SECO-LARM Enforcer EV-1006-N4BQ User manual

Tel: 1-800-662-0800 (Domestic U.S. & Canada) Email: [email protected] Website: www.seco-larm.com

16842 Millikan Avenue, Irvine CA 92606 Tel: 1-949-261-2999 (California and International) Fax: 1-949-261-7326

pi-EV-1006-N4xQ.docx

The SECO-LARM policy is one of continual development. For that reason SECO-LARM reserves the right to change prices and specifications without notice. SECO-LARM is not responsible for misprints.

SECO-LARM®

Sony 1/3” CCD

420 TV lines

18 IR LEDs: Up to 60’ range

Day/Night operation: 0 lux LEDs on, 0.4 lux LEDs off

Cables concealed in bracket to prevent tampering

Rugged, weatherproof (IP67) construction

Built-in backlight compensation

Low current consumption

IR Day/Night Bullet Cameras

Specifications:

Features:

EV-1006-N4WQ 4.3mm Lens, 18 IR LEDs, 60’ Range, White

EV-1006-N4BQ 4.3mm Lens, 18 IR LEDs, 60’ Range, Black

Type

Color camera

Chip

1/3” CCD, Sony

Resolution

420 TV lines

Pickup elements

510 x 492 pixels

Scanning system

2:1 interlace

Sync

Internal

Lens

4.3mm, F2.0 fixed

Minimum illumination

0.4 lux (LEDs off), 0.0 lux (LEDs on)

S/N ratio

>50dB (AGC off)

Backlight compensation

Enclosure

IP67 weatherproof

# of infrared LEDs

Max. LED range

Up to 60 ft. (18m)

Power source

12VDC±10%

Power consumption

100mA (IR off), 280mA (IR on)

Operating temperature

14°~122° F (-10°~50° C)

Dimensions

61/4”(L) x 215/16”(D) (158 x 74 mm)

Weight

13.6 oz. (386g)

Dimensions:

EV-1006-N4BQ

EV-1006-N4WQ

Concealed

Wiring

VDC

Night

Day

18 IR

LEDs

1/3”

Sony

CCD

Wiring concealed in

mounting bracket to

prevent tampering.

IP67

Weatherproof
