Sanyo VCC-HD5600P Series User manual

VCC-HD5600/HD5600P series

Features of This Camera

Specifications

Target size and recording time

Power Unit Connection and Settings

Introductio

The camera supports network operation. By simply connecting a LAN cable to it, you can construct the most

advanced network monitoring system. From the Web browser (Internet Explorer) installed on your PC, you

can operate the camera via the network in an easy-to-use manner.

The camera supports bidirectional audio communications, enabling you to communicate with people at the

camera from your PC while monitoring the surveillance video, instead of just hearing sounds from the

camera.

The camera has 2-megapixel CMOS sensor that produces clear images at ultra-high resolution.

Using multi-stream video transmission, it can simultaneously deliver up to four video/ima

e streams. Because

it allows video/image compression format, resolution, and other image conditions to be set as desired for

each stream, you can choose the optimal video/image for your application.

Installation of the HDMI option board (sold separately) on the camera enables you to monitor surveillance

video in full hi-vision.

You can freely control camera lens orientation with your PC mouse.

With a 10× built-in optical zoom lens, the camera offers a zoom magnification of up to 160× in conjunction

with the electronic zoom function.

By installing an SD memory card or external hard disk (sold separately), surveillance video can be recorded

on the camera side.

The camera's motion sensor function can work in conjunction with any external alarm device, facilitating the

construction of a high-level security system.

Installing associated software applications on your PC further extends the capabilities of your surveillance system.

H.264 Plug-in (supplied):Surveillance video can be viewed in H.264 format.

Auto IP Setup (supplied):This searches your local network for cameras and allows IP

addresses to be set at once.

Downloader (supplied):This downloads image data recorded on the camera to your PC.

DLViewer (supplied):This plays back image data that has been downloaded to your PC.

VA-SW3050Lite (supplied):This allows you to simultaneously monitor multiple camera video

images on a multi-view screen.

VA-SW3050Server/Client (sold

separately):This allows you to record and play back video images from the

camera on your PC that are distributed over the network.

Introductio

This device is composed of a camera unit, power unit (VA-94S) and surface cover (supplied).

Image pickup device 1/2.5” CMOS sensor

Effective pixels 16:9 1920 (H) × 1080 (V), 4:3 1600 (H) × 1200 (V)

Lowest image

illumination

50IRE: 2.0 lx (F1.8, in color mode with high gain)

50IRE: 0.1 lx (F1.8 in black-and-white mode with high gain)

Video S/N ratio 50 dB or higher (when AGC is 'OFF')

Lens Focal Length: f=6.3 - 63 mm

F number: F1.8 - 2.5

Optical zoom 10x, electronic zoom 16x (up to 160x when used in combination with

the optical zoom)

Rotational scope Pan: 360° endless pan

Tilt: –20 to +200°

Rotation speed Pan: Max. 420°/sec.

Tilt: Max. 360°/sec. (0.1 to 120°/sec during manual operation)

Preset position Max. 255

Auto mode Sequential, auto pan, tour, automatic return

Day/Night function Auto, color, black-and-white, alarm input switching

White balance Auto (ATW), one push (AWC), manual (R/B gain adjustable), indoor, outdoor,

fluorescent

Backlight compensation Multi-spot evaluative metering, center-weighted evaluative metering, masking, face

detection

Electronic sensitivity

boosting

Auto (32× max) or Off

Electronic shutter VCC-HD5600P: 1/25, 1/50, 1/120, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/10000

VCC-HD5600: 1/30, 1/60, 1/100, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/10000

Long exposure shutter (1×, 2×, 4×, 8×, 16×, 32×)

Iris AUTO/MANUAL (electronic iris: ON/OFF)

Camera settings Up to 8 patterns of monitoring conditions are configurable.

AGC gain Normal/Middle/High (Manual gain setting possible at Off)

Gamma correction 0.45, 1, Mode 1, Mode 2

Aperture compensation On/Off (Correction level adjustable)

VIVID COLOR EFFECT ON/OFF

DNR (digital noise

reduction)

ON/OFF

Image inversion Horizontal/Vertical/Horizontal and vertical/Off

Privacy mask ON/OFF, up to 32 positions

Motion sensor ON (detection area setting, video analytics)/OFF, face detection function

Auto pursuit ON/OFF

Sway compensation ON/OFF

Language selection English, French, German, Spanish, Japanese

Introductio

I/O

Video output Monitor output terminal (BNC)

LAN 10BASE-T/100BASE-TX (RJ-45 connector)

EX-HDD Connector For external hard disk (VA-HDC4000) connection

SD Card Slot 1 (SDHC compliant, max. 32 GB supported)

Alarm input 8 (NO/NC), also serving as Day/Night switching terminal <control terminal>

Alarm output 2 (NO/NC switching, 16 V, 150 mA, open collector) <control terminal>

Audio input/output Audio input (white: 3.5-mm mini jack)

Audio output (black: 3.5-mm mini jack)

Communication method RS-485

Protocol SSP, PELCO-D

Baud Rate 2400, 4800, 9600, 19200

Address 1 - 255 (sanyo SSP: 1 to 127)

HDMI output: Possible when an HDMI option board (VA-HDB90, sold separately) is attached

Recording media

SD memory card Normal recording, alarm recording, backup video recording in event of a network

failure, log information

External HDD Normal recording, alarm recording, backup video recording in event of a network

failure, log information

Network

Image/video

compression

H.264/JPEG

Video size (H.264) (16:9) 1920×1080, 1280×720, 640×360, 320×180

(4:3) 1600×1200, 1280×960, 1024×768, 640×480, 320×240

Video size (JPEG) (16:9)1920×1080, 1280×720, 1024×576, 640×360

(4:3) 1600×1200, 1280×960, 1024×768, 800×600, 640×480, 320×240

Picture quality QUALITY mode: BASIC, NORMAL, ENHANCED, FINE, SUPER FINE

BITRATE mode: User-specified bit rate

Interface 10BASE-T/100BASE-TX

Protocol TCP/IP, UDP, HTTP, HTTPS, SMTP, NTP, DHCP, FTP, DDNS, RTP, RTSP, RTCP

Audio G.711 (Bidirectional)

Simultaneous access 20

Security BASIC authentication (ID/password), SSL, IP filtering

Power source

Operating ambient

temperature/humidity

–10 to +50°C/14 to 122°F

90% RH or less (no condensation)

Power source 24 VAC±10%, 50/60 Hz

Power consumption 29 W

Introductio

Weight Approx. 1.9 kg/67.0 oz.

Dimensions Unit: mm (inch)

ACamera unit: approx. 1.3 kg/45.9 oz.

BPower unit: Approx. 450 g/15.9 oz.

CSurface cover: approx. 110 g/3.9 oz.

Appearance and specifications are subject to change without prior notice or obligations.

Introductio

This table is displayed using a browser-specific function and therefore not displayed on the PDF

manual.

Refer to the table “Target size and recording time” in the electronic manual.

This table is displayed using a browser-specific function and therefore not displayed on the PDF

manual.

Refer to the table “Target size and recording time” in the electronic manual.

Introductio

This device is composed of a camera unit, power unit (VA-94S) and surface cover (supplied).

When using this camera, connect and configure the power unit.

For details on terminal connections, recording media attachment and switch settings, etc., please refer to

“Connection” and “Control/Address Setting”.

This is the connection point between the camera unit and the power unit.

AControl switch (transmission rate and protocol setting, etc.)

BAddress switch (camera control address setting)

CControl terminal (connection of controller and alarm input/output cable)

Top ( A): LAN terminal (RJ-45 type)

Use this socket to connect the camera to your PC to enable network operation.

Introductio

Bottom ( B): EX-HDD terminal (USB type)

When recording live video onto an external hard disk, put the hard disk in a dedicated hard disk case (VA-

HDC4000, sold separately) and then connect the case to the camera.

When recording live video onto an SD memory card, insert the card into the slot.

Connect this terminal to the power supply.

There is no power indicator on the camera.

Connect this jack via an audio cable to the audio input jack of an amplified speaker system or the monitor.

Use this jack to connect an external microphone to listen to the sound while monitoring the live video, or

simultaneously record the video and sound.

Connect this terminal to a monitor, etc. A live video will be displayed on the monitor once the camera is turned on.

By installing an HDMI option board (VA-HDB90, sold separately), the camera can be connected to a

high vision monitor.

Perform the following connections according to the installation environment and application of your camera.

APower Connection

BNetwork Connection

CControl Terminal Connections

DAudio Jack Connection

EInstalling Recording Media

Before attempting the following connections, be sure to turn off all components of your system.

Improper connection may cause smoke or failures. Before attempting to connect each system

component, carefully read the instruction manual that comes with it to familiarize yourself with the

correct connection procedure.

Introductio

There are two types of power unit, i.e. 24 VAC and 230 VAC. Before using, always make sure of the purchased

model number and arrange the wiring correctly.

24 VAC Type

Connect the power cable to the power terminal. Although the power terminals have no polarity, the earth

grounding wire must be connected to the GND (earth grounding) terminal.

To prevent a fire hazard use any UL listed wire rated VW-1.

Be sure to use an 18AWG or thicker wire power cable.

230 VAC Type

Please refer to the instruction manual that came with the product.

This camera is designed so that you can use all of its functions via network operation.

By connecting the network (LAN) socket of the camera to your PC using a LAN cable, you can configure and

operate it from the Web browser installed on your PC.

Introductio

Use a LAN cable no longer than 100 m (109.4 yards) with the shield type CAT5 or higher.

Use a straight-type cable if connecting to LAN, and use a cross-type cable if directly connecting the

camera to a PC.

The supported Web browser is Internet Explorer Ver.6.0 SP2 or higher, or Internet Explorer Ver.7.0.

About the internet connection

Port forwarding for the video port must be enabled on the broadband router.

For details on how to set port forwarding, please refer to your router's Instruction manual.

To connect two or more cameras, on the NETWORK SETTINGS screen, assign them with port

numbers that are different from that of the first camera.

Connect the alarm input/output cable and controller to the control terminal of the interface board.

Use a thicker cable than 24AWG for connection. (Maximum length 600 m)

Installing and removing the interface board

To place the board back, align the hole ( A) at the right corner of the board to the protruding portion ( B)

and securely fix the board by depressing it.

To connect alarm or other cables to the interface board, take out the board by pulling the portion C.

Introductio
