Samsung LE32C579J1S User manual
English - 1
The Supplied Accessoris¦
Remote Control & Batteries (AAA x 2)
y
Owner’s Instructions
y
Warranty Card / Safety Guide (Not available in some locations)y
Cleaning Cloth
y
Power Cord
y
(46 inch TV)
Blanking Bracket
yCable tie
yHolder-Ring (4ea)
y
See separate guide for installing the stand.
Stand (1EA)
yGuide Stand (1EA)
yScrews (9EA)
y
Installing Batteries in the Remote Control¦
LCD TV
QUICK SETUP GUIDE
(M4 X L12)
NOTE
✎
Use the remote control within 23 feet from
x
the TV.
Bright light may affect the performance
x
of the remote control. Avoid using nearby
special fluorescent light or neon signs.
The colour and shape may vary depending
x
on the model.
BN68-02800A-00
BN68-02801A
BN68-02800A_00Eng_UK QSG.indd 1 2010-03-11 �� 7:06:56
English - 2
Installing the Stand¦
Preset
✎
: Place the Guide Stand and Cover Neck onto the stand and fasten it using the screws. Applicable to models
(Depending on the model)
Step 1. Attach your LCD TV to the stand.
Two or more people should carry the TV.
✎
Make sure to distinguish between the front and back of the stand when assembling them.
✎
To make sure the TV is installed on the stand at a proper level, do not apply excess downward pressure to the
✎
upper left of right sides of the TV.
Step 2. Fasten two screws at position 1 and then fasten two screw at position 2.
Stand the product up and fasten the screws. If you fasten the screws with the LCD TV placed down, it may lean to
✎
one side.
Assembling the Cables¦
Enclose the cables in the Cable tie so that the cables are not visible through the transparent
stand.
Overly rigid or thick cables can damage input jacks over long term use.
Using the remote control buttons¦
A
B
C
D
HDMI
P.MOD
E
S.MOD
E
DUAL
I
-
II
SU
BT.
SO
UR
C
E
0
MEDIA.P
G
UID
E
C
H LI
S
T
Rear
Front
ENTER
E
/ Direction Button
Move the cursor and select an item.
Select the currently selected item.
Confirm the setting.
EXIT Button
Exit the on-screen menu
MENU Button
Displays the favourites channel list.
RETURN Button
Returns to the previous menu
Cable tie
Rear
Front
Preset Step 1 Step 2
BN68-02800A_00Eng_UK QSG.indd 2 2010-03-11 �� 7:06:58
English - 3
Plug & Play¦
When the TV is initially powered on, basic settings proceed automatically and subsequently.
If you want to reset this feature, press the MENU button to display menu.
You can set the Plug & Play by selecting Setup →Plug & Play.
On the screen, you can set as follows.
The each step may vary depending on the Antenna source.
✎
Plug & Play
Select the OSD Language.
E
Enter
Menu Language
: English
►
Step 1
Step 4
Step 3
Plug & Play
Select Country.
Previous
E
Enter
Country
: United Kingdom
►
Step 2
Plug & Play
Store Demo Home USE
Previous
L
Move
E
Enter
Step 7
Step 5 Step 6
Step 8
Plug & Play
HD Connection Guide
How to get the best performance from your new HDTV.
Step 1. Connect the HD Box to the TV using the HDMI or Component
cables.
HD box
TV rear view
1/2
Component Cable
Previous
Skip
r
Next Page
HDMI Cable
Enjoy your TV.
Select the usage mode.
Plug & Play
Serch
Previous
Skip
U
Move
E
Enter
Antenna Source
: Air
►
Channel Source
: Digital & Analogue
Plug & Play
Stop
E
Enter
Auto Store in progress.
Digital 2
TV:2 Radio:0 Data/Other: 0
Analogue 0
Channels 7
3%
Plug & Play
Set the Clock Mode.
Previous
Skip
E
Enter
Clock Mode
: Auto
►
OK
Power Input
VHF/UHF Antenna
Cable
R-AUDIO-L PRPBY
ANT OUT
or
BN68-02800A_00Eng_UK QSG.indd 3 2010-03-11 �� 7:07:01
English - 4
Connecting a AV device¦
R
B
G
WR
W R
RBG
WY R
WY
R
HD connection
DVD / Blu-Ray player / Cable Box
/ Satellite receiver (STB)
Using a DVI Cable
AUDIO OUT DVI OUT
HD connection
DVD / Blu-Ray player / HD Cable Box
/ HD Satellite receiver (STB)
Using an HDMI Cable
HDMI OUT
Audio/Video connection
VCR
Using an Audio/Video Cable
AUDIO OUTVIDEO OUT
Component connection
DVD / Blu-Ray player / Cable
Box / Satellite receiver
Using a Component Cable
AUDIO OUT COMPONENT OUT
VCR / DVD
Using a Scart Cable
EXT
BN68-02800A_00Eng_UK QSG.indd 4 2010-03-11 �� 7:07:04
