Samsung WA49B5205AW/US User manual

Washer

User manual

WA49B5205A*

Untitled-1 1Untitled-1 1 2022-01-25  2:56:532022-01-25  2:56:53

English2

Contents

Safety information 4

What you need to know about the safety instructions 4

Important safety symbols 4

Important safety precautions 5

CALIFORNIA PROPOSITION 65 WARNING 6

Critical installation warnings 6

Installation cautions 7

Critical usage warnings 8

Usage cautions 9

Critical cleaning warnings 12

Installation 13

Unpacking your washer 13

What’s included 14

Installation requirements 16

Step-by-step installation 19

Before you start 28

Initial settings 28

Laundry guidelines 28

Detergent drawer guidelines 32

Operations 35

Control panel 35

Simple steps to start 38

Cycle overview 39

Cycle chart 40

Special features 42

Smart Care 45

Untitled-1 Sec32Untitled-1 Sec32 2022-01-25  2:57:242022-01-25  2:57:24

English 3

Contents

Maintenance 46

Self Clean 46

Cleaning the exterior 47

Cleaning the interior 47

Care for an extended period of non-use 47

Cleaning the mesh lter 48

Cleaning the detergent drawer 49

Troubleshooting 51

Checkpoints 51

Information codes 56

Specications 60

Fabric care chart 60

Helping the environment 61

Declaration of conformity 62

Specication sheet 62

Untitled-1 Sec33Untitled-1 Sec33 2022-01-25  2:57:242022-01-25  2:57:24

SAVE THESE INSTRUCTIONS

English4

Safety information

Congratulations on your new Samsung washer. This manual contains important

information on the installation, use, and care of your appliance. Please take some time to

read this manual to take full advantage of your washer’s many benets and features.

What you need to know about the safety instructions

Please read this manual thoroughly to ensure that you know how to safely and efciently

operate the extensive features and functions of your new appliance. Please store the

manual in a safe location close to the appliance for future reference. Use this appliance

only for its intended purpose as described in this instruction manual.

Warnings and Important Safety Instructions in this manual do not cover all possible

conditions and situations that may occur. It is your responsibility to use common sense,

caution, and care when installing, maintaining, and operating your washer.

Because the following operating instructions cover various models, the characteristics of

your washer may differ slightly from those described in this manual and not all warning

signs may be applicable. If you have any questions or concerns, contact your nearest

service center or nd help and information online at www.samsung.com.

Important safety symbols

What the icons and signs in this user manual mean:

WARNING

Hazards or unsafe practices that may result in severe personal injury, death, and/or

property damage.

CAUTION

Hazards or unsafe practices that may result in personal injury and/or property damage.

NOTE

Indicates that a risk of personal injury or material damage exists.

These warning signs are here to prevent injury to yourself and others. Please follow them

explicitly. After reading this manual, store it in a safe place for future reference.

Read all instructions before using the appliance.

As with any equipment that uses electricity and moving parts, potential hazards exist.

To safely operate this appliance, familiarize yourself with its operation and exercise care

when using it.

Safety information

Untitled-1 4Untitled-1 4 2022-01-25  2:57:242022-01-25  2:57:24

SAVE THESE INSTRUCTIONS

English 5

Safety information

Important safety precautions

WARNING

To reduce the risk of re, electric shock, or injury to persons when using your appliance,

follow basic precautions, including the following:

1. Read all instructions before using this appliance.

2. Do not wash or dry articles that have been previously cleaned in, washed in, soaked

in, or spotted with gasoline, dry-cleaning solvents, other ammable or explosive

substances as they give off vapors that could ignite or explode.

3. Do not allow children to play on or in the appliance. Close supervision of children is

necessary when the appliance is used near children.

4. Before the appliance is removed from service or discarded, remove the lid of the

washing or drying compartment.

5. Do not reach into the appliance if the drum is moving.

6. Do not install or store this appliance where it will be exposed to the weather.

7. Do not tamper with the controls.

8. Do not repair or replace any part of the appliance or attempt any servicing unless it is

specically recommended in the user-maintenance instructions or in published user-

repair instructions that you understand and have the skills to carry out.

9. Do not add gasoline, dry-cleaning solvents, or other ammable or explosive substances

to the wash water. These substances give off vapors that could ignite or explode.

10.Under certain conditions, hydrogen gas may be produced in a hot water system

that has not been used for 2 weeks or more. HYDROGEN GAS IS EXPLOSIVE. If the

hot water system has not been used for 2 weeks or more, before using a washer or

combination washer-dryer, turn on all hot water faucets and let the water ow from

each for several minutes. This will release any accumulated hydrogen gas. As the gas is

ammable, do not smoke or use an open ame during this time.

Untitled-1 5Untitled-1 5 2022-01-25  2:57:252022-01-25  2:57:25

SAVE THESE INSTRUCTIONS

Safety information

English6

Safety information

CALIFORNIA PROPOSITION 65 WARNING

WARNING

Cancer and Reproductive Harm - www.P65Warnings.ca.gov.

Critical installation warnings

WARNING

Plug the power cord into an AC 120 V / 60 Hz/wall socket rated at 15 amps or higher. Use

the socket for this appliance only. In addition, do not use an extension cord.

• Sharing a wall socket with other appliances, using a power strip, or extending the

power cord may result in electric shock or re.

• Do not use an electric transformer. It may result in electric shock or re.

• Ensure that the power voltage, frequency, and current match the product’s

specications. Failing to do so may result in electric shock or re.

Have this appliance installed by a qualied technician or service company.

• Failing to do so may result in electric shock, re, an explosion, problems with the

product, or injury.

Remove all foreign substances such as dust or water from the power plug terminals and

contact points using a dry cloth on a regular basis.

• Unplug the power plug and clean it with a dry cloth.

• Failing to do so may result in electric shock or re.

Plug the power plug into the wall socket in the right direction so that the cord runs

towards the oor.

• If you plug the power plug into the socket in the opposite direction, the electric wires

within the cable may be damaged and this may result in electric shock or re.

This appliance must be properly grounded. Do not ground the appliance to a gas pipe,

plastic water pipe, or telephone line.

• Improper grounding may result in electric shock, re, an explosion, or problems with

the product.

• Never plug the power cord into a socket that is not grounded correctly. Make sure the

socket you use is grounded in accordance with local and national codes.

Do not install this appliance near a heater or ammable material.

Untitled-1 6Untitled-1 6 2022-01-25  2:57:252022-01-25  2:57:25

SAVE THESE INSTRUCTIONS

English 7

Safety information

Do not install this appliance in a humid, oily, or dusty location, or in a location exposed to

direct sunlight or water (rain drops).

Do not install this appliance in a location where gas may leak.

• This may result in electric shock or re.

Plug the power plug into the wall socket rmly. Do not use a damaged power plug,

damaged power cord, or loose wall socket.

• This may result in electric shock or re.

Do not pull or excessively bend the power cord.

Do not twist or tie the power cord.

Do not hook the power cord over a metal object, place a heavy object on the power cord,

insert the power cord between objects, or push the power cord into the space behind the

appliance.

• This may result in electric shock or re.

Do not pull the power cord when unplugging the power plug.

• Unplug the power plug by pulling the plug.

• Failing to do so may result in electric shock or re.

If the power plug or power cord are damaged, contact your nearest Samsung service

center.

Installation cautions

CAUTION

Position the appliance so that the power plug is easily accessible.

• Failing to do so may result in electric shock or re due to electric leakage.

Install your appliance on a level and hard oor that can support its weight.

• Failing to do so may result in abnormal vibrations, noise, or problems with the product.

Unplug the power plug when the appliance is not being used for long periods of time or

during a thunder/lightning storm.

• Failing to do so may result in electric shock or re.

Untitled-1 7Untitled-1 7 2022-01-25  2:57:252022-01-25  2:57:25

SAVE THESE INSTRUCTIONS

Safety information

English8

Safety information

Critical usage warnings

WARNING

If the appliance is ooded, cut the power immediately and contact your nearest Samsung

service center.

If the appliance emits a strange noise, a burning smell, or smoke, unplug the power plug

immediately and contact your nearest Samsung service center.

• Failing to do so may result in electric shock or re.

In the event of a gas leak (such as propane gas, LP gas, etc.), ventilate the area

immediately. Do not turn any appliance or light on or off.

• Do not use a ventilating fan.

• A spark may result in an explosion or re.

Do not wash items contaminated with gasoline, kerosene, benzene, paint thinner, alcohol,

or other ammable or explosive substances.

• This may result in electric shock, re, or an explosion.

Do not force the washer lid open while the washer is operating (high-temperature

washing/drying/spinning).

• Water owing out of the washer may cause burns or cause the oor to be slippery.

This may result in injury.

• Forcing the lid open can damage the product or cause injury.

Make sure to remove the packaging (sponge, styrofoam) attached to the bottom of the

washer before using it.

Do not insert your hand under the washer.

• This may result in injury.

Do not touch the power plug with wet hands.

• This may result in electric shock.

Do not turn the appliance off by unplugging the power plug while the washer is in

operation.

• Plugging the power plug into the wall socket again may cause a spark and result in

electric shock or re.

Keep all packaging materials well out of the reach of children, as packaging materials can

be dangerous to children.

• If a child places a plastic bag over his or her head, the child may suffocate.

Untitled-1 8Untitled-1 8 2022-01-25  2:57:252022-01-25  2:57:25

SAVE THESE INSTRUCTIONS

English 9

Safety information

Do not insert your hand or a metal object under the washer while it is operating.

• This may result in injury.

Do not attempt to repair, disassemble, or modify the appliance yourself.

• Do not use any fuse (such as copper, steel wire, etc.) other than a standard fuse.

• If you need to repair or reinstall the appliance, contact your nearest Samsung service

center.

• Failing to do so may result in electric shock, re, problems with the product, or injury.

If any foreign substance such as water enters the appliance in any area other than the tub,

unplug the power plug and contact your nearest Samsung service center.

• Failing to do so may result in electric shock or re.

If the water supply hose comes loose from the faucet and oods the appliance, unplug the

power plug.

• Failing to do so may result in electric shock or re.

For waterproof fabrics, only use the WATERPROOF cycle.

• Do not use other cycles for waterproof fabrics. This may result in injury or damage to

the washer, walls, oor, or clothing due to abnormal vibrations.

• Set the temperature and spin according to the attached care label.

• WARNING : Failure to closely follow these instructions may result in an abnormal

vibrating and out-of-balance condition that could result in physical injury, property

damage, and/or appliance damage.

Usage cautions

CAUTION

If the washer is contaminated by a foreign substance such as detergent, dirt, food waste,

etc., unplug the power plug and clean the washer using a damp, soft cloth.

• Failing to do so may result in discoloration, deformation, damage, or rust.

The clear portion of the lid can be broken by a strong impact. Take care when using the

washer.

• If the clear portion is cracked or broken, it may result in injury.

After a water supply failure or when reconnecting the water supply hose, open the faucet

slowly.

Open the faucet slowly after a long period of non-use.

Untitled-1 9Untitled-1 9 2022-01-25  2:57:252022-01-25  2:57:25

SAVE THESE INSTRUCTIONS

Safety information

English10

Safety information

• The air pressure in the water supply hose or the water pipe may result in damage to a

part or in water leakage.

If a drain error occurs during an operation, check if there is a draining problem.

• If the washer is used when it is ooded because of a draining problem, it may result in

electric shock or re due to electric leakage.

Do not insert your hand under the washer.

• This may result in injury.

Insert the laundry into the washer completely so that laundry does not get caught in the

lid.

• If laundry gets caught in the lid, it may result in damage to the laundry or the washer,

or result in water leakage.

Ensure that the faucet is turned off when the washer is not being used.

• Ensure that the water supply hose connectors are properly tightened.

• Failing to do so may result in property damage or injury.

Open the faucet and check if the water supply hose connector is rmly tightened and that

there is no water leaking before using the product.

• If the water supply hose connectors are loose, it may result in water leakage.

Do not stand on top of the appliance or place objects (such as laundry, lighted candles,

lighted cigarettes, dishes, chemicals, metal objects, etc.) on the appliance.

• This may result in electric shock, re, problems with the product, or injury.

Do not operate the appliance with wet hands.

• This may result in electric shock.

Do not spray volatile material such as insecticide onto the surface of the appliance.

• As well as being harmful to humans, it may also result in electric shock, re, or

problems with the product.

Do not place an object that generates an electromagnetic eld near the washer.

• This may result in injury due to a malfunction.

Since the water drained during a high-temperature wash or drying cycle is hot, do not

touch the water.

• This may result in burns or injury.

Do not operate the washer if the detergent dispenser is removed.

• This may result in electric shock or injury due to water leakage.

Untitled-1 10Untitled-1 10 2022-01-25  2:57:252022-01-25  2:57:25

This manual suits for next models

Table of contents

Languages:

Other Samsung Washer manuals

Samsung

Samsung WW80H5290E Series User manual

Samsung

Samsung WF8602SEA User manual

Samsung

Samsung WF42H5700A Series User manual

Samsung

Samsung WD1162XVM User manual

Samsung

Samsung WF80F5 series User manual

Samsung

Samsung WA54R7600AC User manual

Samsung

Samsung WF45R6100AW User manual

Samsung

Samsung WF431ABP User manual

Samsung

Samsung WF1124ZA(C/U) User manual

Samsung

Samsung WF42H5200AP User manual

Samsung

Samsung WA54M8750A SERIES User manual

Samsung

Samsung WA85J571 Series User manual

Samsung

Samsung WB30H7 Series User manual

Samsung

Samsung WA50B5100AW User manual

Samsung

Samsung WD-Q1456 User manual

Samsung

Samsung WD10N84 Series User manual

Samsung

Samsung WF428AAW User manual

Samsung

Samsung WA10J7750GW/SA User manual

Samsung

Samsung WF- Series User manual

Samsung

Samsung WA422PRHD Series User manual

Samsung

Samsung WA49B5105 Series User manual

Samsung

Samsung WW6 J4 Series User manual

Samsung

Samsung WF42H5000A User manual

Samsung

Samsung WA14R6380B Series User manual

Popular Washer manuals by other brands

Tricity Bendix

Tricity Bendix AW 1000 W Operating & installation instructions

Panasonic

Panasonic NA-F60L5WRB operating instructions

GE WSLP1500 Dimensions and installation information

Electrolux

Electrolux EWF1284EDW Service manual

Bosch

Bosch WAN2829BSN User manual and installation instructions

LG TV2516DV3B owner's manual

LG TH2517DSAV owner's manual

VESTEL

VESTEL CMH-XL 7510 TE user manual

AEG

AEG 74335 User information

Johnson

Johnson JWF721A user manual

Beko

Beko WTE7604XLW0 owner's manual

Danby

Danby DTT100A1WDB Owner's use and care guide

Amica

Amica WA 14 Ex operating instructions

Daewoo

Daewoo DWD-F1222 instruction manual

Bosch

Bosch WAS28461AU instruction manual

Miele

Miele PW 6080 Vario manual

Finlux

Finlux FLX108CF220 user manual

Whirlpool

Whirlpool 3LBR5132AN0 Use and care guide
