Samsung DMT300 Series Installation guide

Dishwasher

DMT300 series training

Jan 2010

Kitchen Solution Business Team

I. General Specification

a) Features and functions

b) Specification

II. Hardware

a) Wiring diagram

b) Schematic

III. Disassembly

IV. Trouble Shooting

a) Error message

b) Trouble shooting flow

c) Error Trouble shooting

V. Reference

Contents

Agenda

General Specification

Main

Features

Capacity: 14 place settings

Control panel design

- Front type + Button operation.

Dimension (W x D x H) : 23-7/8 x 24-3/4 x 33-7/8 inch (605 x 627 x 860 mm )

Sales Point

Flexible Style : Inclined Rack System, Height adjustable Upper Basket

Upgraded Kitchen : Pleasant kitchen environment, Simple & Modern design

Smart Control : Soil sensing Programming, ABS door system

Features

Dishwasher

Features

Functions

Control Panel

Specification

Product Main Specification

MODELname DMT300RFS, DMT300RFB, DMT300RFW

Power supply Single phaseAC 110V / 60Hz

Water pressure 140 ~ 830 kPa (20 ~ 120 psi)

Wash method Rotating nozzle spray type

Dry method Air vent dry system

Power consumption Standard cycle: 1.03 KWh ±10%

Power

Circulation Motor :185W±15% or below

Heater : 1100W±10% or below

Drain Pump : 45W±15% or below

Fan Motor : 5.5W±15% or below

Water consumption 3.9~7.9 gallon(14.8~30ℓ), Normal cycle

Specification

DMT300RFS DMR57LFS(Basic)

Spec

Capacity 14 place settings 14 place settings

Display None Graphic LED

Control Type Tact Button Touch Sensor

Inlay - -

Washing Program

Normal, Heavy,

Delicate, Quick

Normal, Heavy,

Delicate, Rinse

Sanitize Delay Start, Sanitize

Inlet Water Exclusively for hot water Exclusively for hot water

Basket Color Gray Color (Nylon Coating) Gray Color (Nylon Coating)

Basket Stair Style Basket Stair Style Basket

Sensor Inlet/Temp/Water Level/Rinse/Leakage Inlet/Temp/Water Level/Rinse/Leakage

Rinse Supplement

Direction Yes Yes

Half Load No No

Filter 3-stage (Disposer Type) 3-stage (Disposer Type)

Heater Type Internal Type(1100W) Internal Type(1100W)

Dry Type Air Vent Dry system Fan driven condensing system

Program Lock Child Lock Button Child Lock Button

Reservation No 1~24hr

SIZE 605×627×860mm (W×H×D)

23-7/8 x 24-3/4 x 33-7/8 inch

605×627×860mm (W×H×D)

23-7/8 x 24-3/4 x 33-7/8 inch

Wiring Diagram

Schematic diagram

Schematic
