Samsung AR BXEA Series User manual

Air conditioner

Quick Guide

AR**BXEA**** / AR**BXFC****

•Thank you for purchasing this Samsung air conditioner.

•Before operating this unit, please read this manual carefully and retain it for future reference.

English

Preparation

Connecting SmartThings

Launch a QR code reader app and scan the QR code image on the product.

Try connecting the SmartThings app to the product.

Registering the product / Reading the manual / Connecting to Services

Launch a QR code reader app and scan the QR code image on the product.

Choose the desired menu from the Product Registration, Manual, Customer Support.

If you choose 'Manual' you can read the manual of the product you purchased.

NOTE

•We provide online manuals that can be accessed via your smartphone or our website to contribute

in reducing the usage of manuals in paper format, as part of efforts to save the Earth.

English

01 Air intake

02 Air filter

03 Tri-care filter (For AR**BXEA**** models)

04 WindFree panel

05 Airflow blade (up and down)

06 Airflow blade (left and right)

07 Power button/Remote control receiver

08 Room temperature sensor

09 Display

NOTE

•The product ships with two Tri-care filters and the

manual included.

Display

02 03 04

01 Temperature indicator (numeric)

Filter reset indicator ( )

Electricity consumption indicator (numeric /

For the multi system, usage time indicator)

Auto clean indicator ( )

Defrost indicator ( )

02 AI Auto indicator

03 Timer indicator

good’sleep indicator

04 Wi-Fi indicator

NOTE

•When the Wi-Fi is turned on, the indicator blinks

three times and then turns on.

The appearance of the actual product may differ slightly from the image below.

Indoor Unit Overview

English

Operating the Air Conditioner

Functions and Buttons

Function Button and Selection Display

Power On/Off

WindFree

Cooling In Cool/Dry/Fan mode ▶

AI Auto ▶ ▶ Select Auto.

Auto ▶ ▶ Select Auto.

Cool ▶ ▶ Select Cool.

Dry ▶ ▶ Select Dry.

Fan ▶ ▶ Select Fan.

Heat ▶ ▶ Select Heat.

Fast In Cool or Heat mode ▶

Eco In Cool or Heat mode ▶ ▶

▶ Select Eco. ▶

Quiet In Cool or Heat mode ▶ ▶

▶ Select Quiet. ▶

Electricity

consumption

check

In operation ▶ ▶ ▶

Select Usage. ▶

Usage time

check

In operation ▶ ▶ ▶

Select Usage. ▶

Beep ▶ ▶ Select Beep. ▶

01 Display

02 Button

NOTE

•Although Purify, Direct, Indirect

is displayed on the remote control

display, it is not available on this

model.

•Features may differ depending on

models.

English

Function Button and Selection Display

Display lighting ▶ ▶ Select Display. ▶

Wi-Fi

(SmartThings)

▶ Press and hold for 5 or more

seconds.

Wi-Fi (On/Off)

and

▶ Press and hold for

5 or more seconds.

Timed on/off

▶ Select On or Off ▶

(Set the duration.) ▶

good'sleep

In Cool or Heat mode

▶

(Select .) ▶

(Set the duration.) ▶

English

Cleaning

Auto clean function

Use the Auto clean function if the indoor unit produces odors.

Activating Auto clean

To activate Auto clean, press the (Options) button for at least 3 seconds.

The indoor unit display shows:

Canceling Auto clean

To cancel Auto clean while it is running, follow the procedure below:

▶Press and hold for 3 or more seconds.

Deactivating Auto clean

To deactivate Auto clean, follow the procedure below while the air conditioner is in operation or turned off:

▶ ▶ Select Clean. ▶

Cleaning the filter

Clean the air filter every two weeks or when the (filter-cleaning reminder) appears on the indoor unit

display. The time between cleanings may vary, depending on the usage and environmental conditions.

Vacuum cleaner

Soft brush 30 minutes

Mild detergent

English

1 Slide the filter off of the unit.

2 Use a soft brush or vacuum cleaner to remove any dust or debris on the filter.

3 Soak the filter in a solution of water and mild detergent for 30 minutes.

4 Rinse the filter and let it air dry in a well-ventilated area that is out of direct sunlight.

5 Reinstall the filter.

6 Reset the filter-cleaning reminder:

In operation ▶▶ ▶ Select Filter Reset. ▶

Replacing the Tri-care filter (ForAR**BXEA**** models)

Slide a new Tri-care filter in the direction of arrow 2.

Replace Tri-care filters once every three years. Replacement cycle may differ depending on the environment

and usage time.

Tri-care filter

CAUTION

•Do not clean the Tri-care filterwith water. Failing to do so may result in damage to the filter.

NOTE

•To replace a Tri-care filter, purchase a new one at a service centre.

•To use the Tri-care filter for a long time in an environment where fish cooking and smoking cause odour,

ventilate the place by opening a window.

COUNTRY CALL OR VISIT US ONLINE AT

UK 0333 000 0333 www.samsung.com/uk/support

IRELAND (EIRE) 0818 717100 www.samsung.com/ie/support

GERMANY 06196 77 555 77 www.samsung.com/de/support

FRANCE 01 48 63 00 00 www.samsung.com/fr/support

ITALIA 800-SAMSUNG (800.7267864) www.samsung.com/it/support

SPAIN 91 175 00 15 www.samsung.com/es/support

PORTUGAL 808 207 267 www.samsung.com/pt/support

LUXEMBURG 261 03 710 www.samsung.com/be_fr/support

NETHERLANDS 088 90 90 100 www.samsung.com/nl/support

BELGIUM 02-201-24-18 www.samsung.com/be/support (Dutch)

www.samsung.com/be_fr/support (French)

NORWAY 21629099 www.samsung.com/no/support

DENMARK 707 019 70 www.samsung.com/dk/support

FINLAND 030-6227 515 www.samsung.com/fi/support

SWEDEN 0771-400 300 www.samsung.com/se/support

POLAND 801-172-678* lub +48 22 607-93-33*

* (opłata według taryfy operatora) http://www.samsung.com/pl/support/

HUNGARY 0680SAMSUNG (0680-726-7864) www.samsung.com/hu/support

AUSTRIA 0800 72 67 864 (0800-SAMSUNG) www.samsung.com/at/support

SWITZERLAND 0800 726 786 www.samsung.com/ch/support (German)

www.samsung.com/ch_fr/support (French)

CZECH 800 - SAMSUNG (800-726786) www.samsung.com/cz/support

SLOVAKIA 0800 - SAMSUNG (0800-726 786) www.samsung.com/sk/support

CROATIA 072 726 786 www.samsung.com/hr/support

BOSNIA 055 233 999 www.samsung.com/ba/support

North Macedonia 023 207 777 www.samsung.com/mk/support

MONTENEGRO 020 405 888 www.samsung.com/support

SLOVENIA 080 697 267 (brezplačna številka) www.samsung.com/si/support

SERBIA 011 321 6899 www.samsung.com/rs/support

ALBANIA 045 620 202 www.samsung.com/al/support

BULGARIA

0800 111 31 - Безплатен за всички оператори

*3000 - Цена на един градски разговор или според

тарифата на мобилният оператор

09:00 до 18:00 - Понеделник до Петък

www.samsung.com/bg/support

ROMANIA 0800872678 - Apel gratuit

*8000 - Apel tarifat în reţea www.samsung.com/ro/support

CYPRUS 8009 4000 only from landline, toll free

www.samsung.com/gr/support

GREECE 80111-SAMSUNG (80111 726 7864) only from land line

(+30) 210 6897691 from mobile and land line

LITHUANIA 8-800-77777 www.samsung.com/lt/support

LATVIA 8000-7267 www.samsung.com/lv/support

ESTONIA 800-7267 www.samsung.com/ee/support

QUESTIONS OR COMMENTS?

This appliance is

filled with R-32.
