark Oak

HZ349600TX Wall Mount Shelf W/Hook-

Light Oak

Assembly Instructions

For assistance with assembly contact:

Southern Enterprises Inc.

Customer Service 1-800-633-5096

service@seidal.com

www.seidal.com

PO#

Tool List: 3/16" drill bit, drill, tape measure and pencil

WALL MOUNT SHELF W/HOOK

Parts List

Please check packaging for all parts and hardware before discarding. Unpack and lay parts on clean, padded

surface like carpet or blanket. Check that you have all parts indicated. Call customer service if hardware is missing.

Before beginning assembly, carefully study the diagrams below and sort your hardware according to the pictures.

Using the incorrect hardware will cause damage.

A Quantity

Of 2

plastic anchor

Dia: 1/4” x 1-3/16”L

B Quantity

Of 2

screw

Dia: 1/4“ x 1-1/2”L

C Quantity

Of 1

shelf

Quantity

of 1

leveler

Care and Cleaning Instructions:

Before using, wipe with a clean, dry cloth.

Periodically apply furniture wax to renew

the finish. Avoid rubbing or scratching the

surface with rough or abrasive objects.

For replacement parts or questions, please

call customer service at 1-800-633-5096.

Assembly Tool Required

No.2 Phillips Screwdriver

Not Included

NOTE: NO DRILLED HOLE OR PLASTIC ANCHOR

REQUIRED WHEN MOUNTING TO WOOD WALL.USE

SCREW ONLY. WE DO NOT SUPPLY HARDWARE FOR

MOUNTING ON CONCRETE WALLS.

Figur 1

Find a desired location and mark two locations

for the screws.

One screw (for each unit) must be attached

directly into a wall stud. Wall anchor is not

needed when mounting to wall stud.

Drill one marking 3/16" hole (for each unit).

Insert plastic anchor (A) into the hole on wall as

shown, you will need a hammer when doing this.

Using the phillips head screwdriver, install one

screw (B) into the anchor (A) and the other

screw installed into the stud. Turn the screws

(B) until there is a gap of approximately 13 mm

between the head of the screw and the wall as

shown.

Figur 2

Hang shelf (C) onto the screws and verify the

shelf (C) is resting securely on the mounting

screws (B).

Use a leveler to insure product is level.

Now your wall mount shelf w/hook is ready to

use.

Wall Mount Shelf W/Hook

Assembly Instructions

"The holes measurement on

wall must match with the

holes measurement on back

of the unit"

Please immediately examine this product carefully. Any request for missing parts or damage replacement

must be received within 90 days of your receipt of the product. Replacement, if available, will be honored

within this time frame.Parts will not be available for items arriving fully assembled. We do not recommend

modifying product(s) and we are not responsible for any damages due to product modification(s).

damages or missing parts are not reported within 90 days of your receipt, we are under no obligation to

provide parts or replacement merchandise.

Please contact Southern Enterprises at 800-633-5096 or in Dallas 972-869-0111/ 9am – 4pm Mon-Fri

Central time if you have product issues or email us at servi[email protected]. Please ask for customer service

representative for issues involving damages or replacement parts. Please ask for technical assistance

representative for any issues with product and assembly/construction.

Please contact the retailer that you purchased from for returns.

Customer Information

Name

Address

City/State/Zip Code

Phone Number

Please indicate where you purchased this item: Store/Website/Catalog

Please indicate color/size/style number:

Style No Parts Letter Parts Description Quantity

Needed

Customer Service 1-800-633-5096

service@seidal.com

Southern Enterprises, Inc.

600 Freeport Parkway, Suite 200

Coppell, Texas 75019

Parts Replacement Form

CAUTION

Max shelf load capacity is achieved by mounting screw into studs or cement walls.

If mounting to sheet rock (cavity wall) it is advisable to mount at least one screw

(without anchor) directly to a wall stud or studs. However do not leave either end of mounting

bracket unsupported by at least one anchor. For hollow wall mounting you can use any of the

holes in the back plate to suit where you require the mounting screws positioned.

This manual suits for next models
