Southern Enterprises Barksdale KA326400TX User manual

Page 1

PO：

KA326400TX

Barksdale 3pc Breakfast Set

Assembly Instructions

For assistance with assembly, contact:

Southern Enterprises, Inc.

Customer Service: 1-800-633-5096

[email protected]om

www.seifurniturestore.com

Quantity

of 1

Top Panel

Quantity

of 1

Right Side Frame

C Quantity

of 1

Center Frame

D Quantity

of 1

Left Side Frame

E Quantity

of 2

Seat Panel

F Quantity

of 4

Stool Side Frame

G Quantity

of 1

Bottom Panel

Quantity

of 2

Fixed Shelf

Quantity

of 1

Back Panel

Barksdale 3pc Breakfast Set

Parts List

Please check packaging for all parts and hardware before discarding. Unpack and lay parts on clean, padded surface

like carpet or a blanket. Check that you have all parts indicated. Call customer service if any hardware is missing.

Before beginning assembly, carefully study the diagrams below and sort your hardware according to the pictures.

Using the incorrect hardware will cause damage.

Page 2

J Quantity

of 2

Connecting bar

K Quantity

of 12

Stool Side rail

L Quantity

of 1

Drawer

M Quantity

of 2

Basket Frame

N Quantity

of 2

Basket Bottom Panel

1 Quantity

of 22

Short Bolt \Φ1/4"*1-1/4"L

2 Quantity

of 32

Long Bolt Φ1/4"*1-1/2"L

3 Quantity

of 24

Nut

4 Quantity

of 22

Flat Washer

5 Quantity

of 22

Spring Washer

6 Quantity

of 1

Allen Wrench

7 Quantity

of 24

Wood Plug

Care and Cleaning Instructions:

Before using, wipe with a clean, dry cloth. Avoid rubbing

or scratching the surface with rough or abrasive objects.

For replacement parts or questions, please call SEI

customer service at 1-800-633-5096.

Page 3

Figure 1

Line up Right Side Frame (B) and Center

Frame (C) to Fixed Shelves (H) and

Connecting Bars (J).

Figure 2

Secure Center Frame (C) and Right Side

Frame (B) to Fixed Shelves (H) using

Short Bolts (1), Spring Washers (5), and

Flat Washers (4).

Tighten Bolts (1) with Allen Wrench (6)

Barksdale 3pc Breakfast Set

Assembly Instructions

Page 4

Figure 3

Attach the assembled unit to Bottom

Panel (G),Left Side Panel (D),and Back

Panel (I) using Short Bolts (1), Spring

Washers (5), and Flat Washers (4).

Tighten Bolts (1) with Allen Wrench (6).

Figure 4

Line up the assembled unit with Top

Panel (A).

Page 5

Figure 5

Attach assembled unit to Top Panel (A)

using Short Bolts (1), Spring Washers (5),

and Flat Washers (4).

Tighten Bolts (1) with Allen Wrench (6).

Figure 6

Turn the assembled table over.

Insert pre-assembled drawer (L).

Make sure drawer smoothly slides in and

out.

Page 6

Figure 7

Open the folding Basket Frame (M).

Figure 8

Insert Basket Bottom panel (N) into

Basket Frame (M).

Page 7

Figure 9

Place the assembled baskets on Fixed

Shelves (H).

Figure 10

Now the table is ready to use.

Page 8

Figure 11

Attach Stool Side Frames (F) to Stool Side

Rails (K).

Insert Nuts (3) into pre-drilled holes on

Stool Side Rails (K).

Insert Long Bolts (2) through pre-drilled

holes on Stool Side Frames (F) into Nuts

(3).

Tighten Long Bolts (2) with Allen Wrench

(6).

Figure 12

Cover the holes on Stool Side Frames (F)

using Wood Plugs (7).

Page 9

Figure 13

Attach the assembled unit to Seat

Panel (E), using Long Bolts (2).

Tighten Bolts (2) with

Allen Wrench (6)

Figure 14

Turn the assembled stool over and it is

ready to use.

Repeat steps 11-14 for 2

stool.
