Royal Sovereign RSS-1050 User manual

Royal Sovereign LAMINATORS

OWNER'S MANUAL

RSS-1200,1050 ,685

PLEASE READ AND SAVE INSTRUCTIONS.

- 1 -

MEMO ----------------------------------------------------------------------------------------------

1.HOT FILM -----------------------------------------------------------------------------------------

2.COLD FILM ---------------------------------------------------------------------------------------

CONTROL OF ROLLER PRESSURE ------------------------------------------------------

INSTRUCTIONS FOR CONTROL PANEL ------------------------------------------------

PAGETOPICS

INTRODUCTION --------------------------------------------------------------------------------

SAFETY PRECAUTIONS --------------------------------------------------------------------

3.HOW TO USE BUTTONS -------------------------------------------------------------------

LAMINATING STEPS ---------------------------------------------------------------------------

1.HOT LAMINATING ----------------------------------------------------------------------------

2.COLD LAMINATING --------------------------------------------------------------------------

CHARACTERISTICS -----------------------------------------------------------------------------

SPECIFICATIONS ---------------------------------------------------------------------------------

18~20

26WARRANTY --------------------------------------------------------------------------------------

IT'S NOT OUT OF ORDER. --------------------------------------------------------------------

SPARE PART ----------------------------------------------------------------------------------------

IMPORTANT SAFETY CONCERNS. -------------------------------------------------------

MAINTENANCE ------------------------------------------------------------------------------------

TIPS FOR REMOTE CONTROL AND FOOT SWITCH ----------------------------------

METHOD FOR USING CUTTER --------------------------------------------------------------

1.CROSS CUTTER -------------------------------------------------------------------------------

2.SLITERS -------------------------------------------------------------------------------------------

14~17

SETTING UP FILM -------------------------------------------------------------------------------

HANGING FILM -----------------------------------------------------------------------------------

1.LCD WINDOW ----------------------------------------------------------------------------------

2.FUNCTIONS OF BUTTONS ----------------------------------------------------------------

DJUSTMENT OF FILM TENSION AND LOCATIONS --------------------------------

TABLE OF CONTENTS

NAMES OF MAJOR PARTS OF MACHINE ------------------------------------------------

- 2 -

5. Do not operate machine for any other purposes than its intended use.

6. Do not operate machine if electrical plug or power cord is damaged.

8. This machine is intended for indoor use only.

Thank you for purchasing a Royal Sovereign Roll Laminator. It has been designed and

manufactured to provide years of continuous service in the professional environment.

To insure high quality lamination, please read this instruction manual thoroughly.

This manual will provide you with complete operating and maintenance information.

For additional product support or factory-direct ordering information.

Call Royal Sovereign Customer Service at (800) 397-1025.

liquids to spill inside.

to comply any of the following safety procedures could result in serious personal injury.

1. To prevent the possibility of electrical shock, do not immerse machine in water or permit

The safety recommendations outlined in this section are to be read, understood and

followed before operating machine. Keep this information for future reference. Failure

2. Do not allow articles of clothing (neckties, scarves, papers, etc.) near front or rear

machine openings as they could get caught by rollers and be pulled inside, causing

7. Turn off the power when unattended or not in use. Unplug machine before movig it or

when it is not in use for an extended period of time.

9. Do not alter or extend electric plug. Plug is configured for appropriate electrical supply.

10. The socket-outlet shall be installed mear the equipment and shall be easily accessible.

personal injury.

3. Do not insert sharp objects into front or rear machine openings. Do not place anything

in feed tray openings of machine other than appropriate laminating materials or pouches.

4. Do not attempt to laminate items that exceed total recommended material thickness.

INTRODUCTION

SAFETY PRECAUTIONS

- 3 -

Remote control device allows for control of the machine from the front or rear.

thickness of film and materials to be laminated.

Yes

1200(mm)

47.2(in)

1050(mm)

41.3(in)

685(mm)

27(in)

Yes

221

Yes

Film Alignment

Cutter-Cross

Foot-Switch

AC 100~120/ 200~240V 50~60Hz

6m/min (19.7ft/min)

3000W 3000W 2000W

13mm ( 0.5in)

25~250mic (1 ~ 10mil)Film Thickness

Cold and Hot Laminating

Cooling Blower

Take Up

Power Consumption

Max.Laminating Speed

Max.Laminating Width

Max.Laminating Thickness

Unit Dimensions

Unit Weight

RSS-1200

1070*650*1205(mm)

42.1*25.6*47.4(in)

190(Kg)

418(lbs)

140(Kg)

308(lbs)

100(Kg)

220(lbs)

1400*650*1210(mm)

55.1*25.6*47.4(in)

1550*650*1210(mm)

61*25.6*47.4(in)

Foot-Pedal Switch allows for hands-free operation. It is also designed for convenient use

the latest in laminating technology. It is designed for you to set temperature and speed as

necessary and have the machine remember your settings. Also, you can laminate anything

at high speed, regardless of thickness of material and type of film.

RS Roll Laminator Line are advanced laminators with time transcendental design, utilizing

RSS-1050 RSS-685Description

Voltage/Cycles

CHARACTERISTICS

Yes

SPECIFICATIONS

by anyone through the simple procedure of adjusting film tension in accordancs with the

Paper Counting

Length Measurement

- 4 -

1. FILM-UPPER 8. FOOT SWITCH

2. FILM-LOWER 9. REMOTE CONTROL SWITCH

3. TAKE-UP (ASS'Y-TAKE-UP) 10

CONTROL PANEL

4. IDLER BAR (UPPER) 11

PRESSURE LEVER

5. TABLE-FRONT 12

TENSION CONTROL KNOB

6. SHOE-HEATER,UPPER 13

ALIGNMENT KNOB

7. ASS'Y-STAND 14

TAKE-UP SWITCH

NAMES OF MAJOR PARTS OF MACHINE

13 14

- 5 -

1. HOW TO CONTROL TENSION

2. HOW TO ADJUST ALIGNMEN

Location control device is used when the edges of the lamination are unjustified.

As the drawing shows, when the alignment knob is turned clockwise, the upper film is

to left. Once proper alignment is reached, turn the Locking Nut tight against the Alignment

knob so the adjustment is set.

ADJUSTMENT OF FILM TENSION AND LOCATIONS

can adjust it, to some extent, and make wrinkles straighten from Anti-Wrinkle Part of the

Tension of film can be controlled depending on the state of lamination, but basically you

heat shoe. To increase the tension on the film, turn the knob clockwise.

To lower the tension, turn the handle counter clockwise. If lamination is curved upward,

it means that tension of upper film is high. In this case, it can be controlled by raising

moved to right. On the contrary, when the handle is turned counter-clockwise, it is moved

apply the method in reverse.

tension of lower film or lowering tension of upper film. If lamination is curved downward,

Alignment Knob.

Locking Nut

Tension Control Knob

필름

주름방지부

필름

열판

Film

Shoe-Heater

Film

Anti-Wrinkle

device

- 6 -

1. Set the glossy side of upper/lower film to face the heat.

( Glossy side is PET film and matte side is thermal polymer laminating film.)

2. Like picture 1, insert core into the left side of upper/lower film shaft.

3. Like picture 2 and 3, insert core into the right side of upper/lower film.

4. Like picture 4 and 5, adhere core closely.

(Make the right/left direction of fixing screw consistent.)

5. Locate film in the middle, and then fasten core fixing screw.

SETTING UP FILM

Picture 1

Upper Film

Lower Film

Upper Film

Lower Film

Picture 2

Picture 3

Picture 4

Picture 5

Core Fixing

Screw

- 7 -

1. HOT FILM

10. After checking the status of lamination, Place the pressure lever at the proper

lamination mode.

6. Allow some of the film with melted resin to stick to the Guiding Paper.

7. Repeat step 5 with lower roll film then stick it to the Guiding Paper.

fed through to the rear roller without tension.

8. Unwind 30~40cm(1~1.3ft) of both rolls of film, to loosen the film tension. This should be

1. Insert the bar into the core of roll film then place the bar on the machine.

HANGING FILM

beyond the second set of rollers.

9. Set speed at 1 and press the "RUN" button to feed film into the machine.

2. Place the Pressure Lever to the open mode (10~13mm).

3. Insert a piece of lightweight cardboard (Guiding Paper) between the rollers, through to

**IMPORTANT : It should reach beyond the second set of rollers. It should stick out

5cm (2") in front of front roller.

4. Pull the upper film around the upper idler bar to the anti-wrinkle device and stretch out

the film on the upper heat shoe.

5. When the temperature reaches 80°C (176°F), the resin is melting, stick the film on the

shoe.

SHAFT

LOWER IDLE BAR

UPPER ROLL FILM

SHAFT

LOWER ROLL FILM

GUIDING PAPER

HEAT SHOE

UPPER IDLE BAR

LOWER FILM

SHAFT

LOWER IDLE BAR

HEAT SHOE

Picture 1

- 8 -

2. COLD FILM

1. Take out the guiding table.

2. Put the shaft of roll film in each hole exactly.

3. Set the pressure lever to the proper lamination mode.(1mm/5mm/10~13mm)

4. Pull the film around the idler bar to the Anti-wrinkle device.

5. Put the paper back of the film to the bobbin at take-up bar to rewind the paper back.

**It is to be stuck on to roll up clock wise.

6. Place the sticky part of film on the upper shoe and get ready to laminate.

PAPER BACK

TAKE UP DEVICE

HEAT SHOE

UPPER FILM SHAFT

COLD FILM

UPPER IDLE BAR

- 9 -

1. For setting, pull the pressure lever out and turn the lever to following

the indication.

5. Laminating : Mode that you can do laminate 25mic(1mil) to 250mic(10mil)

2. 10~13mm Board : Mode that you can laminate 10~13mm(1/3" to 1/2")

3. 5mm Board : Mode that you can laminate 5mm(1/4") hard board

4. 1mm hard board : Mode that you can laminate 1mm(40mil) hard board

CONTROL OF ROLLER PRESSURE

***Methods of controlling pressure of the roller ***

- 10 -
