Samsung AR TXCA Series User manual

Air conditioner

User manual

AR**TXCA***

Thank you for purchasing this Samsung air conditioner.

Before operating this unit, please read this user manual carefully and retain it for future

reference.

English

Contents

Safety Information 4

At a Glance 15

Indoor Unit Overview 15

Display 16

Remote Control Overview 17

Replacing the remote control batteries 17

Remote Control Operation 18

Selecting an operation mode 18

 

Smart Features 20

Power Smart Features 20

Wind-Free Cooling function 20

AI Auto mode 21

 

 

 

Variety Smart Features 25

Fast function 25

Motion detect function 26

 

 

Energy-Saving Features 30

 

 

 

 

 

English

Cleaning and Maintenance 35

Schedule 35

Cleaning 36

Appendix 42

Troubleshooting 42

Information about Refrigerant 44

SmartThings app 45

Reference 48

Correct Disposal of This Product

(Waste Electrical & Electronic Equipment)

(Applicable in countries with separate collection systems)

This marking on the product, accessories or literature indicates that the product and its electronic







responsibly to promote the sustainable reuse of material resources.





recycling.

Business users should contact their supplier and check the terms and conditions of the purchase



for disposal.

Correct disposal of batteries in this product

This marking on the battery, manual or packaging indicates that the batteries in this product should not











corporatecitizenship/data_corner.html

Safety Information

English

Safety InformationSafety Information

Safety Information

WARNING: Read This Manual



installation, use, or maintenance of this appliance. Incorrect

installation, use, or maintenance of this appliance can result in death,









characteristics of your air conditioner may differ slightly from those





Notices and notes





WARNING



or death.

CAUTION



property damage.

IMPORTANT

Information of special interest

NOTE

Supplementary information that may be useful

Safety Information

English

Safety InformationSafety Information

WARNING: Low burning velocity material

(This appliance is filled with R-32.)

The user and installer guides should be read carefully.

The service guide should be read carefully.

FOR GENERAL

This appliance is not intended for use by persons (including

children) with reduced physical, sensory or mental capabilities,

or lack of experience and knowledge, unless they have been

given supervision or instruction concerning use of the appliance

by a person responsible for their safety. Children should be

supervised to ensure that they do not play with the appliance.

For use in Europe : This appliance can be used by children aged

from 8 years and above and persons with reduced physical,

sensory or mental capabilities or lack of experience and

knowledge if they have been given supervision or instruction

concerning use of the appliance in a safe way and understand

the hazards involved. Children shall not play with the appliance.

Cleaning and user maintenance shall not be made by children

without supervision.

IMPORTANT

To perform its antimicrobial function this product has been

treated with the biocide substance Silver zinc zeolite.

Safety Information

English

Safety InformationSafety Information

FOR INSTALLATION

WARNING

Use a power cord with this product's power specifications or

higher and use the power cord forthis appliance only. In addition,

do not use an extension cord.

 

Do not use an electric transformer. This may result in electric

shock or fire.

 

may cause fire.

The installation of this appliance must be performed by a

qualified technician or service company.

Failing to do so may result in electric shock, fire, explosion,





Install an Isolation Switch next to the Air Conditioner (but not on

the panels of the Air Conditioner) and circuit breaker dedicated

to the air conditioner.

Failing to do so may result in electric shock or fire.

Fix the outdoor unit firmly so that the electric part of the outdoor

unit is not exposed.

Failing to do so may result in electric shock, fire, explosion, or



Do not install this appliance near a heater, or inflammable

material. Do not install this appliance in a humid, oily or dusty

location, in a location exposed to direct sunlight and water (or

rain). Do not install this appliance in a location where gas may

leak.

This may result in electric shock or fire.

English

Safety InformationSafety Information

Never install the outdoor unit in a location such as on a high

external wall where it could fall.

 

property damage.

This appliance must be properly grounded. Do not ground the

appliance to a gas pipe, plastic, water pipe, ortelephone line.

Failing to do so may result in electric shock, fire, and

explosion.

 

CAUTION

Please coverthe air conditionerwith PE BAG after installation,

and remove it when you start to run air conditioner.

Install your appliance on a level and hard floor that can support

its weight.

 



Install the drain hose properly so that water drains correctly.

 



arise in the future.

The product shall be stored in a room with no ignition sources

(e.g. open flames, gas appliance, electric heater, etc.).

Note that the refrigerant has no odour.

When installing the outdoor unit, make sure to connect the drain

hose so that draining is performed correctly.

 







Safety Information

English

Safety InformationSafety Information

Do not install the product in a place where thermo-hygrostat is

needed (such as server room, machinery room, computer room,

etc.)

 

of the product therefore performance can be poor in these

places.

FOR POWER SUPPLY

WARNING

When the circuit breaker is damaged, contact your nearest

service centre.

Do not pull or excessively bend the power line. Do not twist or tie

the power line. Do not hook the power line over a metal object,

place a heavy object on the power line, insert the power line

between objects, or push the power line into the space behind

the appliance.

This may result in electric shock or fire.

If the supply cord is damaged, it must be replaced by the

manufacturer, its service agent or similarly qualified persons in

orderto avoid a hazard.

CAUTION

When not using the air conditionerfor a long period of time or

during a thunder/lightning storm, cut the power at the circuit

breaker.

Failing to do so may result in electric shock or fire.

English

Safety InformationSafety Information

FOR USING

WARNING

If the appliance is flooded, please contact your nearest service

centre.

Failing to do so may result in electric shock or fire.

If the appliance generates a strange noise, a burning smell or

smoke, cut off the power supply immediately and contact the

nearest service centre.

Failing to do so may result in electric shock or fire.

In case of a malfunction, immediately stop operation of the

air conditioner and disconnect the entire power system. Then

consult the authorized service personnel.

In the event of a gas leak (such as propane gas, LP gas, etc.),

ventilate immediately without touching the power line. Do not

touch the appliance or power line.

 

A spark may result in an explosion or fire.

To reinstall the air conditioner, please contact your nearest

service centre.

 



 

the product in another location, additional construction



 

location such as in an industrial area or near the seaside





Safety Information

English

Safety InformationSafety Information

Do not touch the circuit breakerwith wet hands.

This may result in electric shock.

Do not turn the air conditioner off with the circuit breakerwhile

it is operating.

 

circuit breaker may cause a spark and result in electric shock

or fire.

After unpacking the air conditioner, keep all packaging materials

well out of the reach of children, as packaging materials can be

dangerous to children.

 

suffocation.

Do not touch the airflow blade with your hands or fingers during

heating.

This may result in electric shock or burns.

Do not insert your fingers orforeign substances into the air inlet/

outlet of the air conditioner.

 

inserting their fingers into the product.

Do not strike or pull the air conditionerwith excessive force.

 

Do not place an object nearthe outdoor unit that allows children

to climb onto the machine.

 

Do not use this air conditioner for long periods of time in badly

ventilated locations or near infirm people.

Since this may be dangerous due to a lack of oxygen, open a


