Package Contents
Package Contents
Package Contents
Handset (AQUOS Xx3 mini)
・Battery is built into handset.
・Handset back cover is not removable.
Warranty
1
Charging Handset
Battery is built into handset.
Internal Battery
About Charging
AC Charger
Charging by PC
Internal Battery
A lithium-ion battery is built into handset; it is not removable.
Recycling
This product requires a lithium-ion battery. Lithium-ion batteries are recyclable. To
recycle a used lithium-ion battery, take it to any shop displaying the recycling symbol.
Battery Cautions
Battery Care
To help maintain performance and life of Internal Battery, do not store in the following
conditions (battery level should be at approximately 40% for optimal storage).
Full (immediately after charging is complete)
Exhausted (too low to power on handset)
2
Bulges of Internal Battery
Depending on usage, bulges may appear near end of battery life; this does not affect
safety.
Internal Battery Replacement
Internal Battery is a consumable item; may need to be replaced if operating time
shortens noticeably. Internal Battery is not user replaceable; its replacement incurs fees
and requires handset submission to a SoftBank Shop or other appropriate servicer. For
details, contact a SoftBank Shop or SoftBank Customer Support, General Information.
About Charging
The following charging options are available.
Charging Option
Description
AC Charger
Connect handset and AC Charger (optional
accessory) directly.
USB charging
Connect handset and a PC with Micro USB
Cable (optional accessory).
Charging/Notification Lamp
Charging/Notification Lamp illuminates red while charging; illuminates green when
charge is almost full.
Charging/Notification Lamp goes out when charge is full.
If Charging/Notification Lamp is blinking, charging is not working properly. Make sure
that you are using Charger and products specified by SoftBank Corp. If you are using
specified products only, contact a SoftBank Shop or SoftBank Customer Support,
General Information.
Charging Cautions
Water Resistance
AC Charger (optional accessory) and Micro USB Cable (optional accessory) are not
waterproof. Never connect Micro USB plug while handset or Charger is wet.
Handset is water resistant; however, if Micro USB plug is inserted while it is wet, liquid
(tap water, beverage, sea water, pet urine, etc.) or a foreign object adhered to handset
or Micro USB plug may cause overheating, burnout, fire, malfunction, burns, etc. due to
electric shock, short-circuiting, etc.
Handling Cables
Do not pull, bend, or twist cable; may damage the cable.
3
About Charging Abroad
SoftBank Corp. is not liable for problems resulting from charging handset abroad.
AC Charger
AC Charger is an optional accessory. Be sure to use SB-AC12-HDQC (SoftBank SELECTION
Qualcomm® Quick ChargeTM 2.0 AC Adaptor for smartphones) or SB-AC13-HDMU (Micro USB, 1.0
A) specified by SoftBank Corp.
For information on other peripheral devices, see SoftBank Website.
The following explains how to charge handset using SB-AC12-HDQC (SoftBank SELECTION
Qualcomm® Quick ChargeTM 2.0 AC Adaptor for smartphones).
See User Guide for corresponding AC Charger.
Never connect Micro USB plug while handset or AC Charger is wet.
Insert Micro USB plug of AC Charger into External Device Port
4
Insert Micro USB plug in correct orientation; otherwise, External Device Port may be damaged.
Check contours and orientation of Micro USB plug, then insert it with tabs (○) facing down.
Extend blades and plug AC Charger into AC outlet
Charging starts and Charging/Notification Lamp illuminates.
Charging/Notification Lamp goes out when charge is full.
After charging, remove Micro USB plug from External Device Port, then unplug AC
Charger and retract blades
Charging by PC
Connect handset to a PC with Micro USB Cable (SHDDL1; optional accessory).
Make sure that PC is turned on.
Charging may not be possible/take a long time depending on connection and PC conditions.
Never connect Micro USB plug while handset or Micro USB Cable is wet.
Insert Micro USB plug of Micro USB Cable into External Device Port
5
Insert Micro USB plug in correct orientation; otherwise, External Device Port may be damaged.
Check contours and orientation of Micro USB plug, then insert it with tabs (○) facing down.
Insert USB plug of Micro USB Cable into PC USB port
Charging starts and Charging/Notification Lamp illuminates.
Charging/Notification Lamp goes out when charge is full.
After charging, remove Micro USB Cable from handset and PC
6
Specifications
Handset
TV Antenna Cable
Materials
Handset
Handset specifications are as follows.
Times in the table vary with location, status, settings, etc.
Display employs precision technology; however, some pixels may remain on/off.
Item
Description
Dimensions (W x H x D)
Approx. ＊＊ mm x ＊＊＊ mm x ＊.＊ mm
(without protruding parts)
Weight
Approx. ＊＊＊ g
Maximum Output
3G: 0.25 W
GSM (850 MHz, 900 MHz): 2 W
GSM (1800 MHz, 1900 MHz): 1 W
4G: 0.2 W
Internal Battery Capacity
2,400 mAh
Continuous Talk Time1
3G: Approx. ＊＊＊ minutes
GSM: Approx. ＊＊＊ minutes
VoLTE: Approx. ＊＊＊minutes
Continuous Standby Time2
3G: Approx. ＊＊＊ hours
GSM: Approx. ＊＊＊ hours
4G (AXGP Network): Approx. ＊＊＊ hours
4G (FDD-LTE Network): Approx. ＊＊＊ hours
Full Seg/One Seg Continuous Viewing Time3
Full Seg: Approx. ＊＊ hours
One Seg: Approx. ＊＊ hours
Charging Time4
AC Charger (SB-AC12-HDQC)5: Approx. ＊＊＊
minutes
AC Charger (SB-AC13-HDMU; Micro USB, 1.0
A): Approx. ＊＊＊ minutes
Maximum Transmission Speed6
SoftBank 4G: 165 Mbps in downlink, 10 Mbps in
uplink
SoftBank 4G LTE: 187.5 Mbps7 in downlink, 37.5
7
Mbps in uplink
1 Average measured with handset fully charged, in strong signal conditions at rest.
2 Average measured with handset fully charged, without calls or operations, in strong signal
conditions at rest, and with data communication and Urgent News disabled. May vary with battery
strength, ambient temperature, settings, etc.
3 Calculated in full-screen landscape mode, with Brightness level set to medium, with Earphones
with Mic (optional accessory), and volume at maximum, starting from handset fully-charged and
continuing until 10% remaining battery charge.
Usable time may vary with radio signal conditions and the content played.
4 Measured with power off using AC Charger.
5 SB-AC12-HDQC (SoftBank SELECTION Qualcomm® Quick ChargeTM 2.0 AC Adaptor for
smartphones)
6 Provided on a best-effort basis; transmission speed may decrease or transmission may become
unavailable due to traffic conditions, network environment, etc. In addition, transmission speed
varies by area.
7 Scheduled to be available on an area-by-area basis. Depending on area, maximum downlink
speed is set to 150 Mbps, 112.5 Mbps, 75 Mbps, or 37.5 Mbps or less.
Materials
Parts
Materials Used/Surface Finish
Display
Tempered glass
Shatterproof Film
Polyester/AF coating
Periphery of Display
Aluminum/anodizing
Cabinet (metal part)
Aluminum/anodizing
Cabinet (resin part) for Black
PC resin/coating, UV top coating
Cabinet (resin part) for Purple and White
PC resin/indium deposition, UV top coating
8
Grip Sensor
Acrylic/hard coating
Back Surface
Tempered glass/AF coating
Periphery of Back Surface
PA resin + GF/UV top coating
Power Key
Aluminum/anodizing
Volume Up/Down Key
Aluminum/anodizing
Earphones-Microphone Port Ornament
PC resin
Receiver Screen
SUS/electrophoretic coating
Camera Window
Tempered glass/AF coating
Camera Ornament
Aluminum/anodizing
Fingerprint Sensor
Polyimide/UV top coating
Fingerprint Sensor Ornament
Aluminum/anodizing
Card Slot Cover
PC resin + TPU/UV top coating
Card Slot Cover Gasket
Silicone + SUS
USIM Tray
POM resin
IMEI Tray
PET
Speaker Screen
Nylon resin/water-repellent treatment
External Device Port
SUS/tin plating
9
