1. Precautions

2. Product Specications

3. Alignment and Adjustments

4. Disassembly and Reassembly

5. ASSY CONTROL

6. Wiring Diagram

7. PCB Diagram

8. Operating Instructions

9. Troubleshooting

10. Block Diagram

11. Reference Sheet

AIR CONDITIONER CONTENTS

SPLIT-TYPE AIR CONDITIONER

OUTDOOR UNIT

MODEL CODE

INDOOR UNIT

AR07TXFYAWKNEU

AR07TXHZAWKNEU

AR09TXFYAWKNEU

AR12TXFYAWKNEU

AR09TXHZAWKNEU

AR12TXHZAWKNEU

AR18TXFYAWKNEU

AR18TXHZAWKNEU

AR24TXFYAWKNEU

AR24TXHZAWKNEU

AR09TXFYAWKXEU

AR12TXFYAWKXEU

AR09TXHZAWKXEU

AR12TXHZAWKXEU

AR18TXFYAWKXEU

AR18TXHZAWKXEU

AR24TXFYAWKXEU

AR24TXHZAWKXEU

AR**TXHZWKNEUAR**TXFYWKNEU

AR09TX**WKNEU

AR12TX**WKNEU

AR18TX**WKNEU

AR24TX**WKNEU

Contents

1. Precautions 4

1-1 Installing the air conditioner 4

1-2 Power supply and circuit breaker 4

1-3 During operation 4

1-4 Disposing of the unit 5

1-4 Others 5

2. Product Specications 6

2-1 The Feature of Product 6

2-2 Product Specifications 7

2-3 The comparative specifications of product 9

2-4 Accessory and option specifications 10

3. Alignment and Adjustments 11

3-1 Test mode 11

3-2 Display Error and Check Method 13

3-3 Setting Option Setup Method 14

4. Disassembly and Reassembly 18

4-1 Indoor Unit 19

4-2 Outdoor Unit (N-V2MD) 29

4-2 Outdoor Unit (Q) 35

5. ASSY CONTROL 40

5-1 ASSY KIT CODE DB92-048545B,F 40

5-2 ASSY KIT CODE DB92-04842A 41

5-3 ASSY KIT CODE DB92-04843A 42

5-2 ASSY KIT CODE DB92-04849A 44

6. Wiring Diagram 46

6-1 Indoor unit 46

6-2 Outdoor unit 47

7. PCB Diagram 48

7-1 Indoor main PCB 48

7-2 Outdoor main PCB 49

7-3 DISPLAY PCB 51

7-4 Wire connecting the indoor unit terminal blocks 52

2 3

Contents

8. Operating Instructions 53

8-1 Name of Each Part 53

8-2 Wireless Remote Control-Buttons and Display 55

9. Troubleshootin 56

9-1 Items to be checked First 56

9-2 Communication Error 57

9-2-1 Communication Error 57

9-2-2 Indoor temperature sensor Error 58

9-2-3 Indoor fan motor speed detecting error (BLDC fan) 59

9-2-4 Outdoor temperature sensor error 60

9-2-5 Outdoor Cond temperature sensor error 61

9-2-6 Outdoor Discharge temperature sensor error 62

9-2-7 Operation condition secession error 63

9-2-8 EEPROM error/OTP error 64

9-2-9 Outdoor Fan motor error 65

9-2-10 Compressor starting error 66

9-2-11 Compressor wire missing error/rotation error 67

9-2-12 Current sensor error/Input current sensor error 68

9-2-13 O.C(Over Current) error 69

9-2-14 No power outdoor (Initial Diagnosis) (Not displayed) 71

9-2-15 When the Up/Down, Left/Right, Grill louver motor does not operate 72

9-2-16 When the remote control is not receiving 73

9-2-17 Smart Install error 74

9-2-18 Outdoor OLP over temperature error (One way Inverter Only) 75

10. Block Diagram 76

10-1 Indoor unit 76

10-2 Outdoor unit 77

11. Reference Sheet 80

11-1 Low Refrigerant Pressure Distribution 80

11-2 Pressure & Capacity mark 80

11-3 Q & A for Non-trouble 81

11-4 Cleaning /Filter Change 84

11-5 Installation 87

11-6 Installation Diagram of Indoor Unit and Outdoor Unit 88

11-7 Reference sheet 91

1-1 Installing the air conditioner

• Uses should not install the air conditioner by themselves. Ask the dealer or authorized company to install

the air conditioner except window-type air conditioner in U.S.A and Canada.

• If you don't install the air conditioner properly, it may cause a fire, a water leakage or an electric shock.

• You must install the air conditioner according to the national wiring regulations and safety regulations.

• Install the indoor unit higher than 2.5m from the floor to avoid the injury caused by the operation of the fan.

(except the window-type air conditioner)

• The manufacturer is not responsible for any accidents or injury caused by an incorrect installation.

• When installing the built-in type air conditioner, keep all electric cables such as the power cable and the

connection cord in pipes, ducts, or cable channels to protect them from the danger of impact or any other

incidents.

1-2 Powersupply and circuit breaker

• If the power cord of the air conditioner is damaged, it must be replaced by the manufacturer or a qualified

person in order to avoid a hazard.

• The air conditioner must be plugged into an independent circuit if applicable or connect the power cable to

the auxiliary circuit breaker. An all pole disconnection form the power supply must be incorporated in the

fixed wiring with a contact opening of>3mm.

• Do not extend an electric cord to the air conditioner.

• The air conditioner must be plugged in after you complete the installation.

1-3 During operation

• Do not repair the air conditioner at your discretion. It is recommended to contact a service center directly.

• Never spill any kind of liquid on the air conditioner. If this happens, turn off the air conditioner and contact

an authorized service center.

• Do not insert anything between the airflow blades to prevent damage of the inner fan and consequent

injury. Keep children away from the air conditioner.

• Do not place any obstacles in front of the air conditioner.

• Do not spray any kind of liquid into the indoor unit. If this happens, turn off the air conditioner and contact

a service center.

• Make sure that the air conditioner is well ventilated at all times. Do not place a cloth or other materials over

it.

• Remove the batteries if you don't use the remote control for a long time. (If applicable)

• Use the remote control within 7 meters from the indoor unit. (If applicable)

1. Precautions

1-4 Disposing of the unit

• Before the throwing out the air conditioner, remove the batteries from the remote control.

• When you dispose of the air conditioner, consult your dealer. If pipes are removed incorrectly, refrigerant

may blow out and cause air pollution. When it contacts with your skin, it can cause skin injury.

• The package of the air conditioner should be recycled or disposed of properly for environmental reasons.

1-5 Others

• Never store or load the air conditioner upside down or sideways to prevent the damage to the compressor.

• Young children or infirm persons should be always supervised when they use the air conditioner.

• Max current is measured according to IEC standard for safety.

• Current is measured according to ISO standard for energy efficiency.

2-1 The Feature of Product

uFast cooling

If you want the strong and cool air, just select Fast function! It will get you the strongest air!

uWind-Free Cooling

Use the Wind-Free Cooling function to enjoy a mild breeze coming through ne holes

in the Wind-Free panel instead of air coming directly through the air ow blades.

uMotion detection

Use the motion detection function to make the air conditioner detect people and blow

air directly or indirectly. With no detection, energysaving mode is operated.

uEco

Use the Single User function when you’re along at home. Aside from energy savings from the

inverter technology, the Single User Mode will further minimize your energy consumption and

reduce your electricity bill by adjusting the maximum operating capacity of the compressor.

uEasy Filter

There is no grille to remove before separating the lter from the air conditioner! Therefore, lter

can be cleaned easily and more frequently. Constant lter cleaning will prevent dust from enter-

ing the product or accumulating on the lter.

ugood’sleep function

good’sleep function will allow you to have deep, good night’sleep by adjusting the temperature,

fan speed and air ow direction.

uSmart Install

When the installation is done, your product will examine itself through trial operation to check if

it was installed properly.

uEasy Installation

It’s so easy to install! You can easily hang the product on the wall and connect the pipes

and wires by opening the cover on the bottom of the product. Now you won’t have to tilt

the product to connect the pipe and the wires!

2. Product Specications

2-2 Product specication

Model AR09TXFYAWK/EU AR12TXFYAWK/EU AR09TXHZAWK/EU AR12TXHZAWK/EU

Rating Mode Unit Wall-mounted Wall-mounted Wall-mounted Wall-mounted

Capacity

T1 Cool W 2500 3500 2500 3500

T3 Cool W - - - -

Heat W 3200 3500 3200 3500

Power Input

T1 Cool W 700 1220 700 1220

T3 Cool W - - - -

Heat W 840 940 840 940

Current

T1 Cool A 3.6 5.6 3.6 5.6

T3 Cool A - - - -

Heat - 4 4.5 44.5

Efciency

EER W/W 3.57 2.87 3.57 2.87

- - - - -

COP W/W 3.81 3.72 3.81 3.72

Dehumidifying l/hr. 1 1.5 11.5

Platform IDU - Q1 Q1 Q1 Q1

ODU - N-V2MD N-V2MD N-V2MD N-V2MD

Evap

Main - Φ7, 2R*9(10)S*591mm,

H1.3, N.G.S, 1by2

Φ7, 2R*9(10)S*591mm,

H1.3, N.G.S, 1by2

Φ7, 2R*9(10)S*591mm,

H1.3, N.G.S, 1by2

Φ7, 2R*9(10)S*591mm,

H1.3, N.G.S, 1by2

Sub -Φ7, 2R*5(6)S*591mm, H1.3,

N.G.S : (Q-1-5)

Φ7, 2R*5(6)S*591mm, H1.3,

N.G.S : (Q-1-5)

Φ7, 2R*5(6)S*591mm, H1.3,

N.G.S : (Q-1-5)

Φ7, 2R*5(6)S*591mm, H1.3,

N.G.S : (Q-1-5)

Cond

Main -

Φ7W, 2R*20(21)

S*639/611mm, Corru-

gate1.5, N.G.S, 4by4by2

Φ7W, 2R*20(21)

S*639/611mm, Corru-

gate1.5, N.G.S, 4by4by2

Φ7W, 2R*20(21)

S*639/611mm, Corru-

gate1.5, N.G.S, 4by4by2

Φ7W, 2R*20(21)

S*639/611mm, Corru-

gate1.5, N.G.S, 4by4by2

Sub - - - - -

Comp Model - UB1AR5090FJ6 UB1AR5090FJ6 UB1AR5090FJ6 UB1AR5090FJ6

OLP - - - - -

Motor In Code - DB31-00694A DB31-00694A DB31-00694A DB31-00694A

Name - - - - -

Motor Out Code - DB31-00693A DB31-00693A DB31-00693A DB31-00693A

Name - - - - -

Expansion Φ * L -EEV Φ1.3 EEV Φ1.3 EEV Φ1.3 EEV Φ1.3

Refrigerant type - R-32 R-32 R-32 R-32

charge g 700 g 700 g 700 g 700 g

SVC Valve Liquid /

Gas - 6.35/ 9.52 6.35/ 9.52 6.35/ 9.52 6.35/ 9.52

Tube Dis. / Suc. - 7.94/9.52 7.94/9.52 7.94/9.52 7.94/9.52

Drain hose D * L mm 20*550 20*550 20*550 20*550

4-WAY V/V - 1HP 1 HP 1HP 1 HP

Power Supply V/Hz/Φ 220-240/50/1 220-240/50/1 220-240/50/1 220-240/50/1

Climate Class - T1 T1 T1 T1

Noise IDU UT,T dB 41 43 41 43

ODU dB 53 53 53 53

Net Size

(W*D*H)

IDU mm 820*299*215 820*299*215 820*299*215 820*299*215

ODU 660*475*242 660*475*242 660*475*242 660*475*242

Weight IDU kg 8.6 8.6 8.6 8.6

ODU 19.4 19.4 19.4 19.4

Operation

range

Cooling IDU 16 ˚C~32 ˚C 16 ˚C~32 ˚C 16 ˚C~32 ˚C 16 ˚C~32 ˚C

ODU -10 °C to 46 °C -10 °C to 46 °C -10 °C to 46 °C -10 °C to 46 °C

Heating IDU 27 °C or less 27 °C or less 27 °C or less 27 °C or less

ODU -15 °C to 24 °C -15 °C to 24 °C -15 °C to 24 °C -15 °C to 24 °C

Model AR07TXFYAWKNEU AR07TXHZAWKNEU AR18TXFYAWKNEU AR24TXHZAWKNEU

Rating Mode Unit Wall-mounted Wall-mounted Wall-mounted Wall-mounted

Capacity

T1 Cool W 2000 2000 5000 6500

T3 Cool W - - - -

Heat W 2200 2200 6000 7400

Power Input

T1 Cool W 30 30 1390 1950

T3 Cool W - - - -

Heat W 30 30 1700 2350

Current

T1 Cool A 0.3 0.3 6.4 8.8

T3 Cool A - - - -

Heat - 0.3 0.3 7.8 10.5

Efciency

EER W/W - - 3.60 3.33

- - - - -

COP W/W - - 3.53 3.15

Dehumidifying l/hr. 1 1 2 2.5

Platform IDU - Q1 Q1 Q3 Q3 (AIRISE)

ODU - - - Q-480 Q-480

Evap

Main - Φ7, 2R*9(10)S*591mm,

H1.3, N.G.S, 1by2

Φ7, 2R*9(10)S*591mm,

H1.3, N.G.S, 1by2

Φ7, 2R*10S*825.5mm, H1.3,

N.G.S, 4by4

Φ7, 2R*10S*825.5mm, H1.3,

N.G.S, 4by4

Sub -Φ7, 2R*5(6)S*591mm, H1.3,

N.G.S : (Q-1-5)

Φ7, 2R*5(6)S*591mm, H1.3,

N.G.S : (Q-1-5)

Φ7, 2R*5(6)S*825.5mm,

H1.3, N.G.S : (Q-3-3)

Φ7, 2R*5(6)S*825.5mm,

H1.3, N.G.S : (Q-3-4)

Cond Main - - -

Φ7W, 2R*28S*906.8mm,

Corrugate1.5, N.G.S,

4by4by1

Φ7W, 2R*28S*906.8mm,

Corrugate1.5, N.G.S,

4by4by1

Sub - - - - -

Comp Model - - - UB9TK3150FE4 UB9TK2150FE4

OLP - - - - -

Motor In

Code - DB31-00694A DB31-00694A DB31-00636A DB31-00636A

Name - - - RD-310-25-8A(AL) / SIC-

41CVJ-F127-2

RD-310-25-8A(AL) / SIC-

41CVJ-F127-2

Motor Out

Code - - - DB31-00642C DB31-00658D

Name - - - RD-310-45-8B FMDC531SSE / YMA-

P095AE01A1

Expansion Φ * L - - - Φ1.4 Φ1.4

Refrigerant type - R-32 R-32 R32 R32

charge g - - 1300 g 1150 g

SVC Valve Liquid /

Gas - - - Φ6.35/Φ12.7 Φ6.35/Φ15.88

Tube Dis. / Suc. - - - Φ9.52/Φ12.7 Φ9.52/Φ12.7

Drain hose D * L mm 20*550 20*550 20*550 20*550

4-WAY V/V - - - 2 hp 2 hp

Power Supply V/Hz/Φ 220-240/50/1 220-240/50/1 220-240/50/1 220-240/50/1

Climate Class - T1 T1 T1 T1

Noise IDU UT,T dB 36 36 48/58 dB↓ 51 / 62 dB↓

ODU dB - - 57 / 65 dB↓ 60 / 68 dB↓

Net Size

(W*D*H)

IDU mm 820*299*215 820*299*215 1055*299*215 1055*299*215

ODU - - 880*638*310 880*638*310

Weight IDU kg 9.0 9.0 12.5 12.5

ODU - - 43.7 43.7

Operation

range

Cooling IDU 16 ˚C~32 ˚C 16 ˚C~32 ˚C 16 ~ 32℃ 16 ~ 32℃

ODU - - -10 ~ 46℃ -10 ~ 46℃

Heating IDU 27 °C or less 27 °C or less 8 ~ 27 °C 8 ~ 27 °C

ODU - - -15 ~ 24℃ -15 ~ 24℃

Model AR18TXHZAWKNEU AR24TXFYAWKNEU

Rating Mode Unit Wall-mounted Wall-mounted

Capacity

T1 Cool W 5000 6500

T3 Cool W - -

Heat W 6000 7400

Power Input

T1 Cool W 1390 1950

T3 Cool W - -

Heat W 1710 2350

Current

T1 Cool A 6.4 8.8

T3 Cool A - -

Heat - 7.8 10.5

Efciency

EER W/W 3.60 3.33

- - -

COP W/W 3.51 3.15

Dehumidifying l/hr. 2 2.5

Platform IDU - Q3 Q3 (GEO)

ODU - Q-480 Q-480

Evap

Main - Φ7, 2R*10S*825.5mm, H1.3,

N.G.S, 4by4

Φ7, 2R*10S*825.5mm, H1.3,

N.G.S, 4by4

Sub -Φ7, 2R*5(6)S*825.5mm,

H1.3, N.G.S : (Q-3-3)

Φ7, 2R*5(6)S*825.5mm,

H1.3, N.G.S : (Q-3-4)

Cond Main -

Φ7W, 2R*28S*906.8mm,

Corrugate1.5, N.G.S,

4by4by1

Φ7W, 2R*28S*906.8mm,

Corrugate1.5, N.G.S,

4by4by1

Sub - - -

Comp Model - UB9TK3150FE4 UB9TK2150FE4

OLP - - -

Motor In

Code - DB31-00636A DB31-00636A

Name - RD-310-25-8A(AL) / SIC-

41CVJ-F127-2

RD-310-25-8A(AL) / SIC-

41CVJ-F127-2

Motor Out

Code - DB31-00642C DB31-00658D

Name - RD-310-45-8B FMDC531SSE / YMA-

P095AE01A1

Expansion Φ * L -Φ1.4 Φ1.4

Refrigerant type - R32 R32

charge g 1300 g 1150 g

SVC Valve Liquid /

Gas -Φ6.35/Φ12.7 Φ6.35/Φ15.88

Tube Dis. / Suc. - Φ9.52/Φ12.7 Φ9.52/Φ12.7

Drain hose D * L mm 20*550 20*550

4-WAY V/V - 2 hp 2 hp

Power Supply V/Hz/Φ 220-240/50/1 220-240/50/1

Climate Class - T1 T1

Noise IDU UT,T dB 48/58 dB↓ 51 / 62 dB↓

ODU dB 57 / 65 dB↓ 60 / 68 dB↓

Net Size

(W*D*H)

IDU mm 1055*299*215 1055*299*215

ODU 880*638*310 880*638*310

Weight IDU kg 12.5 12.5

ODU 43.7 43.7

Operation

range

Cooling IDU 16 ~ 32℃ 16 ~ 32℃

ODU -10 ~ 46℃ -10 ~ 46℃

Heating IDU 8 ~ 27 °C 8 ~ 27 °C

ODU -15 ~ 24℃ -15 ~ 24℃

2-3 The comparative specication of product

Model DEVELOPMENT MODEL

AR09TXFYAWK/EU AR12TXFYAWK/EU AR09TXHZAWK/EU AR12TXHZAWK/EU

Design

Indoor Unit

Outdoor Unit

Net Weight Indoor Unit 8.6 8.6 8.6 8.6

Outdoor Unit 19.4 19.4 19.4 19.4

Net Dimension Indoor Unit 820*299*215 820*299*215 820*299*215 820*299*215

Outdoor Unit 660*475*242 660*475*242 660*475*242 660*475*242

Noise Indoor Unit 41 43 41 43

Outdoor Unit 53 53 53 53

Air Purifying System EASY CLEAN FILTER EASY CLEAN FILTER EASY CLEAN FILTER EASY CLEAN FILTER

Indoor Display 88 SEG 88 SEG 88 SEG 88 SEG

Model DEVELOPMENT MODEL

AR07TXFYAWKNEU AR07TXHZAWKNEU AR18TXFYAWKNEU AR24TXHZAWKNEU

Design

Indoor Unit

Outdoor Unit

Net Weight Indoor Unit 9.0 9.0 12.5 12.5

Outdoor Unit - - 43.7 43.7

Net Dimension

Indoor Unit 820*299*215 820*299*215 1055*299*215 1055*299*215

Outdoor Unit - - 880*638*310 880*638*310

Noise Indoor Unit 36 36 48/58 dB↓ 51 / 62 dB↓

Outdoor Unit - - 57 / 65 dB↓ 60 / 68 dB↓

Air Purifying System EASY CLEAN FILTER EASY CLEAN FILTER EASY CLEAN FILTER EASY CLEAN FILTER

Indoor Display 88 SEG 88 SEG 88 SEG 88 SEG

This manual suits for next models

Table of contents

Other Samsung Air Conditioner manuals

Samsung

Samsung AR18NSWXCWKNCV User manual

Samsung

Samsung AM280RNPDKH Series User manual

Samsung

Samsung AWT18WBHDE User manual

Samsung

Samsung SH07AWHX User manual

Samsung

Samsung 310 5G CPE User manual

Samsung

Samsung SH09CA1 User manual

Samsung

Samsung AM14A1E07 User manual

Samsung

Samsung AR09HSFSHWKNCV User manual

Samsung

Samsung AR12FSFPESNNEU User manual

Samsung

Samsung AVXWNH022EE User manual

Samsung

Samsung AG026MN1DEH/EU User manual

Samsung

Samsung MH18ZC1(C2)-09 User manual

Samsung

Samsung DC18BTSA User manual

Samsung

Samsung AVXDSH022EE User manual

Samsung

Samsung DVM-PRO 2008 User manual

Samsung

Samsung AQV18VBAAQV24VBAAQV18VBC User manual

Samsung

Samsung JH052EAV Series User manual

Samsung

Samsung DH052EAMG User manual

Samsung

Samsung AM KN4DCH Series User manual

Samsung

Samsung MH040FXA2B User manual

Samsung

Samsung NCAC 4 User manual

Samsung

Samsung AM***NN1DCH series User manual

Samsung

Samsung AMxxxJXV Series User manual

Samsung

Samsung AC026MNJDKH/EU User manual

Popular Air Conditioner manuals by other brands

Spheros

Spheros CC 355 instructions

Bosch

Bosch Climate 5000 SCI 24 CAS/ OU- OUE owner's manual

Panasonic

Panasonic CS-E12HKEW operating instructions

nedis

nedis ACMB1WT7 quick start guide

Daikin

Daikin FCFV50A Operation manual

Fujitsu

Fujitsu Inverter ASBA30JFC operating manual

Toshiba

Toshiba RAS-M10SMUV-E installation manual

Daikin

Daikin FXLQ20MAVE Operation manual

Hitachi

Hitachi RAS-E24CAK instruction manual

CIAT

CIAT Magister 2 Series Installation, Operation, Commissioning, Maintenance

Bestron

Bestron AAC6000 instruction manual

Hisense

Hisense 7K Use and Installation Instructions

Frigidaire

Frigidaire FFRE0533S1E0 Use & care guide

Frigidaire

Frigidaire CRA073PU11 use & care

Soleus Air

Soleus Air GB-PAC-08E4 operating instructions

McQuay

McQuay MCK020A Technical manual

Webasto

Webasto Frigo Top 25 DS Instructions for use

Frigidaire

Frigidaire FAZ12ES2A installation instructions
