4 TVO-THM-BA-e-2121
4 Check before use
After receipt of the test bench, it should be checked in advance whether no transport
damage has occurred, whether the outer packaging, the metal housing, other parts
or even the test bench itself have been damaged. If any damage is evident, please
notify SAUTER GmbH immediately.
5 Possible applications
The TVO-N or THM-N test stand is designed to accommodate most SAUTER force
measuring devices without any great difficulty. It has a wide range of applications and
can be operated manually. It can also perform individual functions independently.
These are, for example, infinitely variable speed adjustment, automatic horizontal
movement (THM) or vertical movement (TVO) with preset repetition (up to 1000
cycles). It can be used for material testing in the metal, plastics and textile industries.
It can also be operated with SAUTER software (AFH), from where it can be
conveniently controlled by PC. This software is also able to document force, time and
distance.
•Select the correct test stand with regard to the test direction you require.
•Under no circumstances should you attempt to open, repair or modify the unit.
Contact SAUTER GmbH.
•The test bench is not suitable for operation in a humid environment. Avoid
penetration of moisture into the housing under all circumstances.
•Do not use sharp objects to operate the buttons.
•Use the limiting rings on the test bench to check the travel. Precise adjustment
of the travel using the limiting rings prevents damage to the test stand and the
force gauge used.
•From time to time, moisten the rods with a lubricating oil.
Turn off the unit and unplug the power cord if you are not going to use it for a long
time.
