Sharp IG-A20EK-W Manual
IG-A20EK-W
HIGH-DENSITY PLAMACLUSTER TECHNOLOGY
WIDE LOUVER FOR HIGH OUTPUT
EFFECTIVE AGAINST AIRBORNE VIRUSES &
MOULD
3 AIRSTREAM SETTINGS
LOW POWER CONSUMPTION
QUIET OPERATION
AUTO RESTART SWITCH
REDUCING CIGARETTE SMOKE ODOUR FROM
CLOTH
This product is designed for making the business environment healthier and more comfortable. The Plamacluster Ion Generator
creates the best possible indoor climate. The powerful Plamacluster technology is able to reduce harmful particles in indoor air,
as well as nutralise unpleasant odours.
GENERAL
Applicable floor surface area m²: 23.0
Plasmacluster ion generating unit (sets): 2
Ion density (high/ med/ low) icons/cm3: 25000/12000/7000
Inverter operation:
PCI unit replacement light:
PCI unit life (years/hours): approx. 2/17500
Plasmacluster ion generating unit for replacement: IZ-CA20E
Filter (Air Intake) sheets: 1
Filter clean light:
FAN SPEED
Fan speed adjustment (high/med/low): / /
Fan speed indicator:
Air flow volume (high/ med / low) m3/ hour: 468/390/306
Noise level (high/ med/ low) dBA: 45/40/34
TECHNICAL SPECIFICATIONS
Voltage/ frequency: 220-240V/50/60Hz
Power consumption (high/ med/ low) W: 22.0/14.0/9.0
Standby power (W): 0.8
Measures (W x D x H) in mm: 594/230/480
Power cord length (m): 2.0
Colour: white
Net weight (kg): 10.5
EAN Code: 4974019650494
SUPPLIED ACCESSORIES
Operation manual:
Tip-resistant kit:
Screw kit:
Powered by TCPDF (www.tcpdf.org)
www.sharp.co.uk SHARP ELECTRONICS (UK) LIMITED
4 FURZEGROUND WAY
STOCKLEY PARK
UXBRIDGE, MIDDLESEX UB11 1EZ. TEL. 0208 734 2000
