Sony HAP-Z1ES User manual

HDD AUDIO PLAYER HAP-Z1ES

About the HDD AUDIO PLAYER

Features of the HDD AUDIO PLAYER [1]

Playable audio file formats [2]

How to make and enter selections [3]

How to input characters [4]

System requirements for computers connected to the HDD AUDIO PLAYER [5]

Required network environment [6]

Supplied accessories [7]

Supported applications

HAP Music Transfer [8]

HDD Audio Remote [9]

Help for HAP Music Transfer/HDD Audio Remote [10]

Preparations

What you need to do before starting to use the HDD AUDIO PLAYER [11]

Prep 1. Connecting an amplifier [12]

Prep 2. Connecting to a network with a LAN cable (only when using a wired LAN) [13]

Prep 3. Turning on the HDD AUDIO PLAYER [14]

Prep 4. Configuring the initial settings of the HDD AUDIO PLAYER [15]

Prep 5. Configuring the settings of a computer to use HAP Music Transfer [16]

Operating the HDD AUDIO PLAYER from your smartphone or tablet (using HDD Audio

Remote) [17]

Preparing the remote control [18]

Connections

Connecting to a computer [19]

Connecting an amplifier [20]

Connecting an external hard disk drive [21]

Connecting an external CD drive [22]

Network connections (wired LAN)

Required network environment [23]

Connecting the HDD AUDIO PLAYER to a network automatically [24]

Connecting the HDD AUDIO PLAYER to a network manually [25]

Wi-Fi network connections (wireless LAN)

Required network environment [26]

Selecting a Wi-Fi (wireless LAN) connection method [27]

Method 1. Setting up a network connection using the WPS push button configuration method

[28]

Method 2. Setting up a network connection by selecting an access point [29]

Method 3. Setting up a network connection by adding a new access point [30]

Method 4. Setting up a network connection using the (WPS) PIN code configuration method

[31]

Playing music

Playable audio file formats [32]

Transferring music files from a computer to the HDD AUDIO PLAYER [33]

Playing music files [34]

Deleting music files from the HDD AUDIO PLAYER (when operating on the HDD AUDIO

PLAYER) [35]

Deleting music files from the HDD AUDIO PLAYER (when using the HAP Music Transfer)

[36]

Playing tracks using SensMe™ channels [37]

Playing tracks in playlists [38]

Selecting playback methods [39]

Registered music file information [40]

Standby modes [41]

Internet radio

Listening to the TuneIn Internet radio programs [42]

Music copy from a CD

Copying music files from a CD [43]

Useful functions

Copying music files from a CD [44]

Deleting music files from the HDD AUDIO PLAYER (when operating on the HDD AUDIO

PLAYER) [45]

Deleting music files from the HDD AUDIO PLAYER (when using the HAP Music Transfer)

[46]

Using the DSEE function [47]

Adding tracks to “Favorites” [48]

Playing tracks in “Favorites” [49]

Operating an external amplifier using the remote control or the dedicated application [50]

Registered music file information [51]

Parts and controls

Front panel [52]

Rear panel [53]

Remote control [54]

Home screen [55]

Playback screen [56]

Playback Options screen [57]

Play Queue screen [58]

Settings menus

Network Settings [59]

HDD Settings [60]

Audio Settings [61]

Amp Control Settings [62]

System Settings [63]

Network Update [64]

Backups

Backing up data [65]

Backing up music files in the HDD AUDIO PLAYER to your computer (for Windows) [66]

Backing up music files in the HDD AUDIO PLAYER to your computer (for Mac) [67]

Returning backup music files from your computer to the HDD AUDIO PLAYER (for Windows)

[68]

Returning backup music files from your computer to the HDD AUDIO PLAYER (for Mac) [69]

Specifications/Notes

Playable audio file formats [70]

Design and specifications [71]

Software updates for the HDD AUDIO PLAYER [72]

When registering music files to the HDD AUDIO PLAYER [73]

Precautions on heat buildup [74]

Notes on the internal hard disk drive [75]

Precautions for use [76]

Disclaimer regarding services offered by third parties [77]

Trademarks [78]

Troubleshooting

General [79]

Sound/playback [80]

Connections [81]

Hard disk drive [82]

Help for HAP Music Transfer/HDD Audio Remote [83]

If the problem is not solved [84]

Dealing with problems/Inquiries

Standby modes [85]

Forced shutdown of the HDD AUDIO PLAYER [86]

Messages for protecting the HDD AUDIO PLAYER [87]

Other messages [88]

When a notification about a new version of the software appears on the display [89]

Customer support websites [90]

[1] About the HDD AUDIO PLAYER

Features of the HDD AUDIO PLAYER

Thank you for purchasing this HDD AUDIO PLAYER.

The HDD AUDIO PLAYER is a music player that allows you to transfer and store High-

Resolution Audio files, such as DSD, and various other formats of audio files, such as MP3 and

FLAC, from your computer and enjoy playback of high quality audio sources.

You can install a specially designed application on your smartphone or tablet and operate the

HDD AUDIO PLAYER remotely.

The HDD AUDIO PLAYER has the following features:

Transferring various audio files to the HDD AUDIO PLAYER

You can transfer various types of audio files to the hard disk drive of the HDD AUDIO PLAYER

from a computer connected to the same network (*).

Storing audio files in the HDD AUDIO PLAYER allows you to enjoy high quality sound playback

that is not affected by the network environment.

*You can use HAP Music Transfer, an application designed for HDD AUDIO PLAYER, to

automatically transfer audio files from your computer to the HDD AUDIO PLAYER.

High quality audio playback

The HDD AUDIO PLAYER can play High-Resolution Audio files such as 192 kHz/24 bit, 96

kHz/24 bit, or DSD (Direct Stream Digital) audio files.

Furthermore, the HDD AUDIO PLAYER gives a more natural and expansive sound to

compressed audio files, such as MP3s, by restoring high-frequency sound and almost

imperceptible sound during fade-out, which are usually lost by compression.

Easy operation with your smartphone or tablet

The HDD Audio Remote application is available to for even easier operation of the HDD AUDIO

PLAYER.

You can install the application on your smartphone or tablet.

[2] About the HDD AUDIO PLAYER

Playable audio file formats

The following audio file formats can be played on the HDD AUDIO PLAYER.

DSD (DSF, DSDIFF)

Extensions: .dsf, .diff

Sampling frequency: 2.8224 MHz, 5.6448 MHz

LPCM (WAV, AIFF)

Extensions: .wav, .aif, .aiff

Sampling frequency: 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz, 176.4 kHz, 192 kHz

Quantization bits: 16 bits, 24 bits, 32 bits (*)

32-bit playback is only possible for files in WAV format.

FLAC

Extensions: .flac, .fla

Sampling frequency: 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz, 176.4 kHz, 192 kHz

Quantization bits: 16 bits, 24 bits

ALAC

Extensions: .m4a

Sampling frequency: 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz, 176.4 kHz, 192 kHz

Quantization bits: 16 bits, 24 bits

MP3 (MPEG-1/2 Audio Layer-3)

Extensions: .mp3

Bit rate: 64 kbps - 320 kbps

Sampling frequency: 44.1 kHz, 48 kHz

Quantization bits: 16 bits

AAC (MPEG-4 AAC-LC, HE-AAC)

Extensions: .m4a, .mp4, .3gp

Bit rate: 64 kbps - 320 kbps

Sampling frequency: 44.1 kHz, 48 kHz

Quantization bits: 16 bits

WMA (WMA, WMAPro, WMA Lossless)

Extensions: .wma, .asf

Bit rate: 32 kbps - 320 kbps (WMA, WMAPro)

Sampling frequency: 44.1 kHz, 48 kHz (WMA)

Sampling frequency: 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz (WMAPro, WMA Lossless)

Quantization bits: 16 bits (WMA, WMAPro)

Quantization bits: 16 bits, 24 bits (WMA Lossless)

ATRAC (ATRAC3, ATRAC3plus, ATRAC Advanced Lossless)

Extensions: .oma, .aa3

Bit rate: 48 kbps - 352 kbps (ATRAC3plus)

Bit rate: 132 kbps (ATRAC3)

Sampling frequency: 44.1 kHz

Quantization bits: 16 bits

Note

No copy protected files in any of the above formats can be played. If you transfer copy

protected files to the HDD AUDIO PLAYER, music information of the copy protected files will

appear in gray and you will not be able to select it.

Only 2ch files in the above formats are supported.

Playing formats other than those above may produce noise or even damage the speakers if

played at a high volume.

[3] About the HDD AUDIO PLAYER

How to make and enter selections

The basic operations of the HDD AUDIO PLAYER are as follows:

1. Turn the jog dial left or right to select an item.

2. Press ENTER to enter the selection.

Hint

To display the Home screen, press the HOME button.

To go back to the previous screen, press the BACK button.

[4] About the HDD AUDIO PLAYER

How to input characters

When the character input screen appears during operations, enter characters as follows:

A: Character input area

B: Keyboard area

C: OK

1. Turn the jog dial left or right to select a character in the keyboard area, and then press

ENTER to enter the selection.

2. Repeat the operations in step 1 to enter a text string.

3. When the character input is done, turn the jog dial left or right to select [OK], and then

press ENTER.

Hint

To change the type of characters, use the character type selection button on the bottom left

of the keyboard area.

The character type changes in the order of [ABC] (capitals), [abc] (lower case) and [@./]

(symbols).

To move the cursor left and right in the character input area, use / .

To delete a character, move the cursor to the right of the character you want to delete, and

then use [BS] on the keyboard area.

[5] About the HDD AUDIO PLAYER

System requirements for computers connected to the HDD

AUDIO PLAYER

HAP Music Transfer, an application that copies audio files from your computer to the HDD

AUDIO PLAYER, can be used in the following system environment:

Windows 10 Home

Windows 10 Pro

Windows 8.1

Windows 8

Windows 8 Pro

Windows 7 Starter Service Pack 1 or later

Windows 7 Home Basic Service Pack 1 or later

Windows 7 Home Premium Service Pack 1 or later

Windows 7 Professional Service Pack 1 or later

Windows 7 Ultimate Service Pack 1 or later

Windows Vista Home Basic Service Pack 2 or later

Windows Vista Home Premium Service Pack 2 or later

Windows Vista Business Service Pack 2 or later

Windows Vista Ultimate Service Pack 2 or later

Mac OS X 10.6, 10.7, 10.8, 10.9, 10.10, 10.11 (*)

*Intel CPU models, 64 bit (10.6, 10.7, 10.8, 10.9, 10.10, 10.11) and 32 bit (10.6, 10.7) are supported.

Screen resolution

1,024 x 768 pixels or higher

Note

One of the above operating systems should be installed by default. Upgraded operating

systems and multi-boot environments are not supported.

We do not guarantee operation for all computers even if they meet the above system

requirements. Furthermore, the following systems are not supported:

Personally constructed computers or operating systems

Upgraded operating systems

Multi-boot environments

Multi-monitor environments

[6] About the HDD AUDIO PLAYER

Required network environment

You can transfer audio files from your computer to the HDD AUDIO PLAYER by connecting

both to the same network, either by a wired or wireless connection.

Confirm the supported environment described below.

Note

You need to connect the HDD AUDIO PLAYER to a network that can access the Internet if

Other manuals for HAP-Z1ES

Table of contents

Other Sony Media Player manuals

Sony

Sony Walkman NWZ-E453K User manual

Sony

Sony Walkman NW-E303 User manual

Sony

Sony SMPU10 - USB Media Player User manual

Sony

Sony NSZ-GS8 User manual

Sony

Sony SMPU10 - USB Media Player User manual

Sony

Sony SMP-NX20 User manual

Sony

Sony DSX-M55BT User manual

Sony

Sony DSX-S210X User manual

Sony

Sony CE-P13 User manual

Sony

Sony NSZ-GS7 User manual

Sony

Sony NW-A100TPS User manual

Sony

Sony DSX-A410BT User manual

Sony

Sony DSX-A410BT User manual

Sony

Sony Network Walkman NW-E403 User manual

Sony

Sony Walkman NW-ZX2 User manual

Sony

Sony TEP-TX5 Instruction Manual

Sony

Sony WALKMAN NWZ-A15 User manual

Sony

Sony XAV-W650BT User manual

Sony

Sony Walkman NWZ-E443K User manual

Sony

Sony HAP-Z1ES User manual

Sony

Sony VAIO Music Clip MC-S50 User manual

Sony

Sony NW-HD5 Operating Instructions (English) User manual

Sony

Sony NW-A100TPS User manual

Sony

Sony NSZ-GS8 User manual

Popular Media Player manuals by other brands

Visual Land

Visual Land Impulse quick start guide

limHD

limHD 200i user manual

Transcend

Transcend DMP10 user manual

Philips

Philips GoGear Muse SA2MUS08 quick start guide

Fantec

Fantec MM-HDRL user manual

Dune HD

Dune HD Duo 4K user manual

IAdea

IAdea HMP-505S user manual

Camos

Camos MMS-1000 manual

Energy

Energy 75 Series user manual

Z3 Technology

Z3 Technology DME-03 user guide

Meicheng

Meicheng HD-1080K12 user manual

DENAFRIPS

DENAFRIPS ARCE owner's manual

Topaz

Topaz CMS Media Player Hardware user manual

InFocus

InFocus LightCast user guide

IconBiT

IconBiT XDS1003D user manual

Quanmax

Quanmax QDSP-2090 Series user guide

Samsung

Samsung MP-80S Owner's instructions

Trigon Elektronik

Trigon Elektronik CHRONOLOG operating manual
