Silvercrest 275419 User manual

IAN 275419

SHIATSU NECK MASSAGE CUSHION SSMN 2 B3

SHIATSU NECK MASSAGE CUSHION

Operating instructions

SHIATSU-NACKENMASSAGE-

HÖRNCHEN

Bedienungsanleitung

GB/IE/NI Operating instructions Page 1

DE/AT / CH Bedienungsanleitung Seite 15

Before reading, unfold the page containing the illustrations and familiarise yourself with all functions of

the device.

Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen Sie sich anschließend mit allen

Funktionen des Gerätes vertraut.

















GB│IE│NI │ 1 ■

SSMN 2 B3

Index

Introduction ...................................................2

Intended use ..................................................2

Items supplied .................................................3

Disposal of the packaging.................................................. 3

Appliance description ...........................................4

Technical data .................................................4

Safety instructions .............................................5

What is Shiatsu massage? .......................................7

Operation ....................................................7

Connection ............................................................. 7

Fitting .................................................................. 8

Inuse.................................................................. 8

After the massage ........................................................ 9

Cleaning......................................................9

Cleaning the removable cover............................................... 9

Cleaning the appliance ...................................................10

Storage .....................................................10

Troubleshooting ..............................................11

Disposal of the appliance.......................................11

Disposal of the mains adapter...................................11

Kompernass Handels GmbH warranty............................12

Service................................................................ 13

Importer ............................................................... 13

■ 2 │ GB│IE│NI SSMN 2 B3

Introduction

Congratulations on the purchase of your new appliance.

You have clearly decided in favour of a quality product. These operating instruc-

tions are a part of this product. They contain important information in regard to

safety, use and disposal. Before using the product, familiarise yourself with all of

these operating and safety instructions. Use the product only as described and

only for the speciﬁed areas of application. Retain these instructions for future

reference. In addition, pass these documents on, together with the product, to

any future owner.

This documentation is copyright protected.

Any copying or reproduction of it, including as extracts, as well as the reproduction

of images, also in an altered state, is only permitted with the written authorisation

of the manufacturer.

Intended use

This appliance is intended for massaging the neck and shoulders of people.

This appliance is intended solely for personal use in the domestic sector, it is not

to be used for medical or commercial applications and may not substitute for

medical treatment. The appliance is designed for use in dry indoor rooms. It is

not intended for use in the medical/therapeutic or commercial ﬁelds.

WARNING

Risks from unintended use!

Risks can be engendered if this appliance is used for purposes not intended for

it and/or for other types of use.

► Use the appliance exclusively for its intended purposes.

► Pay heed to the procedures described in these operating instructions.

GB│IE│NI │ 3 ■

SSMN 2 B3

NOTICE

► Risks can be engendered if this appliance is used for purposes not intended

for it and/or for other types of use. Use the appliance exclusively for its

intended purposes. Observe the procedures described in these operating

instructions. Claims of any kind for damage resulting from unintended use,

incompetent repairs, unauthorised modiﬁcation or the use of unauthorised

spare parts will not be accepted. The operator alone bears liability.

Items supplied

The appliance is delivered with the following components as standard:

▯ Shiatsu Neck Massage Cushion

▯ Mains adapter

▯ Operating Instructions

1) Remove all parts of the appliance and the operating instructions from the

carton.

2) Remove all packaging material.

3) Clean all parts of the appliance as described in the section "Cleaning".

NOTICE

► Check the contents to ensure that everything is present and for signs of

visible damage.

► If the delivery is not complete or something is damaged due to defective

packaging or through transportation contact the Service Hotline (see

chapter Service).

Disposal of the packaging

The packaging protects the appliance from transport damage. The packaging

materials are selected from the point of view of their environmental friendliness

and disposal technology and are therefore recyclable.

The recirculation of packaging into the material circuit saves on raw material and

reduces the amount of waste generated. Dispose of packaging material that is

no longer needed as per the regionally established regulations.

NOTICE

► If possible, preserve the appliance's original packaging during the warranty

period so that, in the event of a warranty claim, you can package the appli-

ance appropriately for its return.

■ 4 │ GB│IE│NI SSMN 2 B3

Appliance description

Massage heads

Removable cover

Hand loops

Socket

“Warmth” button

“Massage” button

“On/Oﬀ” button

Mains adapter

Connection plug

Technical data

Mains adapter 

Type YJS010A-1201000B

Input voltage 100 - 240 V ~, 50/60 Hz

Current consumption 350 mA

Output voltage 12 V

Output current 1000 mA

Protection class II /

Polarity

Appliance

Input voltage 12 V

Current consumption 1 A

GB│IE│NI │ 5 ■

SSMN 2 B3

Safety instructions

RISK OF ELECTRIC SHOCK

► Operate the appliance only with the supplied power adapter

YJS010A-1201000B.

► Connect the appliance only to correctly installed and

earthed mains power sockets. Ensure that the rating of the

local power supply tallies completely with the details given

on the rating plate of the appliance.

► Ensure that the power cable cannot become wet or damp

while the appliance is in operation. Place it such that it cannot

be crushed or damaged.

► Keep the power cable away from hot surfaces.

► Do not perform any repairs on the appliance. All repairs must

be performed by our Customer Services or by qualiﬁed

personnel.

► Always remove the plug from the mains power socket before

you clean the appliance.

► Do not use the appliance in damp areas, such as in the bath-

room.

► To avoid risks, arrange for defective plugs and/or cables to

be replaced at once by qualiﬁed technicians or our Customer

Service Department.

► Do not insert needles or other sharp objects into the appliance.

■ 6 │ GB│IE│NI SSMN 2 B3

WARNING! RISK OF INJURY!

► Do not use an external timing switch or a separate remote

control system to operate the appliance.

► This appliance may be used by children aged 8 over and by

persons with reduced physical, sensory or mental capabilities

or lack of experience and knowledge, provided that they are

under supervision or have been told how to use of the ap-

pliance safely and are aware of the potential risks. Children

must not play with the appliance. Cleaning and user mainte-

nance tasks must not be carried out by children unless they

are supervised.

► Do not massage infants, young children, helpless persons or

animals with the appliance.

► NEVER use the appliance if you have injuries or pain in the

neck or cervical spine.

► Stop treatment with the appliance IMMEDIATELY if you feel

it to be uncomfortable or painful.

► During use the appliance has a hot surface. Individuals who

are insensitive to heat must take care when using the appliance.

► Do not use the appliance on swollen, burnt, inﬂamed, diseased

or injured regions of the skin and body areas. If in doubt,

obtain medical advice before using the appliance.

► Ensure that your ﬁngers or other body parts do not come

between the rotating massage heads. Risk of crush injuries!

GB│IE│NI │ 7 ■

SSMN 2 B3

WARNING! RISK OF INJURY!

► The appliance may not be used in the face (e.g. eyes), on

the throat, feet or other sensitive body parts.

► During use do not cover the appliance (with a pillow, blanket,

etc.). NEVER use the appliance in the vicinity of petrol or

other inﬂammable materials.

WARNING - PROPERTY DAMAGE!

Use the appliance only indoors.

► Operate the appliance only with the supplied power adapter.

What is Shiatsu massage?

Shiatsu (shi = ﬁnger, atsu = pressure) is a form of massage developed in Japan,

which itself emerged from traditional Chinese medicine. Shiatsu massage consists

of a relaxing and powerful massage with ﬁngers, thumbs or palms. This massager

mimics the movements of shiatsu massage with the help of rotating massage

heads .

Operation

Connection

1) Connect the connection plug on the mains adapter with the socket 

on the appliance.

2) Connect the mains adapter into a mains power socket.
