Sharp FO-80 User manual

The Sharp FO-80 facsimile transceiver is acompact, desktop digital unit.

This manual describes the operating procedures for the FO-80. All of the fea

tures can be easily learned by following the step-by-step instructions on the

following pages.

This manual is divided into indexed sections for quick and easy access to

information.

When aproblem cannot be solved using the troubleshooting procedures

described in this manual, please contact an authorized Sharp service center.

The FO-80 facsimile is capable of automatic communication with aCCITT

Group 3(Subminute) facsimile unit.

PART NAMES AND FUNCTIONS. . . . . . . . . . . . . . . . . . . .

INSTALLATION . . . . . . . . . . . . ●.=.=. . ● ● .●■. . ~~.=●. .

1. Pre-installationNotes . . . . . . . . ..9...... =....~.●.==

2. Installation

DOCUMENTS

Procedures. . . . . . . . . . . . . . . . . . . . . . ●. . . . ~

FOR TRANSMISSIONOR COPYING. . . . . .

OPERATINGPROCEDURES.■.● ● . . . . . . . . . . . . . . . . . . .

Transmitting. ...*....=. . . . . . . . . ●. . ●., ●., . . ●., S

Selectionof MODE .- ..., . . . . . . . . . . . . . =■~. . ●. . . . .

Selectionof Document Size . . . . . . . . . . . . . . . . . . . . . . . .

Selectionof Enlargement or Reduction., . ●...c..........14

Selectionof Contrast

How to Receive. ...

AutomaticReception.

Manual Reception . .

Copying ........

TRANSMITTERMINALRECORDING. . . . . . . . . . . . . . ■.●18

How to Register

How to Set Date

How to Register

.....

and Time ........................... 18

Sender Telephone Number. ................ZO

Sender Name. . . . . . . . . . . . . . . . . . . . . . . . . 22

TABLE OF CONTENTS 3

HOW TO INSURETRANSMITTERMINALRECORDING

TRANSACTIONREPORT. . . . . . .

MAINTENANCE . . . .

How to Replacethe

. . . . . . . . . .

Recording Paper

Purchasing Recording Paper Rolls. .

Cleaning ., . . . . . . . . . . . . . . .

BEFORECALLING FORSERVICE

1. OperationalProblems . . . . . . . . .

2. Copy (luality Problems. ., . . . . . .

SPECIFICATIONS.......m...,.

. . .

Roll

.m.

●☛✌

.’.

.*.

,..

.,*

●

☛

✎

✌

●

✎

●

✎

●

✎

■

‘

●

✎

●

. .

●

✎

■

●

■

✎

☛

✎

●

✎

●

✎

●

✎

1. ExternalView

FRONT VIEW

@Open/Closebuttons

Pull both buttons towards the front

to open the compartment cover.

@Documentcover

@Documentscanner

@loperation panel

(Refer to page 7.)

@Receiveddocument exit

@Documentglass

\\\\\

PARTNAMESAND FUNCTIONS 5

REAR VIEW

@Power switch

@AC powercord connection

@Telephoneline connection

6PARTNAMESAND FUNCTIONS

INTERNAL VIEW

@Recordingpaper rollcover

@Lock lever Push to open the recording paper roll cover

@Recordingpaper roll

@Recordinghead To record the image onto the recording

paper.

@Paper feed roller To advance the recording paper

PARTNAMESAND FUMCTIONS 7

2. OperationPanel .

‘& D

COMM/COpY indicator

Receive button

Send/Copybutton

Mode button

Size button

Paper indicator

Alarm indicator

Stop button

Ratio select

iI I

@Contrast select

(o Auto receive button

This indicator is on during reception, trans-

mission or copying.

Press to begin reception in the manual mode.

Press to begin transmission or to begin

copying.

Press to select transmission or copy resolu-

tion. Use the H-Tone setting for copying or

transmitting photographs.

Press to select original size.

On when out of paper or when recording

paper roll cover is open.

On when the recording paper roll cover is

open, when there is acommunications error,

or there are other alarm conditions.

Press to terminate transmission or copying.

Use to select copy or transmission ratio.

NOTE: Enlarge function is disabled in the H-

Tone mode.

Select dark or light contrast. If no selection is

made, the machine defaults to the auto mode.

Press to begin auto reception mode.

1, Pre-installationNotes

Install the machine on a level surface.

Keep the machine away from air conditioners, heaters, direct sunlight,

humidity and dust.

Provide easy access to the front, back and side of the machine.

Avoid locations where the machine may be spashed by water or chemicals.

A240 volt AC, 50Hz, isolated and grounded (Three prong) outlet is required,

and should be located near the machine.

Amodular telephone must be located near the machine.

When transferring from acold to awarm place, moisture may collect on the

lens and mirror; allow at least two hours before use to allow the machine to

adjust to the new room temperature.

2. InstallationProcedure

1. Install the recording paper roll.

A. Open the machine cover.

B. Open the recording paper roll cover.

2. Place the paper roll as shown.

INSTALLATION 9

3. Pull the leading edge of the paper

through the document exit.

4. Close the recording paper roll cover.

6. Plug in the power cord.

Plug in the telephone line cord.

Turn the machine on.

/,/

,/’

5. Close the machine cover.

Also, check to see that the machine

cover is properly locked.

Power Switch Line Cable I

NOTE:

When installing, detach the cushion and tape used to fix the document scanner.
