Smeg LBW710IT User manual
EN -2-
CHAPTER-1: BEFORE USING THE APPLIANCE
•Correct Usage 6-7
• Generalwarnings 8-9-10-11
• Safetywarnings 12-13-14-15-16-17
• PackagingandEnvironment 18
• SavingsInformation 19
CHAPTER-2: OVERVIEW OF YOUR DEVICE
• GeneralAppearance 20-21
• Specications 22
CHAPTER-3: INSTALLATION
• Removingtransportationsafetyscrews 23-24
• AdjustingAdjustableStays 25-26-27
• Electricalconnection 28
• Waterinlethoseconnection 29-30
• Waterdischargeconnection 31
CHAPTER-4: INTRODUCTION OF CONTROL PANEL 32
• Detergentdrawer 33-34
• Programmeknob 35
• Electronicdisplay 36-37
CHAPTER-5 PRELIMINARY PREPARATION FOR LAUNDERING
• Separatinglaundries 38-39
CONTENTS
EN-3-
• Puttinglaundriesinthemachine 40
• Addingdetergentintomachine 41
• Operatingyourmachine 42-43-44
• AuxiliaryFunctions 45-46-47-48-49-50-51-52
• Childlock 53
• Cancellingprogramme 54
• Finishingprogramme 55
CHAPTER-6: PROGRAM TABLE 56-57-58-59-60-61-62-63
CHAPTER-7: MAINTENANCE AND CLEANING OF YOUR MACHINE
• Warning 64
• Waterinletlters 65
• Pumplter 66-67
• Detergentdrawer 68
• Liquiddetergentapparatus 68
CHAPTER-8: FLUSH STOPPER / BODY / DRUM 69
CHAPTER-9: TROUBLE SHOOTING 70-71-72-73-77
CHAPTER-10: AUTOMATIC FAULT WARNINGS AND
WHAT TO BE DONE 75
CHAPTER-11: PRACTICAL INFORMATION 76-77-78-79
• How to read the energy label and saving energy 80-81
• Disposal of your old machine 82
CONTENTS
EN-4-
CHAPTER -1: BEFORE USING THE APPLIANCE
(SAFETY WARNINGS)
Operatingvoltage/frequency:
(V/Hz)(220-240)V~/50Hz;
Totalcurrent(A):10
Waterpressure(Mpa)
Maximum:1Mpa/Minimum:0.1Mpa
Totalpower(W):2200
Maximumdrylaundrycapacity(kg):7
Donotinstallyourmachineonacarpet
orsuchgroundsthatwouldpreventthe
ventilationofitsbase.
Theapplianceisnotintendedforuseby
people(includingchildren)withreduced
physical,sensoryormentalcapabilities,or
lackofexperienceandknowledgeunlessthey
havebeengivensupervisionorinstruction
concerninguseoftheappliancebyaperson
responsiblefortheirsafety.
Childrenshouldbesupervisedtoensurethat
theydonotplaywiththeappliance.
Callthenearestauthorizedservicefora
replacementifthepowercordmalfunctions.
EN-5-
Useonlythenewwaterinlethosecoming
withyourmachinewhilemakingwaterinlet
connectionsofyourmachine.Neveruseold,
usedordamagedwaterinlethoses.
Thisappliancecanbeusedbychildren
agedfrom8yearsandaboveand
personswithreducedphysical,sensoryor
mentalcapabilitiesorlackofexperience
andknowledgeiftheyhavebeengiven
supervisionorinstructionconcerninguseof
theapplianceinasafewayandunderstand
thehazardsinvolved.
Childrenshallnotplaywiththeappliance.
Cleaningandusermaintenanceshallnotbe
madebychildrenwithoutsupervision.
Note:Forsoftcopyofthisusermanual,
pleasecontactfollowingaddress:
“[email protected]”.Inyour
e-mail,pleaseprovidethemodelnameand
serialnumber(20digits)whichyoucannd
ontheappliancedoor.
CHAPTER -1: BEFORE USING THE APPLIANCE
(SAFETY WARNINGS)
EN -6-
CHAPTER -1: BEFORE USING THE APPLIANCE
(CORRECT USAGE)
• Denitely read the user’s manual.
• Your machine is designed to be used
domestically. Commercial use will
cause your warranty to be cancelled.
•Keepyourpetsawayfromyourmachine.
•Pleasecheckthepackagingofyourmachine
beforeinstallation,andtheoutersurfaceaf-
terthepackageisopened.Donotoperate
damagedmachinesormachineswithopened
package.
•Haveyourmachineinstalledonlybyauthor-
izedservice.Anyinterferencetoyourmachine
byanyoneotherthanauthorizedservices
shallcauseyourwarrantytobevoid.
•Theapplianceisnotintendedforuseby
people(includingchildren)withreducedphys-
ical,sensoryormentalcapabilities,orlackof
experienceandknowledgeunlesstheyhave
beengivensupervisionorinstructionconcern-
inguseoftheappliancebyapersonresponsi-
blefortheirsafety.Childrenshouldbesuper-
visedtoensurethattheydonotplaywiththe
appliance.
EN -7-
CHAPTER -1: BEFORE USING THE APPLIANCE
(CORRECT USAGE)
•Useyourmachineonlyforlaundriesthathave
beenspeciedassuitableforwashingbythe
manufacturer.
• Before operating the washing machine, re-
move the 4 transportation screws and rubber
spacers from the back of the machine. If the
screws are not removed, it may cause heavy
vibration, noise and product malfunction,
(voiding the guarantee).
•Yourmachineisnotcoveredunderwarranty
forfaultscausedbyanykindofexternalfactors
(pesticides,re,etc.).
•Pleasedonotthrowawaythisusermanual;
keepitforfuturereference.Youorsomebody
elsemightneeditinthefuture.
Note:Machineryspecicationsmayvaryde-
pendingontheproductpurchased.
EN -8-
•Thenecessaryambienttemperatureforyour
machine’sidealoperationis15-25°.
•Frozenhosescantearandexplode.Inregions
wheretemperatureisbelowzero,ambienttem-
peraturemightendangerthesafeoperationof
electroniccard.
•Pleaseensurethattheclothesyouwillplace
inyourmachinedonotcontainanyforeignsub-
stances(nail,needle,coins,lighter,matches,clip
etc.)intheirpockets.Theseforeignsubstances
candamageyourmachine.
•Beforestartingtouseyourmachine,youmay
callthenearestauthorizedserviceandrequest
free-of-chargehelpforinstallation,operationand
useofyourmachine.
• It is recommended to perform the rst
washing operation in 90˚ Cotton programme
and without laundry by inserting ½ scale
of detergent in 2nd compartment of the
detergent drawer.
CHAPTER -1: BEFORE USING THE APPLIANCE
(GENERAL WARNINGS)
EN -9-
•Asdetergentorsoftenerexposedtoairfora
longtimemaycauseresidues,putyourdeter-
gentorsoftenerinthedetergentdraweratthe
beginningofeverywashing.
•Itisadvisedthatyouunplugyourmachine
andclosethewaterinlettapifyouwillnotuse
yourmachineforalongtime.Also,leavingthe
doorofyourmachinewillpreventtheforma-
tionofbadodorsduetohumidity.
•Somewatermightbeleftinyourmachine
afterthetrialsandtestsconducteddueto
QualityControlprocedures.Thiswillnotdam-
ageyourmachine.
•Rememberthatpackagingmaterialsofyour
machinemaybedangerousforchildren.
•Keepthepackagingmaterialsinaplace
wherechildrencannotreachordisposeof
themappropriately.
•Usepre-washprogramsonlyforverydirty
laundry.
CHAPTER -1: BEFORE USING THE APPLIANCE
(GENERAL WARNINGS)
EN -10-
•Neveropenthedetergentdrawer
whentheapplianceisrunning.
•Incaseofanybreakdown,unplug
theappliancerstandthenturn
thetapoff.Donotattempttorepair
byyourself,alwayscontactforau-
thorizedserviceadvice.
•Theamountoflaundryyouputin
yourwashingmachineshouldnot
exceedthemaximumamountindi-
cated.
•Neverforcethedoortoopen
whenthemachineisrunning.
•Washingouryclothesinyour
machinedamagesthemachine.
Donotwashouryclothesinyour
machine.
CHAPTER -1: BEFORE USING THE APPLIANCE
(GENERAL WARNINGS)
