Royal Sovereign ES-410 User manual

Royal Sovereign International, Inc.

ES-410

LAMINATOR

Owner's Manual

Please read and retain these instructions.

To register your product, please go to www.royalsovereign.com USA.

Click the Customer Support Tab then Registration Tab.

www.royalsovereign.com

Página en Español 9

Page en Français 17

LAMINATOR

ES-410

SAFETY INSTRUCTIONS

The safety recommendations outlined in this section should be read and understood before operating this machine. When

using this machine follow these basic safety precautions to reduce risk of fire, electric shock or injury. Keep this information

for future reference.

1. To prevent the possibility of a fire or injury, do not allow foreign articles inside the machine.

2. Do not attempt to laminate items that exceed total recommended material thickness.

3. Do not insert pouch film with the back end first. (Front of film: sealed side, Back of film: open side.) This may cause

the pouch to jam the rollers.

4. To prevent the possibility of electric shock, do not immerse the laminator in water or permit liquids inside the machine.

5. Because the laminator creates heat, keep out of the reach of children.

6. Do not cut pouches before inserting them into the laminator. This will cause the laminator to jam.

7. Do not laminate leaves, flower, clothes etc.

 8. Iftheroomtemperatureislow(under64˚F),thereadylightmaytakelongertocomeon.

9. When unplugging the power plug, grip the plug to pull it out. Pulling the cord may result in electric shock, fire, or

damage to the machine.

10. Do not use the machine if the cord is damaged. This may result in electric shock, fire, or other hazards.

11. Do not place objects on the power cord and do not bend it excessively. This may result in electric shock, fire or other hazards.

12. When not using the machine for long periods of time, unplug the power cord from the outlet.

Box Contents 5

Parts 5

Controls 5

Features 5

Operation 6

Troubleshooting 7

Specifications 7

Warranty 8

Contact Information 8

Página en Español 9

Page en Français 17

CONTENTS

ES-410

Control switch

Front opening

Ready light

BOX CONTENTS

Laminator and pouch film

PARTS

CONTROLS

Cold Lamination Hot lamination

Power off

FEATURES

Hot and Cold Lamination

By simply flipping the control switch, this machine can be adjusted to handle hot and cold lamination pouch film. Accepts

pouches 3-5 mil thick.

Ready Light

A blue ready light clearly indicates when the machine has reached optimal temperature and is ready to laminate.

Portability

This lightweight laminator is easily maneuverable from home to office and small enough to be stored on a tabletop.

OPERATION

Hot Lamination

1. Place the machine on a flat, sturdy surface.

2. Turn the control switch to the hot position . The machine will take approximately 8 minutes to warm-up.

When the proper temperature is reached, the ready light will glow steady.

3. Place the item to be laminated into the laminating pouch.

4. Insert the pouch film into the front opening of the laminator. Make sure to place the sealed end of the pouch film in first.

5. The document or photo will then automatically feed out the through the back of the machine.

NOTE: Laminated items exiting the machine may be too hot to touch.

6. If the item is not completely laminated, repeat steps 4-5.

NOTE: Laminated items will be hot and will easily bend. To keep the item flat, place on a flat surface and allow it to cool.

Before laminating important or unique documents,

always test a pouch through the laminator using a similar document.

Cold Lamination

1. Place the machine on a flat, sturdy surface.

2. Turn the control switch to the cold position . If the machine was previously used in hot mode, allow

approximately 25 minutes to cool down. When the proper temperature is reached, the ready light will glow steady.

3. Place the document to be laminated on the adhesive side of the cold film with the document face down, sealed end first.

4. Insert the document to be laminated into the front opening of the machine.

5. Remove paper liner from the cold film slowly while the document is being inserted into the machine.

4mm

7mm 7mm

4mm

7mm 7mm

ES-410

Symptom Solution

Motor does not work. Check to make sure machine is plugged in. Check to make sure the control

switch is turned to hot or cold.

Pouches are not laminating correctly. Make sure that the machine is set to the hot setting.

TROUBLESHOOTING

If you are still having complications, please contact Royal Sovereign’s Service Center at 1-800-397-1025.

SPECIFICATIONS

Model ES-410

Dimensions 8.9 x 5.2 x 3.5 (inch) / 226 x 133 x 89 (mm)

Maximum laminating width 4.4" / 112 mm

Maximum laminating thickness 27.6 mil / 0.7 mm

Film thickness 3~5 mil / 75~125 micron

Number of rollers 2

Cold mode Yes

Heating system Hot shoe

Ready time 8 minutes

Motor type AC motor

Laminating speed 6.5" per min. / 165mm per min.

Weight 1.9 lbs / 0.86 kg

Voltage/Cycle 120 V, 60 Hz

Power consumption 110W

LIMITED ONE YEAR WARRANTY

This warranty applies to repair or replacement of product found to be defective in material or workmanship for one year

from the date of the original purchase. This warranty is extended only to the original purchaser.

This warranty does not apply to damage resulting from abuse, misuse, or improper maintenance of damage that is

attributable to acts of nature. Royal Sovereign International, Inc. (and its affiliated companies) is not liable for incidental or

consequential damages of any nature. This limitation would not apply if you live in those areas that do not permit the

exclusion or limitation of incidental or consequential damages.

Defective products for warranty repair or replacement cannot be returned without a Return Authorization number. Please

go to www.royalsovereign.com USA-Customer Support Tab to make a request for an Office Product Return Authorization

Defective products must be returned to Royal Sovereign International Consumer Return Department, freight prepaid, with

proof of purchase and Return Shipping and Handling payment (check or money order). Upon repair or replacement the

product will be returned to the customer.

Return defective product to the following address with a detailed description of the problem. If possible, pack in original

carton. Please prepay shipping charges.

For out of warranty service or frequently asked questions please go to www.royalsovereign.com USA- Customer Support Tab.

For sales of product, parts or accessories please visit us at www.royalfulfillmentcorp.com.

For service or sales please contact your local Royal Sovereign Office:

ROYAL SOVEREIGN INTERNATIONAL, INC. RS CANADA INC.

2 Volvo Drive Rockleigh, NJ 07647 USA 1025 Westport crescent, Mississauga, Ontario, Canada L5T1E8

TEL : +1) 800-397-1025 FAX : +1) 201-750-1022 TEL : +1) 800-397-1025 FAX : +1) 201-750-1022

www.royalsovereign.com

Royal Sovereign International, Inc.

ES-410

LAMINADORA

Manual del Propietario

Por favor lea y conserve estas instrucciones.

Para registrar su producto, visite el sitio web www.royalsovereign.com USA.

Haga clic en la pestaña de “Customer Support” y después en la pestaña de “Registration”.

www.royalsovereign.com

Página en Español 9

Page en Français 17

Español

LAMINADORA
