Sony NVA-CU3 Operation and maintenance manual
© 2006 Sony Corporation Printed in Thailand 2-681-710-01 (1)
NVA-CU3
Notice for supplied car battery adapter XA-DC2
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
−Reorient or relocate the receiving antenna.
−Increase the separation between the equipment and receiver.
−Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
−Consult the dealer or an experienced radio/TV technician for help.
You are cautioned that any changes or modifications not expressly
approved in this manual could void your authority to operate this
equipment.
Car battery adapter XA-DC2
Maintenance
Fuse replacement
When replacing the fuse in the car battery adapter, be sure to use one
matching the amperage rating stated on the original fuse. If the fuse
blows, check the power connection and replace the fuse. If the fuse
blows again after replacement, there may be an internal malfunction.
In such a case, consult your nearest Sony dealer.
Warning
Never use a fuse with an amperage rating exceeding the one supplied
with the unit as this could damage the unit.
Specifications
Operating temperature: 5 – 45 ºC (41 – 113 ºF)
Power requirements: car cigarette lighter socket DC 12 V
(negative ground)
Fuse (2.5A)
To tighten
To remove
