Sanus Systems VisionMount VMCA7 User manual

Sanus Systems 2221 Hwy 36 West, Saint Paul, MN 55113 USA

Customer Service: 1-800-359-5520 • [email protected] • www.sanus.com

VMCA7

(6901-100065 <01>)

Thank you for choosing the VisionMount VMCA7 ceiling plate. The VMCA7 ceiling plate is designed to attach to an

NPT 1-1/2 in. threaded pipe. The VMCA7 will support a maximum weight of 226.8 kg (500 lbs).

Do not use this product for any purpose not explicitly specied by Sanus Systems. Improper assembly may cause

property damage or personal injury. If you do not understand these directions, or have doubts about the safety of

the assembly, contact Sanus Systems Customer Service or call a qualied contractor. Sanus Systems is not liable for

damage or injury caused by incorrect assembly or use.

CAUTION

10-24 x 0.25 in.

Improper installation may result in serious injury! The ceiling structure and mounting hardware (not included) must

be capable of supporting up to ve times the weight of the A/V equipment and mount combined. If you have any

doubts about the ability of the ceiling to support the installation, contact Sanus Systems Customer Service, or a

qualied contractor.

CAUTION

This product contains small items that could be a choking hazard if swallowed. Keep these items away from

young children!

WARNING

6901-100065 <01>

Supplied Parts and Hardware

Before starting assembly, verify all parts are included and undamaged. If any parts are missing or damaged, do not return the item

to your dealer; contact Sanus Systems Customer Service. Never use damaged parts!

x 1

10-24 x 0.25 in.

x 1

10-24 x 0.25 in.

x 1

10-24 x 0.25 in.

203 mm

(8.0 in.)

203 mm

(8.0 in.)

165 mm

(6.5 in.)

165 mm

(6.5 in.)

82 mm

(3.25 in.)

19 mm

(0.75 in.)

82 mm

(3.25 in.)

1-1/2 in. NPT

11 x 19 mm

(0.44 x 0.75 in.)

19 mm

(0.75 in.)

10-24 x 0.25 in.

17 mm

(0.68 in.)

6901-100065 <01>

10-24 x 0.25 in.

Avoid potential injuries and / or property damage!

Be sure to use the correct mounting hardware ( not

included) for your ceiling structure.

CAUTION

6901-100065 <01>

Milestone AV Technologies, Inc. and its affiliated corporations and subsidiaries (collectively,“Milestone”), intend to make this manual accurate and complete. However,

Milestone makes no claim that the information contained herein covers all details, conditions, or variations. Nor does it provide for every possible contingency in

connection with the installation or use of this product.The information contained in this document is subject to change without notice or obligation of any kind.

Milestone makes no representation of warranty, expressed or implied, regarding the information contained herein. Milestone assumes no responsibility for accuracy,

completeness or sufficiency of the information contained in this document.
