SA-40SE1

All

-

in

-One Soundbar

Key Features

Simple solution to enhance your HDTV sound

quality

Stylish design to match your 40-inch HDTV

Easy connection through a single wire

Easy operation with supplied remote control

Analog Input for connection to most HDTVs

Key Technologies

All Inclusive Sound Bar

With all the components for great sound built right in, there’s no need for a

subwoofer. So there’s no worry about connecting or placing a subwoofer.

Stylish design

The SA

-

40E1 is designed to complement 40

-

inch HDTVs.

Easy, one-

wire installation

Simply connect the supplied analog cable from the television to the bar

and plug the power cord into a wall outlet. No need to run other cables or worry about other

components.

Supplied Remote control

Easily control the operation of the Soundbar. Most universal remotes can

also be programmed to operate the sound bar because it uses standard remote codes.

1

Sony Electronics Inc.

•

16530 Via Esprillo

•

San Diego, CA 92127

•

1.800.222.7669

•

www.sony.com

Last Updated: 03/31/2011

SA-40SE1

All

-

in

-One Soundbar

Please visit the Dealer Source for current

information at www.sony.com/dealersource

Features

Amplifier/Receiver

General

AutoStandby: YES (5min/OFF)

PowerRequirement: 100V

-

240V, 50/60Hz

Power Stand By: 0.5W or Less

RemoteControl: RM

-

ANU102

Amplifier

(8Ohms 1kHz) THD: 10%

(8Ohms 20

-

20kHz)THD: 1% (FTC: 8 ohms,

300

-

20,000Hz)

8Ohms1kHz: 20W / ch

8Ohms 20

-

20kHz: 14W + 14W (FTC: 8 ohms,

300

-

20,000Hz)

Number of amp. channels: 2ch

Sound Field Program :GAME/VOICE:

YES

Sound Field Program :STANDARD: Yes

Front Speaker

General

Front Grille Material:

Punching Metal

Front Grille Type: Fixed

MagneticallyShielded: NO

SpeakerSystem: Passive Radiator type

SpeakerUnit: 65mm x 2

Wooferunit: 65mm x 4

Specifications

Amplifier/Receiver

Inputs and Outputs

Analog Audio In(Inc TV CEC)/Out(excl.

tuner)/TV(CEC): 1 Analog Input

Front Speaker

Audio Specs

Impedance: 8 ohms

Weight and Measurements

Dimensions (Approx.)

CartonOuter: 39.4 x 6.1 x 4.6 in (1001 x

156 x 117mm)

Main Unit (WxHxD): 37.1 x 3.1 x 2.6 in

(942.4 x 80 x 67.7mm)

Weight (Approx.)

Carton: 7.2 lbs. (3.3kg)

MainUnit: 4.8 lbs. (2.2kg)

General

Form

ExtensionBracket(Optional):

WS

-

40SE1B

UPC Code:

027242812772

1.Checktheowner

’

smanualforyourremoteforSony audio control

compatibility.

©2011Sony Electronics Inc. Allrightsreserved.Reproduction in whole or

inpart without written permissionisprohibited.Sony, Sony make.believe

andtheir respective logos aretrademarksofSony. All other trademarks

aretrademarksoftheirrespectiveowners.Featuresandspecifications

aresubject to change without notice. Non

-

metricweights andmeasures

areapproximate and may vary.
