Samsung SCX-4833FD User manual

SCX-483x Series

SCX-563x Series

SCX-573x Series

User’s Guide

Basic

imagine the possibilities

This guide provides information concerning installation, basic operation and

troubleshooting on windows

Contents



1. Introduction

5Key benefits

7Features by models

8Useful to know

9About this user’s guide

10 Safety information

16 Machine overview

21 Control panel overview

28 Turning on the machine

29 Installing the driver locally

30 Reinstalling the driver



2. Menu overview and basic setup

32 Menu overview

48 Changing the display language

49 Media and tray

64 Basic printing

71 Basic copying

75 Basic scanning

77 Basic faxing

82 Using USB memory device

3. Maintenance

90 Ordering supplies and accessories

91 Available supplies

92 Available accessories

94 Available maintenance parts

95 Redistributing toner

97 Replacing the toner cartridge

99 Upgrading a memory module

101 Monitoring the supplies life

102 Setting the toner low alert

103 Cleaning the machine



4. Troubleshooting

108 Tips for avoiding paper jams

109 Clearing original document jams

116 Clearing paper jams

123 Understanding the status LED

125 Understanding display messages



5. Appendix

133 Specifications

Contents 3

143 Regulatory information

157 Copyright

1. Introduction

This chapter provides information you need to know before using the

machine.

•Keybenefits 5

•Featuresbymodels 7

•Usefultoknow 8

• About this user’s guide 9

• Safety information 10

• Machine overview 16

• Control panel overview 21

• Turning on the machine 28

• Installing the driver locally 29

• Reinstalling the driver 30



Key benefits

Environmentally friendly

• To save toner and paper, this machine supports Eco feature.

• To save paper, you can print multiple pages on one single sheet of

paper (see Advanced Guide).

• To save paper, you can print on both sides of the paper (double-

sided printing) (see Advanced Guide).

• To save electricity, this machine automatically conserves electricity

by substantially reducing power consumption when not in use.

Fast high resolution printing

• You can print with a resolution of up to 1,200 x 1,200 dpi effective

output.

• Fast, on-demand printing.

SCX-483x Series:

- For single-side printing, 31 ppm (A4) or 33 ppm (Letter).

- For duplex printing, 15 ppm (A4) or 16 ppm (Letter).

SCX-563x Series or SCX-573x Series:

- For single-side printing, 35 ppm (A4) or 37 ppm (Letter).

- For duplex printing, 17 ppm (A4) or 18 ppm (Letter).

Convenience

• Printing Status (or Smart Panel) is a program that monitors and

informs you of the machine’s status and allows you to customize the

machine’s settings (see Advanced Guide).

• AnyWeb Print helps you screen-capture, preview, scrap, and print

the screen of Windows Internet Explorer more easily, than when you

use the ordinary program (see Advanced Guide).



Key benefits

Wide range of functionality and application support

• Supports various paper sizes (see "Print media specifications" on page 135).

• Print watermark: You can customize your documents with words, such as “Confidential” (see Advanced Guide).

• Print posters: The text and pictures of each page of your document are magnified and printed across the multiple sheets of paper and can then

be taped together to form a poster (see Advanced Guide).

• You can print in various operating systems (see "System requirements" on page 138).

• Your machine is equipped with a USB interface and/or a network interface.

Expand your machine’s capacity

• This machine has an extra memory slot for adding more memory (see "Available accessories" on page 92).

• Zoran IPS Emulation compatible with PostScript 3 (PS) enables PS printing.

• Zoran IPS Emulation compatible with PostScript 3

Corporation.

• 136 PS3 fonts

•ContainsUFSTand Micro from Mono Imaging Inc.



Features by models

Some features and optional goods may not be available depending on model or country.

( ●: Included, ○: Optional, Blank: Not available)

Features

SCX-4833FD

SCX-4835FD

SCX-4833HD

SCX-4833FR

SCX-4835FR

SCX-5637FR

SCX-5639FR

SCX-5637HR

SCX-5737FW

SCX-5739FW

Print, Copy, Scan, Fax ● ● ● ●

Hi-Speed USB 2.0 ● ● ● ●

IEEE 1284 Parallel ○ ○ ○ ○

Network Interface Ethernet 10/100 Base TX wired LAN ●

Network Interface Ethernet 10/100/1000 Base TX wired LAN ● ● ●

Network Interface 802.11b/g/n wireless LAN ●

Eco printing ● ● ● ●

Duplex (2-sided) printing ● ● ● ●

Samsung Easy Printer Manager ● ● ● ●

Memory ○ ○ ○ ○

Tray 2 (520 sheets) ○ ○ ○ ○

SyncThru™ Web Service ● ● ● ●

Automatic Document Feeder (ADF) ●

Dual Automatic Document Feeder (DADF) ● ● ●

Useful to know

Where can I download the machine’s driver?

• Visit www.samsung.com/printer to download the latest

machine’s driver, and install it on your system.

Where can I purchase accessories or supplies?

• Inquire at a Samsung distributor or your retailer.

• Visit www.samsung.com/supplies. Select your country/

region to view product service information.

The status LED flashes or remains constantly on.

• Turn the product off and on again.

• Check the meanings of LED indications in this manual

and troubleshoot accordingly (see "Understanding the

status LED" on page 123).

A paper jam has occurred.

• Open and close the front door.

• Check the instructions on removing jammed paper in this

manual and troubleshoot accordingly (see "Clearing

paper jams" on page 116).

Printouts are blurry.

• The toner level might be low or uneven. Shake the toner

cartridge.

• Try a different print resolution setting.

• Replace the toner cartridge.

The machine does not print.

• Open the print queue list and remove the document from

the list (see "Canceling a print job" on page 65).

• Remove the driver and install it again (see "Installing the

driver locally" on page 29).

• Select your machine as your default machine in your

Windows.

1. Introduction

About this user’s guide

This user's guide provides information for your basic understanding

of the machine as well as detailed steps to explain machine usage.

• Read the safety information before using the machine.

• If you have a problem using the machine, refer to the

troubleshooting chapter.

• Terms used in this user’s guide are explained in the glossary

chapter.

• All illustrations in this user’s guide may differ from your machine

depending on its options or model you purchased.

• The procedures in this user’s guide are mainly based on Windows

• SCX-4833FD, SCX-4833HD and SCX-4835FD are the same series

machine. This User’s Guide is written on the basis of SCX-4833FD.

• SCX-4833FR and SCX-4835FR are the same series machine. This

User’s Guide is written on the basis of SCX-4833FR.

• SCX-5637FR, SCX-5637HR and SCX-5639FR are the same series

machine. This User’s Guide is written on the basis of SCX-5637FR.

• SCX-5737FW and SCX-5739FW are the same series machine. This

User’s Guide is written on the basis of SCX-5737FW.



Conventions

Some terms in this guide are used interchangeably, as below:

• Document is synonymous with original.

• Paper is synonymous with media, or print media.

• Machine refers to printer or MFP.



General icons

Icon Text Description

Caution

Gives users information to protect the

machine from possible mechanical damage

or malfunction.

Note

Provides additional information or detailed

specification of the machine function and

feature.

1. Introduction

Safety information

These warnings and precautions are included to prevent injury to

you and others, and to prevent any potential damage to your

machine. Be sure to read and understand all of these instructions

before using the machine. After reading this section, keep it in a safe

place for future reference.



Important safety symbols

Explanation of all icons and signs used in this chapter



Operating environment

Warning

Warning Hazards or unsafe practices that may result in

severe personal injury or death.

Caution Hazards or unsafe practices that may result in

minor personal injury or property damage.

Do not attempt.

Do not use if the power cord is damaged or if the

electrical outlet is not grounded.

This could result in electric shock or fire.

Do not place anything on top of the machine (water,

small metal or heavy objects, candles, lit cigarettes, etc.).

This could result in electric shock or fire.

• If the machine gets overheated, it releases smoke,

makes strange noises, or generates an odd odor,

immediately turn off the power switch and unplug the

machine.

• The user should be able to access the power outlet in

case of emergencies that might require the user to pull

the plug out.

This could result in electric shock or fire.

Do not bend, or place heavy objects on the power cord.

Stepping on or allowing the power cord to be crushed by

a heavy object could result in electric shock or fire.
