Seagull Models SEA 334 User manual

Specications:

Wingspan--------------- 86.0 in (218.4 cm).

Wing area--------------- 1168.7sq.ins (75.4 sq.dm).

Weight------------------- 21.6 lbs (9.8 kg).

Length------------------- 65.0 in (165.0 cm).

Engine/Motor size----- 50-60cc gasoline.

Radio--------------------- 7 channels with 8 servos.

SEA 334 : Without electric retracts landing gear.

SEA334gear: including Electric retracts landing gear.

ASSEMBLY MANUAL

Code : SEA 334

Giant Zero A6M Gas ARF 50-60cc, 86” Instruction Manual.

ank you for choosing the Giant Zero A6M Gas ARF 50-60cc, 86” ARTF by SG MOD-

ELS . e Giant Zero A6M Gas ARF 50-60cc, 86” was designed with the intermediate/

advanced sport yer in mind. It is a semi scale airplane which is easy to y and quick to as-

semble. e airframe is conventionally built using balsa, plywood to make it stronger than

the average ARTF, yet the design allows the aeroplane to be kept light. You will nd that

most of the work has been done for you already. e motor mount has been tted and the

hinges are pre-installed. Flying the RGiant Zero A6M Gas ARF 50-60cc, 86” is simply a joy.

is instruction manual is designed to help you build a great ying aeroplane. Please read

this manual throughly before starting assembly of your Giant Zero A6M Gas ARF 50-60cc,

86” Use the parts listing below to indentify all parts.

Please be aware that this aeroplane is not a toy and if assembled or used incorrectly it is ca-

pable of causing injury to people or property. WHEN YOU FLY THIS AEROPLANE YOU

ASSUME ALL RISK & REPONSIBILITY.

If you are inexperienced with basic R/C ight we strongly recommend you contact your R/C

supplier and join your local R/C model Flying Club. R/C Model Flying Clubs oer a variety

of training procedures designed to help the new pilot on his way to successful R/C ight.

ey will also be able to advise on any insurance and safety regulations that may apply.

INTRODUCTION

WARNING

KIT CONTENTS

SEA334 Giant Zero A6M Gas ARF

50-60cc, 86”

1. Fuselage

2. Wing set (2)

3. Tail set (2)

4. Canopy

5. Cowling

6. Wing tube

7. Pilot

8. landing gear

9. Fuel tank

10. Tail wheel

ADDITIONAL ITEMS REQUIRED

TOOLS & SUPPLIES NEEDED

in cyanoacrylate glue.

Medium cyanoacrylate glue.

30 minute epoxy.

5 minute epoxy.

Hand or electric drill.

Assorted drill bits.

Modelling knife.

Straight edge ruler.

2mm ball driver.

Phillips head screwdriver.

220 grit sandpaper.

90° square or builder’s triangle.

Wire cutters.

Masking tape & T-pins.

read-lock.

Paper towels.

�50-60cc gasoline engine.

�Computer radio 7 channel with 8

servos.

�Glow plug to suit engine.

�Propeller to suit engine.

�Protective foam rubber for radio

system.

HINGING THE FLAP

2x10mm

Giant Zero A6M Gas ARF 50-60cc, 86” Instruction Manual.

HINGING THE AILERON

Note : e control surfaces, including the ailer-

ons, elevators, and rudder, are prehinged with

hinges installed, but the hinges are not glued in

place. It is imperative that you properly adhere

the hinges in place per the steps that follow us-

ing a high-quality thin C/A glue.

Carefully remove the aileron from one of

the wing panels. Note the position of the

hinges.

Remove each hinge from the wing panel

and aileron and place a T-pin in the center of

each hinge. Slide each hinge into the wing

panel until the T-pin is snug against the wing

panel. is will help ensure an equal amount

of hinge is on either side of the hinge line

when the aileron is mounted to the aileron.

Slide the wing panel on the aileron until

there is only a slight gap. e hinge is now

centered on the wing panel and aileron.

Remove the T-pins and snug the aileron

against the wing panel. A gap of 1/64” or

less should be maintained between the

wing panel and aileron.

NOTE : e hinge is constructed of a spe-

cial material that allows the C/A to wick

or penetrate and distribute throughout

the hinge, securely bonding it to the wood

structure of the wing panel and aileron.

Deect the aileron and completely satu-

rate each hinge with thin C/A glue. e

ailerons front surface should lightly con-

tact the wing during this procedure. Ide-

ally, when the hinges are glued in place,

a 1/64” gap or less will be maintained

throughout the lengh of the aileron to the

wing panel hinge line.

Hinge

T-pin

Hinge

Epoxy

Turn the wing panel over and deect the

aileron in the opposite direction from the

opposite side. Apply thin C/A glue to each

hinge, making sure that the C/A penetrates

into both the aileron and wing panel.

Using C/A remover/debonder and a paper

towel, remove any excess C/A glue that may

have accumulated on the wing or in the

aileron hinge area.

Repeat this process with the other wing

panel, securely hinging the aileron in

place.

Aer both ailerons are securely hinged,

rmly grasp the wing panel and aileron to

make sure the hinges are securely glued

and cannot be pulled out. Do this by

carefully applying medium pressure, try-

ing to separate the aileron from the wing

panel. Use caution not to crush the wing

structure.

Work the aileron up and down sev-

eral times to “work in” the hinges

and check for proper movement.

Note :

WING TIP BULBS

Please see below pictures.

5.3.

ey are designed to operate on volt-

ages 12 volts.

Giant Zero A6M Gas ARF 50-60cc, 86” Instruction Manual.

INSTALL THE AILERONS

CONTROL HORN

Fiberglass control horn

Ailerons control horn

Epoxy

CA glue

Install the ap control horn using the

same method as same as the aileron con-

trol horns.

Fiberglass control horn

INSTALL FLAP CONTROL HORN

Flap control horn

INSTALLING THE AILERON SERVOS

Because the size of servos dier, you

may need to adjust the size of the precut

opening in the mount. e notch in the

sides of the mount allow the servo lead to

pass through.

Place the servo between the mounting

blocks and space it from the hatch. Use a

pencil to mark the mounting hole loca-

tions on the blocks.

Minimum servo spec.

Torque : 194 oz-in (14 kg-cm) @ 6.0V;

236 oz-in ( 17kg-cm) @ 7.4V

Epoxy

Giant Zero A6M Gas ARF 50-60cc, 86” Instruction Manual.

Use dental oss or heatshrink tube to

secure the connection so they cannot be-

come unplugged.

Apply 2-3 drops of thin C/A to each of

the mounting holes. Allow the C/A to

cure without using accelerator.

1.5mm

5.8.

Secure the servo to the aileron hatch

using Phillips screwdriver and the screws

provided with the servo.

Apply 1-2 drops of thin C/A to each of

the mounting tabs. Allow the C/A to cure

without using accelerator.

Remove the string from the wing at the

servo location and use the tape to attach it

to the servo extension lead. Pull the lead

through the wing and remove the string.

C/A glue

Use drill bit in a pin vise to drill the

mouting holes in the blocks.

12.

13.

14.

10.

11.

Set the aileron hatch in place and use a

Phillips screw driver to install it with four

wood screws.

3x10mm

INSTALLING THE FLAP SERVO

Repeat the procedure for the ap servo.

Giant Zero A6M Gas ARF 50-60cc, 86” Instruction Manual.

AILERON PUSHROD INSTALLATION

Please see below pictures.

INSTALLING THE FLAP PUSHROD

INSTALLING LANDING GEAR

Locate items necessary to install Sprin

Landing Gear.

75mm
