Shuttle MVP User manual
Page 1
MVP
Page 1
Congratulations on the purchase of your new Shuttle MVP. Shuttle equipment has been trusted by physical therapists and
sports training facilities around the globe for almost half a century. It is our mission to deliver the finest quality exercise
devices with superior customer service. We welcome you as a valued customer.
For your safety it is crucial that you read this manual thoroughly and understand the equipment before use. If you have any
questions about your Shuttle MVP you can give us a call at +1 (800)-334-5633, email us at
[email protected], or chat with us via live chat at www.shuttlesystems.com (Monday-Friday, 8 am to 5
pm Pacific Time).
WELCOME TO THE FAM
IMPORTANT SAFETY INFORMATION ..…………………………………………………………….…………. 1
PERSONAL SAFETY ……….……………………………………………………………………….……………. 1
SPECIFICATIONS ………………………………….………………………………………..…………..……….. 2
IDENTIFICATION OF THE MANUFACTURER …………………………………………………….……….…. 2
ASSEMBLY OF THE MVP ………………………………………………………..……………………………… 3
- ASSEMBLY OF MVP RAILS…………………………………………………………..4
- ATTACHING THE HEAD-END STAND………………………………………..……5
- ATTACHING THE KICKPLATE STRUCTURE………………………………………..6
- INSTALLING THE REBOUND STOP BLOCKS……………………………………..7
- INSTALLING THE ELASTICORDS…………………………………………….……..8
- INSTALLING THE HANDLEBARS………………………………………………….10
- INSERTING THE CARRIAGE……………………………………………………….11
- ATTACHING THE KICKPLATE BOARD……………………………………………13
- ATTACHING THE HEADREST……………….………………………………..……14
- ATTACHING THE BACKREST EXTENSION PAD………….……………………..15
USING THE PRODUCT ………………………………………………………………………….………….….. 16
MAINTENANCE AND CARE ……………………………………………………………………….….……… 17
WARRANTY….…………………………………………………………..……………………..…………..…… 19
SUPPORT… ………………………………………………………………………………………….………….. 20
TABLE OF CONTENTS
Page 1
Read all safety information before operating the MVP. It is the owner’s responsibility to ensure that users are aware of
all warnings and precautions.
Please read all instructions before using the product. These instructions were written to ensure the safety of the user and to
protect the product.
You should always consult with a physician before beginning a new fitness plan.You are advised to investigate and inform
yourself about any health related actions and choices you make.
Use caution when mounting and dismounting.
Do not allow children to have unsupervised access to the product.
Keep pets away from the MVP at all times.
Perform regular maintenance for optimal performance and longevity. To ensure safety, the MVP must be checked for wear
and damage on a regular basis.
Replace any damaged or worn parts immediately. Do not use the MVP until the repair is performed.
Use only original parts from the manufacturer. Changes or modifications to this unit not expressly approved by Shuttle
Systems could void the warranty.
The MVP is for indoor use only. Do not store the MVP outdoors, near water, or at high humidity levels.
Fully assemble the product before using it. Check the product before each use. Do not continue to use the product if it is
not working properly.
The MVP provides anchor slots in the kickplate structure and head-end stand to enable securing the machine to the floor.
Use of this product is subject to medical examination to assess your suitability to the type of workout exercise you intend to
perform, and in compliance with the conditions for use laid down by Shuttle Systems.
Persons suffering from certain physical conditions may only use the product under the strict supervision of a doctor with
specific qualifications.
Before starting any workout, make sure your position on the product is correct, paying attention to any components that
may obstruct use.
Plan the workout according to your physical characteristics and state of health, beginning with less demanding workloads.
Do not overexert yourself or work to exhaustion. Incorrect or excessive exercise may cause physical harm or sudden death.
If you feel any pain or abnormal symptoms, stop your workout immediately and consult your physician.
Wear proper workout clothing and shoes during training; do not wear loose clothing. Tie long hair back. Keep hands,
shoelaces, garments, and accessories away from moving parts. Do not insert objects into openings on the equipment.
When using the MVP, other people must remain at a safe distance.
Do not use the product when children or pets are present.
The person in charge of the gym must explain proper and improper use of the equipment to users.
Assemble and use the product only on a solid and flat surface.
Keep the product in good working condition. If you see signs of wear, contact Shuttle Technical Support Service.
Do not attempt any maintenance work on the product other than the operations described in the user manual.
IMPORTANT SAFETY INFORMATION
PERSONAL SAFETY
Page 2
Dimensions: 31”W x 109”L
Floor Space Required: 3’W x 10’L
Carriage Capacity: 450 lbs
Max Resistance:
Classic: 12-300 lbs*
Pro: 12-500 lbs*
Elite: 12-650 lbs*
Total Elasticords:
Classic: (8) Total Elasticords
(1) 12 lb elasticord
(7) 25 lb elasticords
Pro: (12) Total Elasticords
(1) 12 lb head-end elasticord
(7) 25 lb head-end elasticords
(4) 25 lb foot-end elasticords
Elite: (16) Total Elasticords
(1) 12 lb head-end elasticord
(7) 25 lb head-end elasticords
(8) 25 lb foot-end elasticords
KICKPLATE
HANDLEBARS
HEADREST
BACKREST
HEAD-END
ELASTICORDS
FOOT-END
ELASTICORDS
ROM HANDLE
KNEE
BUMPERS
BUTT
PAD
KNURLED
KNOBS
ANCHOR
SLOTS
HEAD-END
SLOTTED PLATE
FOOT-
END
SLOTTED
PLATE
A - Manufacturer’s name and contact
B - Item number
C - Description of product
D - Serial number
A
B
D
C
* Elasticords are rated starting resistance, but will gain resistance up to 40% in extension
SPECIFICATIONS
IDENTIFICATION OF MANUFACTURER
Page 3
Assembly of the MVP requires two people
Keep in mind that the following images pertain to just one of the four available MVP models, your parts may appear slightly
different than those in the included images but the required steps remain the same.
Tools Needed: 7/16 inch socket and/or wrench, 1/2 inch socket and/or wrench, 9/16 inch socket and/or wrench.
The MVP will come in four boxes:
1. Head-End Stand
- Head-End Stand
- Connector Plate
- Parts Bags (1-7)
- User Manual
-Accessories
3. Kickplate Structure
- Kickplate Structure
- Backrest Extension Pad &
Bib Headrest
- Elasticords (small box)
- Kickplate Board
2. MVP Rails
- Two 9 foot Rails
4. Carriage
- MVP Carriage
- Three Handlebars
It is important to become familiar with the expressions “foot-end” and “head-end”, as they indicate orientation for the
various steps and structures.
Head-End Stand
(Head-End)
Kickplate Structure
(Foot-End)
ASSEMBLY OF THE MVP
Page 4
ASSEMBLING THE MVP RAILS WITH THE CONNECTOR PLATE
STEP 1
ITEMS REQUIRED
MVP Rails
Connector Plate
Parts Bag #1
1. Arrange the MVP rails parallel to each other on the floor, upright, hole patterns matching and labels facing outward.
(Pic 1.1)
2. Insert the connector plate (sticker facing up) and align the holes of the plate with those located midway along the rails.
(Pic 1.2)
3. Insert the four 5/16” x 1 3/4” long button head bolts from outside the MVP rails and through the connector plate.
4. Hand tighten a 5/16” lock nut onto each bolt end on the inside of the connector plate.
1.1
1.2
ASSEMBLY OF THE MVP (STEP 1)
Page 5
ATTACHING THE HEAD-END STAND
STEP 2
ITEMS REQUIRED
Head-End Stand
Carriage Box
Parts Bag #2
1. Set the assembled MVP rails, right side up, atop the carriage box, allowing the head-end of the rails to overhang the
box at least 18”. (Pic 2.1)
2. Place the head-end of the MVP rails to the inside of the head-end stand vertical tabs, and slide the stand forward until
the holes of each structure are aligned. Once aligned, move the box to where the head-end stand can rest against it.
3. Locate the lower bolt holes (one on each side) of the head-end stand. Insert the 5/16”x 5/8” button head bolts from
outside the head-end stand and through the MVP rails. Hand tighten the 5/16” lock nuts. (Pic 2.2)
4. Locate the upper bolt holes (two on each side) of the head-end stand. Insert the 5/16”x 5/8” button head bolts from
inside the rails and out through the head-end stand. Hand tighten the 5/16” lock nuts. (Pic 2.3)
2.1
2.2
2.3
Head-End
ASSEMBLY OF THE MVP (STEP 2)
Page 6
3.1
3.2
3.3
Flange
ATTACHING THE KICKPLATE STRUCTURE
STEP 3
ITEMS REQUIRED
Kickplate Structure
Parts Bag #3
1. Remove the plywood attached to the bottom and back of the kickplate structure. Dispose of the plywood along with the
nuts and bolts that held it together.
2. Position the foot-end of the MVP rails to the inside of the kickplate structure. Align the holes and place the MVP rail
ends on the flange of the kickplate structure. (Pic 3.1)
3. From outside the kickplate structure, insert the 3/8”x 2” socket head bolts into the bottom eight holes (four on each
side) and through the rails. Gently rock the stand to align the remaining four exterior bottom holes and insert the bolts.
Once all eight bolts are in, place the 3/8” washers, then the lock nuts, onto the bolt ends and hand tighten. (Pic 3.2)
4. From the inside of the MVP rails, insert the 5/16”x 5/8” button head bolts into the top four parallel bolt holes (two on
each side) and out through the kickplate structure. Add the lock nuts to the bolt ends and hand tighten. (Pic 3.3)
5. Tighten all the bolts of the assembled pieces including the connector plate, head-end stand, and kickplate structure.
ASSEMBLY OF THE MVP (STEP 3)
Page 7
INSTALLING THE REBOUND STOP BLOCKS
STEP 4
ITEMS REQUIRED
Remaining Parts in Parts Bag #2 & #3
Parts Bag #4
1. Remove the two plastic rebound stop blocks from Parts Bag #4 and unscrew the lock nuts from the bolts.
2. With the bumper cones facing toward the head-end stand, insert the bolts of the plastic rebound blocks into the MVP
rails and through the kickplate structure. Tighten down fully. (Pic 4.1)
3. Place the nut caps from Parts Bag #4 on the rebound stop blocks and the nut caps from Parts Bag #3 over the lower lock
nuts and upper 4 lock nuts on the kickplate structure. (Pic 4.2 & 4.3)
4. Place the nut caps fro Parts Bag #2 over the 4 lock nuts on the outside of the head-end stand. (Pic 4.4)
4.1
4.2
4.3
4.4
ASSEMBLY OF THE MVP (STEP 4)
