Samsung EO-SG928 User manual
www.samsung.com
User Manual
English (EU). 09/2015. Rev.1.0
EO-SG928
2
Table of Contents
Read me first
Getting started
4 Package contents
5 Device layout
6 Charging the battery
7 Turning the Bluetooth speaker on or
off
8 Notification light identification
Using the Bluetooth
speaker
9 Bluetooth
10 Connecting to another device
12 Connecting additional devices
13 Reconnecting or disconnecting device
14 Using the Bluetooth speaker
15 Using the ultra high quality Bluetooth
(UHQ-BT) feature
16 Sharing audio via Dual Sound
Appendix
17 Troubleshooting
19 Removing the battery
3
Read me first
Please read this manual before using the device to ensure safe and proper use.
•
Images may differ in appearance from the actual product. Content is subject to change
without prior notice.
•
Before connecting the Bluetooth speaker to your other device, make sure the other
device is compatible with the Bluetooth speaker.
Instructional icons
Warning: situations that could cause injury to yourself or others
Caution: situations that could cause damage to your device or other equipment
Notice: notes, usage tips, or additional information
4
Getting started
Package contents
Check the product box for the following items:
•
Bluetooth speaker
•
Quick start guide
•
The items supplied with the device and any available accessories may vary
depending on the region or service provider.
•
The supplied items are designed only for this device and may not be compatible
with other devices.
•
Appearances and specifications are subject to change without prior notice.
•
You can purchase additional accessories from your local Samsung retailer. Make
sure they are compatible with the device before purchase.
•
Use only Samsung-approved accessories. Using unapproved accessories may cause
the performance problems and malfunctions that are not covered by the warranty.
•
Availability of all accessories is subject to change depending entirely on
manufacturing companies. For more information about available accessories, refer
to the Samsung website.
Getting started
5
Device layout
Speaker
Volume (+) button
Power button
Multifunction
button
Volume (-) button
Audio cable jack
Charger port
Buttons and functions
Name Function
Power button
•
Press and hold to turn the Bluetooth speaker on or off.
Multifunction
button
•
Press and hold for approximately three seconds to enter Bluetooth
pairing mode.
•
Press to reconnect devices when the connection is lost.
•
Press to play or pause multimedia files.
Volume buttons
•
Press to adjust the volume during media playback.
•
Press and hold the Volume (+) button to skip to the next file during
media playback.
•
Press and hold the Volume (-) button to skip to the previous file
during media playback.
Getting started
6
Charging the battery
This Bluetooth speaker has a built-in battery. Before using the Bluetooth speaker for the
first time or when the battery has been unused for extended periods, you must charge the
battery.
Use only Samsung-approved chargers (5 V/2 A or higher) and cables. Unapproved
chargers or cables can cause the battery to explode or damage the Bluetooth speaker.
If the battery is completely discharged, the Bluetooth speaker cannot be turned on
immediately when the charger is connected. Allow a depleted battery to charge for a
few minutes before turning on the Bluetooth speaker.
Connect the Bluetooth speaker to the USB power adaptor via the USB cable. Plug the USB
power adaptor into an electric socket.
•
The notification light turns red while the Bluetooth speaker is being charged. The
notification light turns green when charging is complete.
Connecting the charger improperly may cause serious damage to the Bluetooth
speaker. Any damage caused by misuse is not covered by the warranty.
Getting started
7
•
The Bluetooth speaker can be used while it is charging, but it may take longer to
fully charge the battery.
•
While charging, the Bluetooth speaker may heat up. This is normal and should not
affect the Bluetooth speaker’s lifespan or performance. If the battery gets hotter
than usual, the charger may stop charging.
•
If the Bluetooth speaker is not charging properly, take the Bluetooth speaker and
the charger to a Samsung Service Centre.
After fully charging, first unplug the USB cable from the Bluetooth speaker, and then unplug it
from the computer or the electric socket.
•
To save energy, unplug the charger when not in use. The charger does not have a
power switch, so you must unplug the charger from the electric socket when not in
use to avoid wasting power. The charger should remain close to the electric socket
and easily accessible while charging.
•
The socket-outlet shall be installed near the equipment and shall be easily
accessible.
Turning the Bluetooth speaker on or off
Press and hold the Power button to turn the Bluetooth speaker on or off.
Follow all posted warnings and directions from authorised personnel in areas where
the use of wireless devices is restricted, such as aeroplanes and hospitals.
Getting started
8
Notification light identification
The notification light alerts you to the Bluetooth speaker’s status.
Status Colour
Power on
•
Flashes green three times
Bluetooth pairing
mode
•
Flashes red and blue
Connected via
Bluetooth
•
Continuously on blue
Charging
•
Continuously on red
Fully charged
•
Continuously on green
Power off
•
Flashes red three times
During use or in
sleep mode
•
Off (If the remaining battery power is less than 10%, the light
continuously flashes red.)
•
If the notification light does not work as described, disconnect the charger from
the Bluetooth speaker and reconnect it.
•
The notification light may work differently depending on the connected device.
9
Using the Bluetooth speaker
Bluetooth
About Bluetooth
Bluetooth is a wireless technology standard that uses a 2.4 GHz frequency to connect to
various devices over short distances. It can connect and exchange data with other Bluetooth
enabled devices, such as mobile devices, computers, printers, and other digital home
appliances, without connecting via cables.
Notices for using Bluetooth
•
To avoid problems when connecting your Bluetooth speaker to another device, place the
devices close to each other.
•
Ensure that your Bluetooth speaker and the other Bluetooth device are within
the Bluetooth connection range (10 m). The distance may vary depending on the
environment the devices are used in.
•
Ensure that there are no obstacles between the Bluetooth speaker and a connected
device, including human bodies, walls, corners, or fences.
•
Do not touch the Bluetooth antenna of a connected device.
•
Bluetooth uses the same frequency as some industrial, scientific, medical, and low power
products and interference may occur when making connections near these types of
products.
•
Some devices, especially those that are not tested or approved by the Bluetooth SIG, may
be incompatible with your Bluetooth speaker.
•
Do not use the Bluetooth feature for illegal purposes (for example, pirating copies of files
or illegally tapping communications for commercial purposes).
Using the Bluetooth speaker
11
Connecting via Bluetooth
1 Bluetooth speaker Press and hold the Power button to turn on the Bluetooth speaker.
2 Bluetooth speaker Press and hold the Multifunction button for approximately three
seconds to enter Bluetooth pairing mode.
When you turn on the Bluetooth speaker for the first time, it automatically enters
Bluetooth pairing mode.
3 Other device Activate the Bluetooth feature and search for Bluetooth devices.
For more information, refer to the other device’s user manual.
4 Other device Tap
Samsung Level Box Pro (0000)
from the list of available devices.
•
The PIN for the Bluetooth speaker is the four-digit number in parenthesis displayed
on the other device’s Bluetooth settings screen. The number differs depending on
the Bluetooth speaker.
•
Once devices are paired, recently connected devices automatically connect to your
Bluetooth speaker whenever you turn it on.
•
If the Bluetooth connection fails or the other device cannot locate the Bluetooth
speaker, remove the device’s information from the other device’s list. Then, try to
connect again.
•
The Bluetooth connection range and sound quality may vary depending on the
connected devices.
