Shinco SPS5-08C User manual
SPS5-08C / SPS5-10C
Portable Air Conditioner
User’s Manual
Thanks for choosing this high quality portable air conditioner.
Please read the Manual carefully before operation. In case of any
problem, please contact professional maintenance personnel in time.
CONTENT
User Knowledge
Matters Needing Attention ..................................1
Important Safety Tips
Special Warning
Main Parts and Components
Control Panel and Remote Controller
Placement and Installation
Product Introduction
Product Operation
Operation Method
Clean and Maintenance
Common Failures and Diagnosis
Drainage Method
Maintenance
Intelligent Error Detection
Trouble-shooting
Machine Parts Parameters
Fuse Parameter
Machine Dimensions
.........................................3
...............................................6
...............................7
...................8
..................................9
............................................14
..............................................15
.................................................15
................................18
.............................................18
.............................................19
........................................19
Service Information.................................20
1
USER KNOWLEDGE
The meaning of this user manual is shown bellow.
MATTERS NEEDING ATTENTION
Please prohibit such operation for your health and safety with your family.
For the sake of health and safety of your family, you must do the following.
Do not stack items around the
machine so as not to impede the
air exchange.
This machine is for household use
only.
This machine is for indoor use only
Please place it in dry environment.
Do not place heavy objects on the
machine to avoid damage to the
machine.
2
稀释剂
For your health, please don not drink
condensed water discharged from
machine.
Please unplug the power supply if
the machine is not used for a long
time.
Non professionals should not
disassemble or repair the machine
without authorization.
Do not operate the unit with wet hands
or in a humid environment.
Please wipe the machine with a soft
cloth. Do not use wax, thinner or
irritant detergent.
Please clean the filter regularly and
recommend cleaning once every
two weeks.
3
IMPORTANT SAFETY TIPS
Please not use damaged power
cord or power cord plug, do not
insert power cord into loose socket.
Do not damage or use damaged or
unknown type of power cord. Please
ensure that the voltage used meets the
requirements before use.
Do not modify or extend the power cord. It is recommended to use grounding
receptacles when running this unit.
Do not plug or unplug the power cord
with wet hands, this operation has the
risk of causing electric shock.
When pulling the power cord, please
pinch the plug and do not pull the
power cord.
4
Do not control the opening and closing
state of the machine by plugging the
power plug.
Please turn off the machine before you
pulling the plug.
Do not share a power outlet with multiple
high-power electrical appliances.
Please keep the machine away from the
heat source and avoid direct sunlight.
If the machine makes a strong noise,
smell or smoke, please turn off the
machine immediately and pull the plug
to check the cause.
Do not press heavy objects on the
power cord, so as to prevent the
power cord from being crushed and
cause electric shock.
5
Don’t insert your fingers or any hard
object to wind guide bar of the air outlet.
Do not let water enter the electrical
part of the machine.
If water enters the machine, shut it down
immediately and pull out the plug, then
contact the professional maintenance
personnel for repair.
If you need to wipe, clean, move the
machine or replace the machine parts,
please turn off the machine and unplug
the power plug first.
When the gas leak occurs, please open
the windows first, ensure the air
circulation, then run the machine.
The appliance user must be eight years
of age. Weak people, people with weak
sensory abilities or low psychological
quality must be supervised and used
when they understand the correct use
methods and harmfulness. Children are
prohibited from playing. Children must be
cleaned and maintained under supervision.
19.7in.
19.7in.
n.i7.91
6
SPECIAL WARNING
Place the A/C on even ground and
install it vertically, so as to ensure
normal operation of the compressor.
The A/C should be at least 19.7in. away
from surrounding objects. Keep air inlet
and outlet smooth.
Don’t use the A/C beside gasoline or
any other inflammable liquid.
Don’t use spraying agent and other solvent
or flammable substances near the A/C;
otherwise, its plastic may deform and
electric parts may be damaged.
4
1
2
3
5
8
10
9
7
6
1
2
3
4
5
6
7
8
Drainage nozzle
9
10
11
12
11
7
PRODUCT INTRODUCTION
Handle
MAIN PARTS COMPONENTS
Air inlet (Down)
Control Panel
Air outlet louver
Castor
Remote controller
Air outlet(Up)
Hot air outlet
Air outlet grille
Exhaust duct assembly
Window sealing plate assembly
12
1
2
3
4
5
6
7
7
8
8
8
CONTROL PANEL AND REMOTE CONTROLLER
Power key
Press the key to turn ON/OFF the A/C.
Speed key
Press the key to choose high/middle/low speed.
Temperature/ time adjusting key
Press the key at cooling mode
to increase/reduce the setting temperature;
press it at timing mode to adjust timing ON/OFF
time; press Up and Down keys simultaneously to
switch Fahrenheit and Centigrade degree temperature.
Mode key
Press the key to choose cool,fan,dry.
Timer key
Press the key at standby mode to set ON time.
Press this key at ON mode to set OFF time.
Temperature/ time display window
This window displays the adjusted temperature and time.
Switch key
Press the key to switch ℃and ℉.
Swing key
Press this button or press the speed key and timing key
simultaneously to turn on / off the swinging function.
HR
Dry
Fan
Cool
Low
Mid
High
Mode Fan Timer
